石化产品流程图(英文版)

一：配管工程常用英语缩写1 管子及管件编号缩写中文名称英文名称P 管子PipeEL 弯头ElbowELL 长半径弯头Long radius elbowELS 短半径弯头Short radius elbowMEL 斜接弯头（虾米腰弯头）Mitre elbow REL 异径弯头Reducing elbowT 三通TeeLT 斜三通Lateral teeRT 异径三通Reducing teeR 异径管接头（大小头）ReducerCR 同心异径管接头（同心大小头）Concentric reducerER 偏心异径管接头（偏心大小头）Eccentric reducerCPL 管箍CouplingFCPL 双头管箍Full couplingHCPL 单头管箍Half couplingRCPL 异径管箍Reducing couplingBU 内外螺纹接头BushingUN 活接头UnionHC 软管接头Hose couplerSE 翻边短节Stub endNIP 短节Pipe nipple or straight nipple SNIP 异径短节Swaged nippleCP 管帽（封头）CapPL 管堵（丝堵）PlugBLK 盲板BlankSB 8字盲板Spectacle blind (blank)RP 补强板Reinforcing pad2 法兰编号缩写中文名称英文名称PLG 法兰FlangeWNF 对焊法兰Welding neck flangeSOF 平焊法兰Slip-on flangeSWF 承插焊法Socket-welding flangeT 螺纹法兰Threaded flangeLJ 松套法兰Lapped joint flangeREDF 异径法兰Reducing flangeBF 法兰盖（日法兰）Blind flangeFSF 法兰密封面Flange scaling faceFF 全平面Flat faceRF 凸台面Raised faceMFF 凹凸面Male and female faceLF 凹面Female faceLM 凸面Male faceRJ 环连接面Ring joint face TG 榫槽面Tongue and groove faceTF 榫面Tongue faceGF 槽面Groove face3 垫片编号缩写中文名称英文名称G 垫片GasketNMG 非金属垫片Non-metallic gasketAG 石棉垫片Asbestos gasketRG 橡胶垫片Rubber gasketTEG 聚四氟乙烯包复垫片PTFE envelope gasketSMG 半金属垫片Semimetallic gasketMJG 金属包垫片Meta-jacket gasketSWG 缠绕式垫片Spiral wound gasketMG 金属垫片Metallic gasketFMG 金属平垫片Flat metallic gasket SMSG 齿形金属垫片Solid metal serrated gasketLER 透镜式金属环垫Lens ring gasketOCR 八角形金属Octagonal ring gasket OVR 椭圆形金属环垫Oval ring gaksetIR/OR 内外定位环Inner ring and outer ring IR 内定位环Inner ringOR 外定位环Outer ring4 坚固件编号缩写中文名称英文名称螺栓BoltSB 螺柱Stud boltNU 螺母NutTB 花蓝螺母TurnbuckleWSR 垫圈WasherSWSR 弹簧垫圈Spring washer5 阀门编号缩写中文名称英文名称GV 闸阀Gate valveGLV 截止阀Globe valveCHV 止回阀Check valveBUV 蝶阀Butterfly valveBAV 球阀Ball valvePV 旋塞阀Plug valve (cock)CV 调节阀Control valveSV 安全阀Safety valveRV 减压阀Pressure reducing valveST 蒸汽疏水阀Steam trapPRV 泄压阀Pressur relief valveBV 呼吸阀Breather valveNV 针形阀Needle valveAV 角阀DV 隔膜阀TWV 三通阀SGV 插板阀6 管道上用的小型设备编号缩写中文名称英文名称SPR 气液分离器SeparatorFA 阻火器Flame arresterSR 过滤器StrainerSRY Y型过滤器Y-type strainerSRT T型过滤器T-type strainerSRB 桶式过滤器Bucket type strainerTSR 临时过滤器Temporary strainerSIL 消声器SilencerSG 视镜Slight glassSC 取样冷却器Sample coolerDF 排液漏斗Drain funnelLM 管道混合器Line mixerRO 限流孔板Restriction orificeMO 混合孔板Mixing orificeRD 爆破片（爆破膜）Rupture diskEJ 补偿器Expansion joint7 隔热、伴热编号缩写中文名称英文名称INS 隔热Thermal insulationH 保温Hot insulationC 保冷Cold insulationP 防烫伤隔热Personnel protection insulation T&I 伴热Tracing and insulationT 管道伴热（冷）TracingEST 蒸汽外伴热External steam tracingIST 蒸汽内伴热Internal steam tracingSJT 蒸汽夹套伴热Steam-jacket tracingET 电伴热Electric tracing8 配管材料和等级编号缩写中文名称英文名称M 金属材料Metallic materialCS 碳钢Carbon steelCAS 铸钢Cast steelFS 锻钢Forged steelAS 合金钢Alloy steelSS 不锈钢Stainless steelAUSTSS 奥氏体不锈钢Austenitic stainless-steelCI 铸铁Cast ironMI 可锻铸铁Malleable ironDI 球墨铸铁Ductile ironAL 铝Aluminum BRS 黄铜BrassBRZ 青铜BronzeCU 紫铜CopperLAS 低合金钢Low