华为全系列路由器1.产品概述:华为全系列路由器是华为公司开发的网络设备,用于实现局域网和广域网之间的连接。
它们提供高性能和可靠的数据传输,适用于各种规模的企业和机构。
2.路由器类型:2.1 家用路由器- 适用于小型家庭和个人用户,提供基本的无线网络连接和有限的局域网管理功能。
- 型号:华为AR1200、华为AR160、华为AR2200等。
2.2 中小型企业路由器- 针对中小型企业网络需求,提供更强大的性能和功能,包括高速数据传输、多重WAN连接、安全防护等。
- 型号:华为AR3200、华为AR3600、华为AR6000系列等。
2.3 大型企业路由器- 适用于大型企业和运营商网络,具有高密度的接口、高速的数据处理能力和灵活的扩展性。
- 型号:华为NE20E-S系列、华为NE5000E系列等。
3.功能特性:3.1 网络接口- 提供以太网接口、光纤接口和电信运营商专线接口,支持不同的网络连接方式。
- 支持多个VLAN、QinQ、虚拟路由和VRF等功能。
3.2 路由和转发- 支持静态路由、动态路由和策略路由,实现数据的快速转发和选择最佳路径。
- 支持IPv4和IPv6协议,满足不同网络环境的需求。
3.3 安全防护- 提供防火墙、入侵检测和防御、虚拟专用网络和VPN等安全功能,保护网络安全。
- 支持访问控制列表(ACL)和流量监测,实现精确的流量控制和管理。
3.4 QoS和流量控制- 支持基于服务质量(QoS)的流量优化和控制,确保重要数据的传输质量。
- 支持流量统计和流量限速功能,实现对网络带宽的有效管理。
4.配置和管理:4.1 命令行界面(CLI)- 提供基于文本的命令行界面,方便管理员进行配置和管理。
- 支持批量命令和自动化脚本,简化操作和提高效率。
4.2 图形用户界面(GUI)- 提供基于Web的图形界面,通过图形化的方式进行配置和管理。
- 支持实时监控和诊断工具,方便故障排除和性能调优。
4.3 远程管理- 支持SSH和Telnet等远程管理协议,方便管理员远程访问和管理路由器。
Product OverviewHuawei ® NetEngine40E Universal Service Router (NE40E) Series routers are high-end network products developed by Huawei. The NE40E Series routers are usually deployed at core nodes on enterprise wide area networks (WANs), access nodes on large-scale enterprise networks, interconnection and aggregation nodes on campus networks, and edge nodes on large-scale Internet Data Center (IDC) networks. The NE20E, NE40E, and NE5000E can work together to provide a complete hierarchical IP network solution.The NE40E Series includes the NE40E-X3, NE40E-X8, NE40E-X16, NE40E-X3A, NE40E-X8A and NE40E-X16A, as shown in Figure 1.Figure 1Huawei NE40E Series routers (Front)NE40E-X3 (DC)NE40E-X3 (AC)NE40E-X8NE40E-X16NE40E-X16A NE40E-X8ANE40E-X3A(DC)NE40E-X3A(AC)Figure 2Huawei NE40E Series routers (Back)NE40E-X3 (DC)NE40E-X3 (AC)NE40E-X8NE40E-X16NE40E-X16ANE40E-X8ANE40E-X3A(AC)NE40E-X3A(DC)The NE40E Series routers run on the Versatile Routing Platform (VRP ®) operating system and useHuawei-developed NP chips and hardware-based forwarding and non-blocking switching technologies. Based on distributed hardware forwarding, non-blocking switching technologies, distributed Clos architecture, and industry-leading 2T bps platform, the NE40E Series routers have the following features:●Support for 1T routing line cards in each slot, with excellent compatibility with currently used line cards toprotect carriers' investments to the largest extent.●Line speed forwarding capabilities, industry-leading reliability, excellent scalability, a well-designedquality of service (QoS) mechanism, and strong service processing capabilities.●Powerful service access and aggregation capabilities and various features, such as Layer 2 virtual privatenetwork (L2VPN), L3VPN, multicast, multicast VPN (MVPN), and Multiprotocol Label Switching - Traffic Engineering (MPLS-TE).●Various service features, such as IP Security (IPSec), Network Address Translation (NAT), and NetStream.●Support for IPv6 and smooth transition from IPv4 to IPv6.The NE40E can be flexibly deployed at the edge or core of IP or MPLS networks, simplifying network structure. With its ability to provide an extensive range of services and reliable service quality, the NE40E is driving IP and MPLS bearer networks to develop greater broadband capacity and to become more secure, more intelligent, and more service-oriented.Product FeaturesTable 1 lists the features of the Huawei NE40E Series Routers. Table 1.Features of Huawei NE40E Series RoutersProduct SpecificationsTable 2 lists the specifications of Huawei NE40E Series Routers. Table 2.Specifications of Huawei NE40E Series Routers1. In the physical dimensions shown in the table, the width (W) does not include the rack-mounting ears.2. Temperature and humidity are measured at 1.5 m (4.92 ft.) above the floor and 0.4 m (1.31 ft.) in front of the cabinet. Thereshould be no protection board on the front or back of the cabinet.3. "Short-term" refers to continuous working time that does not exceed 96 hours and accumulated working time per yearthat does not exceed 15 days. If the working time exceeds either of these values, it is considered "nominal" or "long-term".4.The bundle values in "Weight (full configuration)" include the weight of the interface boards in full configuration.Ordering InformationTo place an order, visit the UniSTAR SCT Workspace.Basic Hardware ConfigurationsTable 3.NE40E-X16A Basic Configuration BundleTable 4.NE40E-X8A Basic Configuration BundleTable 5.NE40E-X3A Basic Configuration BundleTable 6.NE40E-X16 Basic Configuration BundleTable 7.NE40E-X8 Basic Configuration BundleTable 8.NE40E-X3 Basic Configuration BundleTable 9.NE40E-X16A/X8A/X16/X8 PowersTable 10.NE40E-X3A/X3 PowersTable 11.CF/SDRAM/Other ComponentsService Interface BoardsTable 12.NE40E Series 50G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 13.NE40E Series 50G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 14.NE40E Series 120G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 15.NE40E Series 120G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 16.NE40E Series 200G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 17.NE40E Series 200G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 18.NE40E Series 240G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 19.NE40E Series 240G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 20.NE40E Series 480G Flexible Card Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 21.NE40E Series 480G Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 