alloy steelFLAS 低合金锻钢Forged low alloy steel CLAS 低合金铸钢Cast low alloy steel壁厚ThicknessSCH 表号Schedule numberSTD 标准StandardXS 加强Extra strongXXS 特强Double extra strong9 装置布置编号缩写中文名称英文名称CN 建北Construction northE 东EastW 西WestS 南SouthN 北NorthH 水平HorizontalV 竖直、铅直、直立VerticalGRD 地坪GroundUG 地下UndergroundBL 装置边界线Battery limit lineESEW 事故沐浴洗眼器Emergency shower and eye washerHS 软管站Hose stationML 接续分界线Match linePS 管道支架（管架）Piping supportPR 管桥Pipe rackSTRU 构架（构筑物）StructureBLDG 建筑物BuildingPD 清扫设施Purge devicePT 池PitSHLT 棚ShelterCOFF 围堰CofferdamFL 楼板FloorPF 平台Plateform10 尺寸标注编号缩写中文名称英文名称EL 标高ElevationBOP 管底Bottom of pipeCOP 管中心Center of pipeTOP 管顶Top of pipeFOB 底平Flat on bottomFOT 顶平Flat on topCL(屯) 中心线Center lineTL 切线T angent lineSYM 对称的SymmetricalBOS 支架底Bottom of supportTOS 支架顶Top of supportCL 净距（净空）ClearanceCTC 中心至中心Center to centerCTF 中心至面Center to faceCTE 中心至端部Center to endETE 端到端End to endFEF 法兰端面Flange and faceFTF 面到面Face to faceD 直径DiameterDN 公称直径Nominal diameterID 内径Inside diameterOD 外径Outside diameterDIM 尺寸DimensionMAX 最大MaximumMIN 最小MinimumAVG 平均AverageAPP 约、近似ApproximatePT.EL 点标高Point elevation11 图表编号缩写中文名称英文名称PFD 工艺流程图Process flow diagramPID 管道和仪表流程图Piping & instrument diagramCOD 接续图Continued on drawingDTL 详图DatailSPDWG(ISODWG) 管段图Spool drawing (each line isometric drawing)DWGNO 图号Drawing numberDWGI 所在图号Drawing identification LOW 材料表List of materialMTO 汇料Material take-offAPPX 附录AppendixJOB. No. 工号Job NumberBEDD 基础工程设计数据Basic engineering design dataDEDD 详细工程设计数据Detail engineering design dataREV. No. 修改号Recision numberREFDWG 参考图Reference drawingSC 采样接口Sample connection12 操作方式及工作参数编号缩写中文名称英文名称AUT 自动AutomaticML 手动Manual controlCHOP 链条操作Chain operatedCSC 铅封关Car seal closeCSO 铅封开Car seal openLC 锁闭Lock closed LO 锁开Lock openNC 正常关Normally closeNO 正常开Normally openATM 大气压AtmospherePN 公称压力Nominal pressureA 绝压G 表压(T) 温度Temperature(P) 压力Pressure13 施工编号缩写中文名称英文名称W 焊接WeldingAW 电弧焊Arc weldingGSAW 气体保护电弧焊Gas shielded-acr weldingEFW 电熔焊Elecric fusion weldingERW 电阻焊Electric Resistance weldingGW 气焊Gas weldingLW 搭接焊Lap weldingBW 对焊Butt weldingTW 定位焊Tack weldingSW 承插焊Socket weldingCW 连续焊Continuous weldingSEW 密封焊Seal weldingSFG 堆焊SurfacingFW 现场焊接Field weldingHT 热处理Heat treatmentPH 预热PreheatingSR 应力消除Stress reliefPWHT 焊后热处理Post weld heat treatment EIT 检查、探伤和实验Examination, inspection & testingVE 外观检查Visual examinationUI (UT) 超声探伤Ultrasonic inspection (test) RI (RT) 射线探伤Radiographic inspection (test)MPI (MT) 磁粉探伤Magnetic particle inspection (test)LPI (PT) 液体渗透检验Liquid penterant inspection (test)HADT 硬度实验Hardness testingHYDT 水压实验Hydraulic testingPNET 气压实验Pneumatic testingCE 焊条Covered electrodeWW 焊丝Welding wireASSY 装配、组合AssemblyF 现场FieldF/F 现场制造Field faricatedSF 现场决定Suit in fieldCSP 冷紧Cold springBCT 螺栓冷紧Bolt cold tighteningBHY 螺栓热紧Bolt hot tightening