22.NE40E Series 1T Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Table 23.NE40E Series 2T Integrated Line Processing Units ("●" indicates "support", and "-" indicates "not support")Versatile Service BoardsTable 24.NE40E Series Service Process Units ("●" indicates "support", and "-" indicates "not support")Software ConfigurationTable 25.Software LicenseDocumentsTable 26.Documents for NE40EOptical/Electrical Transceivers Table 27.100G Optical TransceiverTable 28.50G Optical TransceiverTable 29.40G Optical TransceiverTable 30.FE/GE/10GE Optical TransceiverTable 31.622M SFP/eSFP Optical TransceiverTable 32.155M SFP/eSFP Optical TransceiverTable 33.GE CWDM Optical TransceiverTable 34.10GE CWDM Optical TransceiverPower Distribution BoxesTable 35.High-power distribution boxesBreakoutTable 36.100G QSFP28 Breakout BoxesTelescopic SlidesTable 37.Telescopic SidesSoftware Upgrade PathsVisit Software Upgrade Paths to get VRP software release version or patches.For More InformationFor more information about the Huawei NE40E Series Routers, visit or contact us in the following ways:●Global service hotline: /en/service-hotline●Logging into the Huawei Enterprise technical support web: /enterprise/●Sendinganemailtothecustomerservicemailbox:********************Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.Trademark Notice, HUAWEIandare trademarks or registered trademarks of Huawei Technologies Co., Ltd.Other trademarks, product, service and company names mentioned are the property of their respective owners.General DisclaimerThe information in this document may contain predictive statementsincluding, without limitation, statements regarding the future financial and operating results, future product portfolio, new technology, etc. There are a number of factors that could cause actual results and developments to differ materially from those expressed or implied in the predictivestatements. Therefore, such information is provided for reference purpose only and constitutes neither an offer nor an acceptance. Huawei may change the information at any time without notice.HUAWEI TECHNOLOGIES CO.,LTD.Huawei Industrial BaseBantian, LonggangShenzhen 518129, P.R. ChinaTel: +86-755-28780808。
华为公司数通全系列产品速查手册华为技术有限公司行业数通产品部2011年6月目录1NE路由器系列产品 .................................................................................................... 1-11.1NE 5000E集群路由器.................................................. 1-11.1.1NE 5000E集群路由器.................................................. 1-11.1.2简介 ................................................................ 1-11.1.3外观 ................................................................ 1-11.1.4关键特性............................................................. 1-21.1.5产品规格............................................................. 1-31.1.6定购信息............................................................. 1-41.2NE 5000E-X16 集群路由器.............................................. 1-71.2.1简介 ................................................................ 1-71.2.2外观 ................................................................ 1-71.2.3关键特性............................................................. 1-81.2.4产品规格............................................................. 1-91.2.5定购信息............................................................ 1-101.3NE40E 全业务路由器.................................................. 1-131.3.1简介 ............................................................... 1-131.3.2外观 ............................................................... 1-131.3.3关键特性............................................................ 1-131.3.4产品规格............................................................ 1-141.3.5定购信息............................................................ 1-161.4NE20E-X6 高智能业务路由器........................................... 1-191.4.1产品概述............................................................ 1-191.4.2外观 ............................................................... 1-191.4.3产品特点............................................................ 1-191.4.4产品规格............................................................ 1-211.4.5定购信息............................................................ 1-231.5NE20E/20系列多业务路由器........................................... 1-251.5.1产品特点............................................................ 1-251.5.2产品规格............................................................ 1-261.5.3定购信息............................................................ 1-27 2S系列交换机产品........................................................................................................ 2-12.1S9300系列T比特核心路由交换机....................................... 2-12.1.1产品特点............................................................. 2-12.1.2产品规格............................................................. 2-42.1.3配置指南............................................................. 2-62.1.4订购信息............................................................. 2-72.1.5解决方案应用........................................................ 2-11 2.2S7700系列智能路由交换机............................................ 2-132.2.1产品特点............................................................ 2-132.2.2产品规格............................................................ 2-152.2.3订购信息............................................................ 2-182.2.4解决方案应用........................................................ 2-21 2.3S6700系列万兆交换机................................................ 2-232.3.1产品概述............................................................ 2-232.3.2产品特点............................................................ 2-232.3.3产品规格............................................................ 2-252.3.4组网应用............................................................ 2-282.3.5订购信息............................................................ 2-29 2.4S5700系列全千兆企业网交换机........................................ 2-302.4.1产品概述............................................................ 2-302.4.2产品外观............................................................ 2-302.4.3产品特点............................................................ 2-322.4.4产品规格............................................................ 2-342.4.5组网应用............................................................ 2-372.4.6订购信息............................................................ 2-38 2.5S3700系列企业网交换机.............................................. 2-402.5.1产品概述............................................................ 2-402.5.2产品型号和外观...................................................... 2-402.5.3产品特点............................................................ 2-412.5.4产品规格............................................................ 2-442.5.5组网应用............................................................ 2-472.5.6中小型企业网络应用.................................................. 2-472.5.7产品选购............................................................ 2-48 2.6S2700系列企业网交换机.............................................. 2-502.6.1产品概述............................................................ 2-502.6.2产品型号和外观...................................................... 2-502.6.3产品特性和优势...................................................... 2-512.6.4产品规格............................................................ 2-522.6.5组网应用............................................................ 2-552.6.6订购信息............................................................ 2-55 2.7S1700系列企业网交换机.............................................. 2-572.7.2产品型号和外观...................................................... 2-572.7.3产品特性和优势...................................................... 2-572.7.4产品规格............................................................ 2-582.7.5组网应用............................................................ 2-602.7.6订购信息............................................................ 2-61 3AR G3产品.................................................................................................................. 3-13.1AR 3200系列企业路由器............................................... 3-13.1.1产品概述............................................................. 3-13.1.2关键特性及价值....................................................... 3-23.1.3产品规格............................................................. 3-43.1.4典型应用............................................................. 3-53.1.5选配方式............................................................. 3-73.2AR 2200系列企业路由器............................................... 3-93.2.1产品概述............................................................. 3-93.2.2关键特性及价值...................................................... 3-103.2.3产品规格............................................................ 3-123.2.4典型应用............................................................ 3-133.2.5选配方式............................................................ 3-163.3AR 1200系列企业路由器.............................................. 3-183.3.1产品概述............................................................ 3-183.3.2关键特性及价值...................................................... 3-193.3.3产品规格............................................................ 3-213.3.4典型应用............................................................ 3-233.3.5选配方式............................................................ 3-25 4BRAS系列产品 ........................................................................................................... 4-14.1ME60多业务控制网关.................................................. 4-14.1.1产品外观............................................................. 4-24.1.2关键特性............................................................. 4-24.1.3产品规格............................................................. 4-34.1.4定购信息............................................................. 4-5 5网管产品 ....................................................................................................................... 5-15.1U2000网络管理系统................................................... 5-15.1.1产品简介............................................................. 5-15.1.2关键特性............................................................. 5-15.2华为企业网管eSight .................................................. 5-35.2.1产品简介............................................................. 5-35.2.2产品特点............................................................. 5-35.2.4产品配置............................................................. 5-61 NE路由器系列产品1.1 NE 5000E集群路由器1.1.1NE 5000E集群路由器1.1.2简介NE 5000E集群路由器(以下简称NE5000E)是华为公司面向互联网骨干节点、城域网核心节点、数据互联中心节点以及Internet承载节点推出的超级核心路由器产品。