CO 清洗口Clean outANNY 退火AnnealedPE 平端面Plain endBE 坡口端Belelled endTHR 螺纹ThreadHB 布氏硬度Brinnel hardnessRC 洛氏硬度14 其他编号缩写中文名称英文名称14.1 FDN 基础FoundationINF 信息（资料）Information REF 参考ReferenceREV 修改Revision SEQ 序号（顺序）SequenceW/E 设备带来With equipmentW/I 仪表带来With instrument CM 色标Colour markCA 腐蚀裕度Corrosion allowance UTL 公用系统UtilityUC 公用工程接头Utility connection QTY 数量QuantityWT 重量WeightMHR 工时Man hourBC 螺栓分布圆Bolt circleHP 高点High pointLP 低点Low pointSUC 吸入（口）SuctionDIS 排出（口）DischargeSO 蒸气吹扫（口）Steam outNPT 美国标准锥管螺纹National standard taper pipe threadNPS 美国标准直管螺纹National standard straight pipe threadDR 排液DrainVT 放气VentRTG （压力）等级RatingCL 等级ClassSMLS 无缝Seamless14.28 螺旋缝石油化工工程英语常用缩写序号缩写英文中文1 AC Air Conditioning 空气调节装置2 AGO Atmospheric gas oil 常压瓦斯油3 AML Approved Manufacturers' List 批准的厂商名单4 APE Area Project Engineer 区域项目工程师5 AR Atmospheric residue 常压渣油6 ARDS Atmospheric residue desulfurization 常压渣油加氢脱硫7 ASME American Society of Mechanical Engineers 美国机械工程师协会8 BD Business Director 商务主任9 BD Business Development 市场部10 BEDP Basic Design Engineering Package 基础设计包11 BFW Boiler feed water 锅炉给水12 BL Battery limits 界区13 BEDD Basic Engineering Design Data 基础工程设计数据14 BM Bill of Material 材料表15 BOD Basis of Design 设计基础16 BOD Biological Oxygen Demand 化学需氧量17 BP Boiling point 沸点18 BS Bright stock 光亮油19 BSI British Standards Institute 英国标准协会20 BTEX Benzene, toluene, ethyl benzene, xylene 苯,甲苯,乙苯,二甲苯21 BTU British thermal unit 英热单位22 BTX Benzene, toluene, xylene 苯,甲苯,二甲苯23 C Construction 施工24 CAD Computer Aided Design 计算机辅助设计25 CADD Computer Aided Design and Drafting 计算机辅助设计和绘图26 CCR Conradson carbon residue 康氏残炭27 CCR Continuous Catalyst Regeneration 催化剂连续再生28 CDU Crude distillation unit 原油蒸馏装置29 CGO Coker gas oil 焦化瓦斯油30 CI Cetane index 十六烷指数31 CL Center line 中心线32 CM Construction Manager 施工经理33 CN Conference Note 会议纪要（老外更喜欢用 MOM:Minitues of Meeting）34 COD Chemical oxygen demand 化学需氧量35 CPDP Chinese Preliminary Design Package 中国初步设计包（直接称为PDP就OK了）36 CPM Critical Path Method 关键路径法37 CR Catalytic Reforming 催化重整38 CS Carbon Steel 碳钢39 CW Cooling Water 冷却水40 FEED Front End Engineering Design 前期工程设计41 GB GUO BIAO 国标42 GCD Guaranteed Completion Date 保证完成日期43 GG Gauge glass 玻璃液面计44 GHSV Gaseous hourly space velocity 气体体积空速45 GPH Gas phase hydrogenation 气相加氢46 GSN Global Supply Network 全球供应网络47 GTG Gas Turbine Generator 燃气涡轮发电机48 GW Gross weight 毛重49 HAZID Hazard Identification Review 危险识别审查50 HAZOP Hazard and Operability Study 危险与可操作性研究51 HBP Highly branched paraffins 高支链烷烃52 HC Hydrocracking 加氢裂化53 HCCO Heavy catalytic cycles oil 重催化循环油54 HCGO Heavy coker gas oil 重焦化瓦斯油55 HDA hydrodearomatization 加氢脱芳烃56 HDF hydrofinishing 加氢后精制57 HDM hydrodemetallization 加氢脱金属58 HDN hydrodenitrogenation 加氢脱氮59 HDPE High Density Polyethylene 高密度聚乙烯60 HO Home Office 总部61 HDS