Huawei AR100,AR120 and AR200 SeriesEnterprise Routers DatasheetRealize Your PotentialHuawei AR100, AR120 and AR200 Series Enterprise Routers DatasheetHuawei's next-generation routers, the AR100, AR120 and AR200 series are designed for enterprisebranch offices and small businesses, delivering a comprehensive set of services, including routing,switching, voice, security, and wireless access.Product OverviewThe AR100, AR120 and AR200 series are fixed interface routers that provide a comprehensive platform fora variety of network topologies, including IMS, NGN, WAN and PSTN. The AR100, AR120 and AR200 alsoemploy embedded hardware encryption for security as well as a voice Digital Signal Processor (DSP) for voiceservices.The AR100, AR120 and AR200 series are mature, stable and quiet routers that offer high performancefunctionality for small networks, enabling small businesses to greatly increase productivity at a lower cost.AR100s, AR120s and AR200s are easy to deploy, configure and customize, greatly reducing cost ofdeployment and maintenance, while offering maximum value to customers. These models allow networkadministrators to expand their networks easily and quickly, saving time and costs. The routers supportfirewalls, call processing, and application program functionalities. The AR100, AR120 and AR200 seriesincludes the following models:• AR109, AR109W, AR109GW-L• A R129CVW, AR129CGVW-L, AR121,AR129CV• AR201,AR207The specifications for these models are shown in the following table.Product Features and Benefits• More applications: Huawei series routers use the dual-core processor that isolates the control plane from the forwarding plane and processes more enterprise applications. Huawei series routers improve user experience for multimedia service when streams overlap.• Higher performance: The AR100s, AR120s and AR200s can process various enterprise applications, and its service processing capability is four times that in the industry.• Greater potential: Huawei series routers provide the capability to migrate services to the 3G and LTE networks.Small Size and High Performance1• Maturity and Stableness: The AR100s, AR120s and AR200s uses the Huawei VRP operating system and VSP voice platform. In addition, the AR100s, AR120s and AR200s uses modularized hardware design, which brings good user experience.• L ow-noise office: Huawei series routers have no fan, which brings low noise and good user experience. • Secure environment: The lightning failure rate AR100s, AR120s and AR200s is only 3% of industry average. The AR100s, AR120s and AR200s can be applied in the harsh environment.Small footprint on a Comprehensive Platform3• Easy to construct: The AR100s, AR120s and AR200s supports plug-and-play, intelligent configuration, and deployment using the USB flash drive. It can function immediately after being installed. Users do not need to configure an IP address manually. The PPP and VPN indicators show the status of corresponding services. The AR100s, AR120s and AR200s helps to quickly construct an enterprise IT network.• Simplified solution: Huawei provides an all-around solution that integrates the routing, switching, voice, security, and wireless services. Customers can customize solutions as required.• Easy to expand: Huawei series routers have four/eight FE/GE ports, can access more employee for small enterprises. The two uplink WAN ports implement load balancing and link protection, maximizing the return on investments.Low Investment with High Returns2Example deployment in branch networks for WAN access. In this example, the AR100s, AR120s and AR200s function as the egress routers on enterprise branch networks and provide multiple access methods, including Ethernet, xDSL, 3G, LTE and WLAN.WAN AccessSample DeploymentsEnterprise Voice Services DeploymentIP PBX with WAN and PSTN AccessThis illustration shows AR120 series router deployed at an enterprise branch with access to a WAN and a PSTN. If a fault occurs on the WAN, the PSTN acts as a backup to the WAN and ensures that call services remain uninterrupted.AR120s are deployed at enterprise branch offices to provide intelligent, integrated dialing across the network. When deployed as voice service gateways, AR120s can function as IP PBX boxes and SIP access gateways.IP PBX.AR120s have a built-in PBX, which supports the enterprise main number, interactive voice response (IVR), and billing query functions. These features help enhance the corporate image of small businesses by allowing them to look more professional to their customers, while simultaneously improving the efficiency of their enterprise communications.SIP Server. AR120s have a built-in SIP server that ensures reliability of voice services. If the SIP server at the headquarters office becomes unreachable, the local built-in SIP server at the branch office ensures that communication remains uninterrupted between branch offices and the PSTN network.Mid-scale branchThe AR120 series routers provide integrated voice, fax, and IP services. The AR120s can function as SIP access gateways for enterprise branch offices that transform traditional phone signals into Voice over IP (VoIP). Typically, AR120s are connected upstream from the IMS and NGN networks to enable anytime voice communication on any media, such as phones, handsets, and computers.VPNs Connecting Branches and Partners to HeadquartersVPN Deployment for Secure Enterprise CommunicationsThis illustration shows how to deploy AR100s, AR120s and AR200s using VPNs to connect branches and partners to headquarters.AR100s, AR120s and