hydrodesulfurization 加氢脱硫62 HDT hydrotreating 加氢精制，加氢处理63 HGO Heavy gas oil 重瓦斯油64 HR Human Resource 人力资源65 HP High pressure 高压66 HSFO High sulfur fuel oil 高硫燃料油67 HSR Heavy straight run 重直馏油68 HVAC Heating, Ventilation and Air Conditioning 采暖通风69 HVGO Heavy vacuum gas oil 减压重瓦斯油70 HVI High viscosity index 高粘度指数71 IBL Inside Battery Limits (Same as ISBL) 界区内72 IBP Initial Boiling Point 初馏点，初沸点73 IEC International Electro-technical Commission 国际电工委员会74 IFA Issued for Approval 用于正式批准75 IFB Issued for Bid 用于招标（ITB：用的更多）76 IFC Issued for Construction 用于施工77 IFD Issued for Design 用于设计78 IFH Issued for HAZOP 用于危险与可操作性研究79 ISBL Inside Battery Limits (same as IBL) 界区内80 ISO International Standardization Organization 国际标准化组织81 IS&T/IT Information System and Technology (same as IT) 信息系统和技术82 ITB Invitation to Bid 邀标书83 JV Joint Venture 合营者84 KW Kilo-Watt 千瓦85 LAN Local Area Network 局域网86 LC Letter of Credit 信用证87 LCC Life Cycle Cost 寿命周期成本88 LCCO Light catalytic cycle oil 催化裂化轻循环油89 LCGO Light coker gas oil 焦化轻瓦斯油90 LCN Light coker naphtha 焦化轻汽油91 LCO Light cycle oil 轻循环油92 LDE Lead Discipline Engineer 专业负责人93 LDPE Low Density Polyethylene 低密度聚乙烯94 Level 1 High Level Schedules, control documentsused for control of total scope 项目计划1 （项目进度）95 Level 2 Intermediate Level Schedules, control documents designed to control scope at unit, area, department, contract or discipline level 项目计划296 Level 3 Detailed Schedules, control documents designed to control and report the status of individual deliverables, e.g. documents, requisitions etc. 项目计划3（还有LEVEL 4）97 LLDPE Linear Low Density Polyethylene 线性低密度聚乙烯98 LOI Letter of Intent 意向书99 LP Low Pressure 低气压100 LPG Liquefied Petroleum Gas 液化石油气101 LS Lump Sum 固定总价102 LS Low sulfur 低硫103 LSD Low sulfur diesel 低硫柴油104 LSFO Low sulfur fuel oil 低硫燃料油105 LSR Light straight run 轻直馏油106 LSTK Lump Sum Turn Key （一揽子价格）总承包107 LSWR Low sulfur waxy residue 低硫含蜡渣油108 LTFT Low-temperature flow test 低温流动性试验109 LTRS Low-temperature recovery system 低温回收系统110 LV Low Voltage 低（电）压111 LVGO Light vacuum gas oil 轻减压瓦斯油112 LVI Low viscosity index 低粘度指数113 LVN Light virgin naphtha 直馏轻石脑油馏分114 MC Mechanical Completion 机械竣工115 MCR Micro carbon residue 微残炭116 MEG Mono Ethylene Glycol same as EG) 乙二醇117 MHC Mild hydrocracking 缓和加氢裂化118 MPA Multi Project (Purchasing) Agreement 大宗采购协议119 MFA Multi-Facility (Purchase) Agreement 大宗采购协议120 MON Motor octane number 马达法辛烷值121 MP Medium pressure 中压122 MPHC Moderate pressure hydrocracking 中压加氢裂化123 MR Material Requisition 请购单124 MRP Material Requisition (issued for Purchase) 请购单(用于购买)125 MRQ Material Requisition (issued for Quotation) 请购单(用于报价)126 MRR Material Receiving Report 材料验收单127 MTO Material Take-Off 材料表128 MV Medium Voltage 中（电）压129 MW Mega-Watt 兆瓦130 MW Molecular weight 