AR200s provide various VPN tunnel protocols to ensure secure communications between:• Enterprise branches andother branch offices • Enterprise branchesand headquarters • Partners and enterpriseresourcesAR100s, AR120s and AR200s support the following VPN tunnel protocols:• GRE VPN • I PSEC VPN• DSVPN • L2TP VPNAR100s, AR120s and AR200s support fast tunnel set-up and authentication.IPSEC VPN DSVPNGRE VPNAR3200VPN ClientL2TP VPN3G/LTE and Wi-Fi Wireless Access applicationWireless Access and Management in BranchThe AR100s, AR120s routers complied with 3G and LTE standards including HSPA+ and FDD LTE, meeting or LTE data link can be used as a backup for wired link to protect the xDSL, FE/GE, uplinks. The backup link improves network stability and reduces network construction costs. Some models of AR100s, AR120s routers are dual SIM devices, providing dual SIM standby. Thecustomers can switch the SIMcard manually according to 3G/LTE network standards. In addition, the device can switch to the backup SIM card when signal is weak to avoid link interruption.The AR100s, AR120s routers integrated WLAN wireless access capabilities, support 802.11a/b/g/nstandard communication, Built-in AC function make the deployment and management more conveniently. Its wireless features can meet users' demand for wireless access, and help enterprises to build a branch network flexibly.AR3200HeadquartersBranch 1Branch 2Wireless AC ManagementapplicationThe AR120s and AR200s routers integrated AC (Access Controller, a wireless controller) functionality, which can manage the wireless AP (Access Point, Access Point) in wireless LAN. AR supported rich certification and flexible user access control, which can provide security access guarantee for Wi-Fi users. The rich wireless capabilities integrated in one device, this can realize centralized management of wired and wireless network,meet the customers' requirements of building different scale enterprises networks.Branch 1Branch 2Technical SpecificationsTable1: AR100s Technical SpecificationsTable 2: AR120s Technical SpecificationsTable 3: AR200 Technical SpecificationsHardware*Service performance depending on specific feature configuration. Ordering InformationThe AR100, AR120 and AR200 series routers are configured by selecting and installing the appropriate configuration module. The configuration module ordering information and descriptions are shown in the following table4-7.Table 4: Chassis OptionsTable 5: Power Module OptionsTable 7: SD Card and USB Disk OptionsTable 6: License OptionsProfessional Service and SupportHuawei Professional Services provides expert network design and service optimization tasks, helping customers design and deploy a high-performance network that is reliable and secure, maximizing return on investment as well as reducing operational expenses.Company AddendumFor more information, please visit /en/ or contact your local Huawei office.Copyright © Huawei Technologies Co., Ltd. 2017. All rights reserved.No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.Trademark Notice, HUAWEI, and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.Other trademarks, product, service and company names mentioned are the property of their respective owners.General DisclaimerThe information in this document may contain predictive statements including,without limitation, statements regarding the future financial and operating results,future product portfolio, new technology, etc. There are a number of factors thatcould cause actual results and developments to differ materially from thoseexpressed or implied in the predictive statements. Therefore, such information isprovided for reference purpose only and constitutes neither an offer nor anacceptance. Huawei may change the information at any time without notice.。
H3C SecPath F1800-A 防火墙操作手册杭州华为三康技术有限公司资料版本:T1-081658-20061015-C-1.01产品版本:VRP3.30声明Copyright © 2006 杭州华为三康技术有限公司及其许可者版权所有,保留一切权利。
非经本公司书面许可,任何单位和个人不得擅自摘抄、复制本书内容的部分或全部,并不得以任何形式传播。
H3C、Aolynk、、IRF、H3Care、、Neocean、、TOP G、SecEngine、SecPath、COMWARE、VVG、V2G、V n G、PSPT、NetPilot、XGbus均为杭州华为三康技术有限公司的商标。
对于本手册中出现的其它公司的商标、产品标识及商品名称,由各自权利人拥有。
除非另有约定,本手册仅作为使用指导,本手册中的所有陈述、信息和建议不构成任何明示或暗示的担保。
如需要获取最新手册,请登录。
技术支持用户支持邮箱:customer_service@技术支持热线电话:800-810-0504网址:前言相关手册手册名称用途《H3C SecPath F1800-A 防火墙安装手册》介绍了SecPath F1800-A 防火墙的安装过程、设备的启动、硬件维护与监控等内容。
《H3C SecPath F1800-A 防火墙操作手册》对用户使用SecPath F1800-A 防火墙进行操作指导。
包括入门、系统管理、接口、链路层协议、网络与路由协议、安全防范、VPN、可靠性等网络互连的操作指导。
《H3C SecPath F1800-A 防火墙命令手册》详细解释SecPath F1800-A 防火墙中的操作命令。
包括入门、系统管理、接口、链路层协议、网络与路由协议、安全防范、VPN、可靠性等网络互连的所有命令。
本书简介本手册各章节内容如下:z第1部分入门。
从防火墙发展和安全概念入手,顺次介绍SecPath F1800-A 防火墙提供的安全特性、防火墙配置环境搭建、防火墙管理,最后介绍SecPath防火墙的工作模式。
华为路由TC7102快速入门认识路由器WAN/LAN 自适应接口:连接天翼网关、电脑等发现可配对的 HUAWEI HiLink 智能设备,路由器指示灯自动变为慢闪。
此时点按一下路由器的 H 键后,指示灯闪烁加快,可配对设备将连接路由器的Wi-Fi。
连上后,路由器指示灯停止闪烁。
请参考本手册,配置路由器。
请确保网线无松动和连接无错误。
请致电中国电信,确认网络是否存在故障。
红色常亮绿色常亮可以上网闪烁HiLink 模式下,路由器已检测到可配对的设备:无法上网:指示灯若您误碰 H 键导致指示灯闪烁,请等待2分钟,指示灯会自动恢复。
路由器的 H 键同时具有 WPS 按键功能。
连线路由器四根天线均竖直向上,Wi-Fi 信号更优。
设置上网路由器的指示灯绿色常亮表示可以上网。
路由器的 Wi-Fi 名称和密码自动与天翼网关相同。
无需配置,即插即用。
若不确定您的天翼网关是否支持 e-Link 智能组网,请联系中国电信(服务热线:10000)。
情景一:您的天翼网关支持 e-Link 智能组网123手机连接路由器 Wi-Fi ,Wi-Fi 名称和密码请查看路由器底部。
输入宽带账号和密码。
若您只有一根网线,可以先用这根网线连接旧路由器获取网络配置,获取成功后,再用这根网线连接新路由器的任意网口和上行网络(如:天翼网关)。
您也可以用网线将电脑连接到路由器,使用电脑设置上网。
界面请以实际产品为准。
打开浏览器,页面自动跳转(若未跳转,请输入“192.168.2.1”),输入登录密码,登录密码请查看路由器底部。
若您记得宽带帐号和密码,请直接输入。
若您忘记了宽带帐号和密码,请选择从旧路由器获取:另取一根网线连接旧路由 WAN 口和新路由器的任意网口。
输入或联系中国电信,获取宽带帐号和密码。
连接好路由器的电源线和网线后,请参照以下步骤设置上网。
情景二:您的天翼网关不支持 e-Link 智能组网设置路由器的新 Wi-Fi 和管理密码。
(整理)华为产品规格路由器.路由器:规格名称AR2201-48FE/AR2202-48FE AR2204AR2220AR2220LAR2240硬件规格描述转发性能350Kpps450Kpps2.5Mpps600Kpps 5Mpps~20Mpps带业务转发性能(IMIX)200Mbps 200Mbps 400 Mbps 200Mbps 600Mbps~4.5Gbps防⽕墙性能 (1500字节)900Mbps 900Mbps 1.9 Gbps 950Mbps 5.5Gbps~15Gbps整机交换容量- 10Gbps 32 Gbps 14Gbps 80Gbps固定以太⽹路由端⼝2*GE(1*Combo),2*FE (由以太⽹交换端⼝提供)3*GE(1*Combo)3*GE(1*Combo)3*GE(1*Combo)3 * GE(2 * Combo)/4 * GE Combo+ 2* 10GESIC插槽0 4 4 4 4WSIC插槽(缺省/最⼤**)0 0/2 2/4 2/4 2/4XSIC 插槽(缺省/最⼤**)0 0 0/2 0/2 2/4EXSIC插槽(与0 0 0 0 1XSIC共享插槽)DSP插槽0 2 1 2 0/3USB2.0端⼝1 2 2 2 1/2Mini-USB控制台端⼝1 1 1 1 1串⾏辅助/控制台端⼝1 1 1 1 1内存容量512MB 1GB 2 GB 1GB 2GB/8GBFlash(缺省/最⼤**)512MB 512MB/4GB2 GB/4 GB 512MB /4GB2 GB/4 GB最⼤⽀持功率60W 150W 150 W 150 W 350 W(单电源)/700 W(双电源)电源(AC)100~240 V 100~240 V 100~240 V 100~240 V 100~240 V 电源频率50/60 HZ 50/60 HZ 50/60 HZ 50/60 HZ 50/60 HZ 电源(DC)- - -48~-60 V -48~-60 V -48~-60 V外形尺⼨(H x W x D)(单位:mm)44.5 x 442 x31044.5 x 442x 42044.5 x 442 x42044.5 x 442x 42088.1 x 442 x 470重量4.8KG 6 KG(不含插卡)4.95 KG(不含电源及插卡)6 KG(不含插卡)8.85 KG(不含电源及插卡)环境温度0~45°C0~45°C0~45°C0~45°C0~45°C环境相对5-95% (不结5-95% 不5-95% (不结5-95% (不5-95% (不结露)规格名称AR2201-48FE-S AR2204-S AR2220-S AR2240-S 硬件规格描述转发性能(64字节)350Kpps 450Kpps 2.5 Mpps 5 Mpps带业务转发性能(IMIX)200Mbps 200Mbps 400 Mbps 600 Mbps 防⽕墙性能(1500字节)900Mbps 900Mbps 1.9 Gbps 5.5 Gbps 带机量250-300台PC250-300台PC300-400台PC 400-600 台PC整机交换容量- 10Gbps 32 Gbps 80 Gbps固定以太⽹路由端⼝2*GE (1*Combo),2*FE (由以太⽹交换端⼝提供)3*GE(1*Combo)3*GE(1*Combo)3*GE(2*Combo)SIC插槽0 4 4 4WSIC插槽(缺省/最⼤)0 0/2 2/4 2/4XSIC 插槽(缺省/最⼤)0 0 0/2 2/4EXSIC插槽(与XSIC0 0 0 1共享插槽)DSP插槽0 2 1 3USB2.0端⼝1 2 2 2Mini-USB控制台端⼝1 1 1 1串⾏辅助/控制台端⼝1 1 1 1内存容量512MB 1GB 2 GB 2 GB Flash 512MB 512MB 16 MB 16 MB Micro SD - -/4GB 2 GB/4 GB 2 GB/4 GB (缺省/最⼤)最⼤⽀持功率60W 150W 150 W 350 W(单电源)/700 W(双电源)电源(AC)100~240 V 100~240 V 100~240 V 100~240 V 电源频率50/60 HZ 50/60 HZ 50/60 HZ 50/60 HZ 电源(DC)- - -48~-60 V -48~-60 V外形尺⼨(H x W x D)44.5 x 442 x 44.5 x 442 x42044.5 x 442 x 420 88.1 x 442 x 470(单位:mm)310重量4.8KG 6 KG(不含插卡)4.95 KG(不含电源及插卡)8.85 KG(不含电源及插卡)环境温度0~40°C0~40°C0~40°C0~40°C环境相对湿度5-90% (不结露)5-90% (不结露)5-90% (不结露)5-90% (不结露)软件规格描述AR3200系列企业路由器的主要规格描述如下表:能(IMIX)防⽕墙性能5.5 Gbps~20 Gbps(1500字节)整机交换容量160GbpsSIC插槽 2 Gbps;WSIC插槽 5 Gbps;XSIC和EXSIC插槽 20 Gbps 每槽位交换容量3 * GE(2 * Combo) /4*GE Combo+ 2*10GE固定以太⽹路由端⼝SIC插槽 4WSIC插槽(缺2/4省/最⼤**)4/6XSIC插槽(缺省/最⼤**)EXSIC插槽 1DSP插槽0/3USB2.0端⼝ 2Mini-USB控制1台端⼝1串⾏辅助/控制台端⼝内存容量 2 GB/8 GB2 GB/4 GBFlash(缺省/最⼤**)最⼤⽀持功率350 W(单电源)/700 W(双电源)电源(AC)100~240 V电源频率50/60 HZ电源(DC)-48~-60 V外形尺⼨(W x Dx H)(单位:mm)442 x 470 x 130.5重量11 KG(不含电源及插卡)环境温度0~45°C环境相对湿度5-95% (不结露)软件规格描述基础功能DHCP server/client/relay,PPPoE server/client,PPPoA server/client,PPPoEoAserver/client,NAT,⼦接⼝管理语⾳功能RTP协议,SIP 协议,SIP AG,IP PBX/TDM PBX,FXO/FXS,VoIP/电话会议, BEST,DISA,SBC, H.323⽹守⽆线局域⽹(AC) AP设备管理(AC发现/AP接⼊/AP管理),CAPWAP协议, WLAN ⽤户管理,WLAN射频管理(802.11a/b/g/n),WLAN QoS(WMM),WLAN 安全(WEP/WPA/WPA2/密钥管理)3G功能CDMA 2000 EV-DO Rev A制式,WCDMA制式,3G链路独⽴上⾏/作为备份链路LTE功能⽀持制式速率:FDD LTE:上⾏ 50Mbit/s 下⾏ 100Mbit/s局域⽹功能IEEE 802.1P,IEEE 802.1Q,IEEE 802.3 ,VLAN管理,MAC管理,MSTP等IPv4单播路由路由策略,静态路由,RIP,OSPF,IS-IS,BGPIPv6基本功能IPv6 ND,IPv6 PMTU,IPv6 FIB,IPv6 ACLIPv6隧道技术⼿⼯隧道,⾃动隧道,GRE隧道,6to4,ISATAPIPv6单播路由路由策略,静态路由,RIPng,OSPFv3,IS-ISv6,BGP4+组播功能IGMP V1/V2/V3,IGMP-Snooping V1/V2/V3,PIM SM,PIM DM,MSDPMPLS LDP,MPLS L3 VPN,静态LSP,动态LSP,MPLS TE,IP FRR,LDP FRR,TE FRR VPN IPSec VPN,GRE VPN,DSVPN,SSL VPN,L2TP VPNQoS Diffserv模式,MPLS QoS,优先级映射,流量监管(CAR),流量整形,拥塞避免(基于IP优先级/DSCP WRED),拥塞管理(LAN接⼝:SP/WRR/SP+WRR;WAN 接⼝:PQ/CBWFQ),MQC(流分类,流⾏为,流策略),端⼝三级调度和三级整形⼯业级路由器:规格名称AR531-2C-H AR531-F2C-H 硬件规格描述带业务转发性能(IMIX)150 Mbps 150 Mbps固定以太⽹端⼝2*GE(SFP) + 6*FE + 2*FE combo 2*GE(SFP) + 6*FE(SFP)+ 2*FEcomboRS485接⼝2路2路DI接⼝2路2路USB2.0端⼝ 1 1串⾏辅助/控制台端⼝1 1内存容量512MB 512MB Flash容量512MB 512MB 最⼤⽀持功率44.5W 44.5W电源AC:100V~240V(单相),173V~415V(三相)AC:100V~240V(单相),173V~415V(三相)电源频率50/60Hz 50/60Hz 重量5Kg 5Kg外形尺⼨(HxWxD)88mm*220mm*250mm 88mm*220mm*250mm安装⽅式壁挂,DIN导轨壁挂,DIN导轨环境相对湿度5-95%(不结露)5-95%(不结露)防护等级IP51 IP51软件规格描述最⼤连接电表数1124(其中单相电表1024,三相电表100)⼯业通信协议符合IEC62056基本特征⽀持DHCP server/client/relay,PPPoE server/client,NAT,⼦接⼝管理LAN IEEE 802.1P,IEEE 802.1Q,IEEE 802.3,VLAN 管理,MAC地址管理等环⽹协议SEP、STP、RSTP 、MSTPIPv4 单播路由路由策略,静态路由,RIP,OSPF,IS-IS,BGPIPv6单播路由路由策略,静态路由,RIPng,OSPFv3,IS-ISv6,BGP4+组播IGMP版本1/2/3,PIM SM,PIM DM,MSDPVPN IPSec VPN,GRE VPN,DSVPN,SSL VPN,L2TP VPN服务质量(QoS) 区分服务模式,优先级映射,流量监管(CAR),流量整形,拥塞避免(基于IP 优先级/DSCP WRED),拥塞管理(LAN 接⼝:SP/WRR/SP+WRR;WAN 接⼝:PQ/CBWFQ),MQC (流分类,流量⾏为,流量策略),H-QoS,智能应⽤控制(SAC)安全访问控制列表(ACL),防⽕墙,802.1x 认证,AAA 认证,RADIUS认证,HWTACACS 认证,⼴播风暴抑制,ARP 安全,ICMP防攻击,URPF,CPCAR,⿊名单,PKI管理和维护升级管理,设备管理,基于Web的GUI,GTL,SNMP(v1/v2c/v3),RMON,NTP,CWMP,⾃动配置,基于U盘的开局,⽹络配置,CLINE⾼档路由器:产品规格属性NE5000E交换容量CLOS⽆阻塞交换结构,⽀持最⼤64个机框集群系统最⼤可达50.32Tbps – 3220Tbps端⼝容量15Tbps - 960Tbps转发性能11520Mpps – 737280Mpps多框集群⽅式多框互联采⽤⽆阻塞的交换⽹接⼝,跨框流量不低于单框交换容量接⼝板槽位16槽位/单机框接⼝类型GE、10GE、155M POS、622M POS、2.5G POS、10G POS、40G POS、40GE、100GE等路由协议⽀持OSPF、IS-IS、BGP、PIM、MSDP、MBGP等路由协议IPv6 l 全⾯⽀持IPv4和IPv6双协议栈。
路由器操作手册1.认识控制(Console)线Array控制线是由一端RJ45头,一端串口头组成。
其中:RJ45头连接到路由器控制口(CON)串口头连接到电脑串口上;通常,控制线存在与路由器包装盒中;2.认识路由器(以华为1600和18-13为例)路由器后面接口说明:CON:控制口,主要用于查看及配置路由器;100BASE-T:网络接口,用于连接交换机接口;SERIAL:串口,主要用于连接广域网口,连接电信运营商提供的协议转换器;其它接口:用于系统其它功能,我公司暂时不需要;路由器面板指示灯说明:POWER:电源指示灯,接通电源后常亮;100M ETH:局域网络指示灯,连接交换机并通电后常亮;SERAIL:串口指示灯,连接协议转换器后指示灯常亮;BRI:我公司暂时不需要AUX:我公司暂时不需要SYSTEM:系统指示灯,加电后闪烁系统正常运行后常亮;3.认识电脑串口接口4.控制线连接将控制线串口头连接到电脑串口上;将控制线RJ45头连接到路由器控制口上;V.35连接线包括两个头,左面扁口控制头用于连接路由器串口。