分子量131 N/A Not applicable or Not Appropriate 不适用的132 N/A Not Available 无133 NEC National Electrical Code 国家电气规范134 NEMA National Electrical Manufacturers Association 国家电气制造商协会135 NFPA National Fire Protection Association 全国防火协会136 NGL Natural Gas Liquids 天然气液体137 NP Normal paraffin 正构烷烃138 NPSH Net positive suction head 净吸入头139 NR Non Reimbursable (costs) 非实报实销140 NTP Notice To Proceed 开工通知书141 NTS Not to Scale 不按比例142 OBL Outside Battery Limits ￡®same as OSBL 界区外143 OBS Organization Breakdown Structure 组织分解结构144 OSBL Outside Battery Limits (same as OBL) 界区外145 P3 Primavera Project Planner 项目计划管理（一个盛名之下，其实难负的进度编制软件，用来忽悠忽悠老外还行）146 PAC Polycyclic aromatic compound 稠环芳烃,多环芳烃147 PAG Project Automation Group 项目自动化团队148 PAF Personnel Authorization Form 职员批准表149 P&ID Process and instrumentation Diagram 工艺仪表流程图150 PID Proportional, Integral and Differential 比例、积分加微分（控制）151 PC Personal Computer 个人电脑152 PDA Propane deasphalting 丙烷脱沥青153 PDAO Propane deasphalted oil 丙烷脱沥青油154 PDU Propane deasphalting unit 丙烷脱沥青装置155 PE Project Engineer 项目工程师156 PE Polyethylene 聚乙烯157 PEM Project Engineering Manager 项目设计经理158 PET Project Execution Team 项目执行组159 PFD Process Flow Diagram 工艺流程图160 PFE Project Field Engineer 项目现场工程师161 PFPM Project Field Procurement Manager 项目现场采购经理162 PEFS Process Engineering Flow Scheme (same as P&ID) 工艺设计流程图163 PFS Process Flow Scheme (same as PFD-Process Flow Diagram) 工艺流程图164 P/L Packing List 装箱单165 PM Project Manager 项目经理166 PMC Project Management Contractor 项目管理承包商167 PMM Project Material Manager 项目材料经理168 PNA Polynuclear aromatics 稠环芳烃,多环芳烃169 PNA Paraffin, Naphthene, Aromatic 烷烃、环烷烃、芳烃170 PO Procurement Order 采购订单171 POX Partial Oxidation 部分氧化造气172 PP Polypropylene 聚丙烯173 PPM Project Procurement Manager 项目采购经理174 PQP Project Quality Plan 项目质量计划175 PQAM Project Quality Assurance Manager 项目质量保证经理176 PQCM Project Quality Control Manager 项目质量控制经理177 PR Procedure 程序178 PRC People Republic of China 中华人民共和国179 PRS Power recovery system 能量回收系统180 PSA Pressure swing adsorption 变压吸附181 PSM Project Site Manager 项目现场经理182 PVC Poly Vinyl Chloride 聚氯乙烯183 PW Paraffin wax 石蜡184 QA Quality Assurance 质量保证185 QC Quality Control 质量控制186 QM Quality Management 质量管理187 RDS Resid desulfurization 渣油(加氢)脱硫188 RFCC Resid FCC 渣油催化裂化189 RFG Reformulated gasoline 新配方汽油190 RHC Resid hydroconversion 渣油加氢转化191 RHDS Residue hydrodesulfurization 渣油加氢脱硫192 RIS Refinery information system 炼油厂信息系统193 RMP Risk management plan 风险管理计划194 RON Research octane number 研究法辛烷值195 RONC Research octane number clear 不加铅研究法辛烷值196 ROSE Resid oil supercritical extraction 渣油超临界抽提197 SCO Synthetic crude oil 合成原油198 SDW Solvent dewaxing 溶剂脱蜡199 SIGF Site Integration & General Facility 全场一体化和一般设施200 RFSU Ready for Start Up 待开车201 S/C Subcontractor 分包商202 