右面方口针脚外露用于连接V.35协议转换器;将本地连接线连接好;打开超级终端出现提示,选择否,进行下一步操作出现提示,选择取消,然后进行下一步操作点击确定后进入超级终端软件选择图标选择COM1进行连接选择还原为默认值,用默认端口设置进行连接,点击确定,进行下一步操作初始用户名和密码为huawei其中密码输入不回显,只需正常输入即可成功登陆后显示命令行,路由器配置时,所有命令行结束后需要敲击回车键执行命令查看系统配置信息命令为display current配置信息分页显示,敲击空格键后,配置信息整页滚动,敲击回车键后,配置信息整行滚动敲击空格键后,下一页配置信息1.在配置页面上可以通过鼠标进行选择配置信息,然后COPY到文本文件中2.另外一种保存方法就是通过超级终端自带功能进行保存,首先选择传送菜单下捕获文字选择好文件保存路径,并命名配置文件名称,后点击启动按钮提示:配置文件名最好与使用机构名称命名,如keshan.txt等易于理解的名称命名;在这中间任何在屏幕上显示的命令及提示信息都会被记录到文件中保存文件:选择传送菜单-捕获文字-停止停止将信息记录到文件中。
华为路由器配置手册华为路由器配置手册第一章系统基本命令本章主要介绍命令行接口相关命令、配置文件管理命令、基本的系统管理命令、网络测试工具命令、系统调试命令、SNMP配置命令、日志配置命令和终端服务命令。
第二章接口配置命令本章主要介绍以太网口配置命令、串口配置命令、CE1/PRI接口配置命令和接口管理命令。
第三章广域网协议配置命令本章主要介绍PPP、SLIP、MP、LAPB、X.25、X.25交换、帧中继和ISDN协议配置命令。
第四章网络协议配置命令本章主要介绍IP地址配置命令、静态地址解析配置命令、静态域名解析配置命令、地址转换配置命令、IP性能配置命令、静态路由配置命令、OSPF路由协议配置命令、RIP路由协议配置命令、IGRP路由协议配置命令、BGP路由协议配置命令和IPX协议配置命令。
第五章安全配置命令本章主要介绍AAA配置命令、Radius协议配置命令、终端访问安全配置命令、防火墙配置命令和包过滤配置命令。
第六章拨号配置命令本章主要介绍DDR配置命令和Modem管理配置命令。
第七章备份中心配置命令本章主要介绍备份中心配置命令。
第八章VPN配置命令本章主要介绍L2TP协议配置命令。
第九章桥配置命令本章主要介绍透明桥协议配置命令。
第十章Quidway(R)系列路由器调试命令本章主要介绍调试命令的使用方法及各协议或功能的调试命令。
第一章系统基本命令1.1命令行接口相关命令与命令行接口相关的命令包括:configurecontroller e1disableenableexithelpinterfacelanguagelogic-channelroutershow historyvpdn-group1.1.1 configure用户使用configure命令从特权用户模式进入全局配置模式。
configure【命令模式】特权用户模式【举例】Quidway#configureEnter configuration commands, one per line. End with command exit! Quidway(config)#【相关命令】exit1.1.2. controller e1用户使用controller e1命令从全局配置模式进入CE1/PRI接口配置模式。
华为路由器配置说明华为路由器是一款功能强大的网络设备,可以将多个电脑或其他设备连接到互联网。
为了实现最佳的网络体验,正确的配置华为路由器是非常重要的。
本文将详细介绍华为路由器的配置方法,帮助用户顺利设置并使用路由器。
一、连接路由器首先,确保购买的华为路由器设备已经准备齐全。
将其中一个以太网口连接到宽带猫或光猫的LAN口,然后通过另一个以太网口连接到计算机,确保设备之间的连接正常。
二、登录路由器管理页面1. 打开电脑上的浏览器,输入默认的路由器管理地址(一般是192.168.1.1或者192.168.0.1)并回车。
2. 在弹出的登录页面中输入默认的用户名和密码(一般是admin/admin或者root/admin),然后点击登录按钮。
三、更改管理密码为了保护路由器的安全,首先需要修改默认的管理密码。
1. 在登录成功后的页面中,找到“系统管理”或“设置”选项。
2. 在设置页面中,找到“管理密码”或“密码设置”选项。
3. 输入当前默认密码,然后输入新密码并确认。
4. 点击保存并等待系统重启。
四、连接互联网1. 在登录路由器管理页面后,找到“网络设置”或“WAN设置”选项。
2. 在WAN设置页面中,选择您的上网方式。
如果您的上网方式是动态IP,选择“动态IP”;如果是PPPoE,选择“PPPoE”并填写您的宽带账号和密码;如果是静态IP,选择“静态IP”并填写相关信息。
3. 点击保存并等待系统重启。
五、配置无线网络1. 找到路由器管理页面中的“无线网络设置”选项。
2. 在无线网络设置页面中,启用无线功能。
3. 设置无线网络的名称(即SSID)和密码,确保密码强度较高,并且记住这个密码以供日后使用。
4. 点击保存并等待路由器重启。
六、QoS(服务质量)配置如果您有多台设备连接到华为路由器,为了确保网络稳定,可以进行QoS配置。
1. 找到路由器管理页面中的“QoS设置”选项。
2. 在QoS设置页面中,启用QoS功能。
DatasheetProduct OverviewHuawei's next-generation NetEngine AR600 series enterprise routers use multi-core processors and a non-blocking switching structure, helping to deliver three times the industry average performance. The NetEngine AR600 also integrates functions such as SD-WAN, cloud management, routing, switching, VPN, WLAN, and security, ensuring diversified and cloud-based services are fully supported.Huawei NetEngine AR600 series enterprise routers can be deployed at branches of SMBs and small-sized enterprises as required to provide enterprise network egress capabilities. The NetEngine AR600 series include two sub series, NetEngineAR650 series and NetEngine AR610 series.NetEngine AR650 series consists of models such as the NetEngine AR651C, NetEngine AR651, NetEngine AR651W, NetEngine AR657W. The NetEngine AR610 series consists of models such as the NetEngine AR611W, NetEngine AR617VW, NetEngine AR617VW-LTE4EA. Huawei provides various models which can meet networking requirements of enterprises of different scales.Front and rear views of Huawei NetEngine AR651CFront and rear views of Huawei NetEngine AR651Front and rear views of Huawei NetEngine AR651WFront and rear views of Huawei NetEngine AR657WViews of Huawei NetEngine AR611WViews of Huawei NetEngine AR617VWViews of Huawei NetEngine AR617VW-LTE4EAFeatures and BenefitsFeatures and BenefitsArchitecture HighlightsProduct Specifications NetEngine AR650 Series T echnical SpecificationsNetEngine AR610 Series T echnical SpecificationsNetEngine AR600 Series Software Features and ProtocolsNetworking and Application●SD-WAN Using Hybrid LinksIn the SD-WAN Solution, the NetEngine AR600 functions as the gateway of SMBs and small-sized enterprise branches and supports hybrid access using multiple physical links, such as Internet links, and LTE links. The solution also leverages Huawei's next-generation controller, the Agile Controller, which implements centralized and visualized management. The NetEngine AR600 provides extensive SD-WAN features and delivers optimal service experience for enterprises through intelligent application identification, intelligent traffic steering, and intelligent acceleration. For details about Huawei SD-WAN Solution, visit https:///en/solutions/business-needs/enterprise-network/sd-wan.SD-WAN networking●WAN Interconnection ScenarioIn this scenario, the NetEngine AR600 series routers are used as enterprise branch egresses and provide flexible WAN access methods to support remote network connections. A single NetEngine AR600 router can satisfy different access requirements, for example, for the private line, Ethernet, 3G, LTE, and WLAN access, helping the customer reducedeployment and maintenance costs while helping them extract much value.WAN interconnection networkingBuilding Different Types of VPNs by Leveraging Internet ResourcesThe NetEngine AR600 provides various secure access functions for communication between enterprise branches and between branches and headquarters. These functions also allow an enterprise's partners to access its resources. Secure tunnels such as GRE VPN, IPSec VPN, DSVPN, L2TP VPN, and EVPN tunnels can be set up between the headquarters and branches for secure data access and transmission. The NetEngine AR600 supports quick tunnel deployment and authentication for branches. Furthermore, partners authenticated and authorized by the AR600 can remotely access the enterprise resources over these tunnels.VPN networkingOrdering InformationThe NetEngine AR600 series routers are configured by selecting and installing the appropriate configuration module. The configuration module ordering information and descriptions are shown in the following tables.The NetEngine AR650 sub series routers require 3 types of configuration modules:●Basic software configuration●Software license configuration●Performance license configurationThe basic software configuration modules provide functions such as routing, switching, voice, and security.The software license configuration modules provide additional functions such as SRP, DSVPN.The NetEngine AR610 sub series routers don’t need to configure the license.License function and descriptionOrdering componentsMore InformationFor more information about Huawei next-generation AR enterprise routers, visit or contact us in the following ways:●Global service hotline: /en/service-hotline ●Logging in to the Huawei Enterprise technical support website: /enterprise/ ● Sending an email to the customer service mailbox: ********************Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.No part of this document may be reproduced or transmitted in any form or by any means without prior writtenconsent of Huawei Technologies Co., Ltd.Trademarks and Permissionsand other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.All other trademarks and trade names mentioned in this document are the property of their respective holders.NoticeThe purchased products, services and features are stipulated by the contract made between Huawei and thecustomer. All or part of the products, services and features described in this document may not be within thepurchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, andrecommendations in this document are provided "AS IS" without warranties, guarantees or representations ofany kind, either express or implied.The information in this document is subject to change without notice. Every effort has been made in thepreparation of this document to ensure accuracy of the contents, but all statements, information, andrecommendations in this document do not constitute a warranty of any kind, express or implied.Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China Website: 。
Quidway® R3600E系列模块化中心路由器Quidway®R3600E系列模块化中心路由器是华为3Com公司开发的面向企业级的网络产品,提供了极其丰富的软件特性,支持哑终端接入服务器和金融POS接入功能,支持SNA/DLSw、VoIP特性等,提供丰富的备份方案及QoS特性;硬件采用模块化结构,具有更高的处理能力和更大的接入密度,既适合于在中小型企业网中担当核心路由器,也可以在大型网络中担当汇聚层路由器。
Quidway®R3600E系列包含三款路由器:Quidway®R3640E、Quidway®R3680E和Quidway®R3680E RPS(冗余电源主机)。
Quidway® R3640E路由器外观图Quidway® R3680E路由器外观图产品功能特性◆互连协议:以太网、桥、帧中继、X.25、HDLC、SDLC、LAPB、SLIP、PPP、PPP头压缩、MP、ISDN、PPPoE Client、按需拨号、拨号串循环备份、PPP/ISDN回呼、L2TP建立二层隧道、GRE 建立三层隧道、宽带接入。
◆网络协议:DHCP、VLAN、IPX、DLSw、RIP-1/RIP-2、OSPF、BGP、策略路由、组播、路由负载分担、地址借用、TCP报文头压缩、路由策略。
◆网络安全:登录用户认证、RADIUS/Tacacs+认证/计费、IPSEC、IKE、硬件加密卡、防火墙支持对接口/时间段/MAC地址的过滤、高性能NAT。
◆网络可靠性:接口/子接口间的物理层备份,虚链路/虚模板/拨号接口/逻辑接口间的链路层备份,动态路由实现网络层备份、VRRP实现设备层备份。
◆语音特性:静音压缩、舒适噪音、语音防抖动、音量调节、PBX交换机功能模拟、主叫号码识别、自动忙音检测、灵活VOIP选路与备份策略、IP传真、语音RADIUS、GK Client、IPHC、语音QoS。
NetEngine40E全业务路由器N etEngine40E系列全业务路由器(以下简称NE40E)是华为公司推出的高端网络产品,主要应用在IP骨干网、IP城域网以及其他各种大型IP网络的边缘位置,与NE5000E、NE80E核心路由器产品配合组网,形成结构完整、层次清晰的IP网络解决方案。
NE40E基于分布式的硬件转发和无阻塞交换技术,具有良好的线速转发性能,优异的扩展能力,完善的QoS机制和强大的业务处理能力。
NE40E基于最新的可扩展400G平台,实现40G/Slot到400G/Slot的平滑扩展,且兼容现网所有线卡,最大限度保护客户的投资。
NE40E具有强大的汇聚接入能力,凭借丰富的特性支持,可以灵活部署L2VPN,L3VPN,组播,组播VPN,MPLS TE,QoS等,实现业务运营级的可靠性承载;同时,NE40E全面支持IPv6,可以实现IPv4到IPv6的平滑过渡。
因此,NE40E可以灵活应用在IP/MPLS网络的边缘、核心,可以简化网络结构,提供丰富的业务类型和可靠的服务质量,是IP/MPLS 承载网向宽带化、安全化、业务化、智能化发展的重要源动力。
NE40E系列主要包括NE40E-X16、NE40E-X8、NE40E-X3和NE40E-8,适应不同规模的网络组网需求。
NE40E-X16 NE40E-X8 NE40E-X3 NE40E-8产品特点♦领先的400G平台NE40E系列节能减排机框基于400G平台,具备每槽位400Gbps转发能力,可以从每槽位40Gbps平滑扩容到400Gbps带宽,满足未来3~5年的带宽增长需求。
同时NE40E系列基于现有VRP软件平台,完全兼容现网所有线卡,充分利旧,最大限度保护客户的投资。
整机采用高端口密度、紧凑性设计,单机端口密度最大可达64×10G,单机柜容量最大可达132×10G,可以有效的节省空间。
♦绿色的设计理念节能减排整机采用完全绿色的设计,更加环保节能。
12345二. 连线三. 设置上网下图为华为路由器常见的几种形态,仅供参考,请匹配您购买的实 际机型进行连线。
本资料仅供参考,不构成任何形式的承诺。
快速指南手机连接路由器 Wi-Fi,Wi-Fi 名称请查看路由器底部铭牌,无密码。
下载智慧生活 App连接电源,网线接入路由器任意一个网口。
打开智慧生活 App,界面将自动弹出提示框,请按提示操作。
若未出现提示框,请点击界面中的“+”添加设备。
23根据界面向导完成配置。
路由器指示灯绿色常亮(部分型号为蓝色常亮)表示配网成功。
图示仅供参考,具体界面请以实际产品为准。
若您记得宽带帐号和密码:请直接输入。
情景一:自动获取 IP(您的网络配置无需输入宽带帐号和密码)。
情景二:宽带帐号上网(您的网络配置需要输入宽带帐号和密码)。
若您忘记了宽带帐号和密码:另取一根网线连接旧路由 WAN/LAN 自适应网 口 或 WAN 口和新路由WAN/LAN 自适应网 口 或 LAN 口,选择从旧路由获取。
联系宽带运营商获取宽带帐号和密码。
以外置天线路由器为例:光猫墙上网口常见问题2. 如何将路由器恢复出厂设置?将路由器接通电源,稍等片刻(待路由器完成启动),使用针状物按下路由器的 RESET 复位孔,并保持 2 秒以上(部分型号请按下路由器的 RESET 键,并保持8 秒以上),指示灯熄灭后松开。
等待路由器重启亮红灯后,即已完成恢复出厂设置。
答:恢复出厂设置后,需要重新对路由器进行配置。
请确保智慧生活 App 版本为最新。
请确保路由器已连接电源,稍等片刻(待路由器完成启动)后重新扫描。
请确保手机连接上路由器的 Wi- Fi。
请确保路由器为全新或已恢复出厂状态。
建议配置路由器的手机与路由器之间不超过两堵墙。
1. 智慧生活 App 无法识别到路由器,怎么办?答:答:3. 如何与其他华为路由器级联组网?网线直连:使用网线将路由器的 WAN/LAN 自适应网口或 LAN 口连接其他华为路由器(全新或已恢复出厂设置)的 WAN/LAN 自适应网口或 WAN 口,无需其他操作,即可完成组网。
扫描二维码,关注“华为路由器
打开公众号,选择“配置视频”,观看该产品的相关视频,如首次配置、多台路由器扩展 Wi-Fi、与旧路由器级联上网等视频。
用户姓名:通讯地址:
购机日期:
售机单位名称(加盖公章)售机单位地址:产品型号:
用户姓名:通讯地址:
购机日期:
售机单位名称(加盖公章)售机单位地址:
产品型号:
华为终端客户服务官方微信路由器花粉论坛
玩机技巧
售后服务更多信息请访问 /cn 消费者服务热线: 购买华为终端产品请访问 华为商城:
华为商城客户端产品资讯。