SM Styrene Monomer 苯乙烯单体203 SOR Start of run 运转初期204 SR Semi-regenerative 半再生的205 SR Straight run 直馏206 SRU Sulfur recovery unit 硫磺回收装置207 SS Stainless Steel 不锈钢208 SSOT Single stage once through 一段一次通过加氢裂化209 STG Steam Turbine Generator 蒸汽发电机210 TAN Total acid number 总酸值211 TBD To be Determined 待定212 TBN Total base number 总碱值213 TBS Technical Bid Summary 技术标概要214 T&C'S Terms and Conditions (e.g. of purchase) 术语和条件(用于采购) 215 TCD Target Completion Date 目标完成日期216 TGCU Tail gas cleanup unit 尾气净化装置217 TGTU Tail gas treating unit 尾气处理装置218 TIC Total Installed Cost 总体安装费用219 T&L Traffic and Logistics 交通与后勤管理220 TS Technical Specialist 技术专家221 TSA Technical Services Agreement 技术服务协议222 TF Tank Farm 罐区223 UFD Utility Flow Diagram 公用工程流程图（UP&ID 或UID更常用）224 ULSD Ultra low sulfur diesel 超低硫柴油225 UK United Kingdom 英国226 UR Unit Rate 单价227 USA United States of America 美利坚合众国228 VDU Vacuum distillation unit 减压蒸馏装置229 VE Value Engineering 价值工程230 VGO Vacuum gas oil 减压瓦斯油231 VI Viscosity index 粘度指数232 VL Vendor List 制造厂表233 VP Vendor Print 厂商资料234 VPMS Vendor Print Management System 厂商资料管理系统235 VPTL Vendor Print Transmittal Letter 厂商资料传送236 VR Vacuum residue 减压渣油237 VRDS Vacuum residue desulfurization 减压渣油加氢脱硫238 VTB Vacuum tower bottoms 减压渣油239 WAN Wide Area Network 广域网240 WHSV Weight hourly space velocity 重时空速241 WPC World Petroleum Congress 世界石油大会242 WT Weight 重量243 WWTS Wastewater treatment system 污水处理系统244 VCM/PVC Vinyl Chloride 氯乙烯/聚氯乙烯245 VIP Value Improvement Practices 价值工程实践246 WBS Work Breakdown Structure 工作分解结构（这个是很重要的衡量进度的手段。

管道仪表流程图物料代号和缩写词1996-12-15发布 1997-01-01实施中国石化兰州设计院目次1 说明 (1)2 管道仪表流程图上的物料代号 (1)3管道仪表流程图上的缩写词 (6)附加说明 (30)1 说明1.1在本规定中列入的物料代号和缩写字母是最基本的。

当工程设计中需要补充本规定所列以外的物料代号和缩写字母时，不要与本规定相矛盾。

1.2 当必须指明物料代号是供给或返回时，可在物料代号后加S(Supply)表示供给，加R(Return)表示返回。

例如，本文中冷却水供水为CWS，冷却水回水为CWR。

1.3 要指明气相或液相等相特性时，可在物料代号后加G(Gas)表示气相，加L(Liquid)表示液相，例如氨作为冷冻剂，AMG为气氨，AML为液氨。

1.4本规定中，不包括自控专业用的代号和缩写字母，不包括计量单位和符号，不列入单位、协会、标准等的缩写字母。

2 管道仪表流程图上的物料代号2.1分类物料代号用于管道编号，分为工艺物料代号及化学品、辅助物料和公用物料代号两类。

2.2工艺物料代号缩写代号英文中文词义P Process stream 工艺物料(通用代号)PG Process gas 工艺气体PL Process liquid 工艺液体PS Process solid 工艺固体2.3 化学品、辅助物料和公用物料代号缩写代号英文中文词义A Air 空气AC Acid 酸、酸液ACG Acidily gas 酸性气体ACL Acidily liqiud 酸性液体ACS Acidily sewage 酸性污水AD Additive 添加剂AM Ammonia 氨AMG Gaseous ammonia 氨气(作制冷剂)AML Liquid ammonia 液氨(作制冷剂)AMW Ammonia water 氨水BA Blowing Air 鼓风空气BD Blow down 排污BR Brine 盐卤水BW Boiler feed water 锅炉给水C Steamy condensate 水蒸汽凝液CA Caustic 碱、碱液CAG Caustic gas 碱性气体CAL Caustic liquid 碱性液体CAS Caustic sewage 碱性污水CAT Catalyst 催化剂CCA Carrier catalyst Air 催化剂载运空气CDR Chemical Drain 化学污水放净CHW Chilled water 冷冻冷水(指0℃以上)CL Chlorine 氯CM Chemicals 化学品CNS Clean sewage 清净下水CO Cooling oil 冷油(冷却油)COO Carbon dioxide 二氧化碳CRS Contaminated rain and sewage 污染下水(指污染的雨水、冲洗水、放净水、排水)CSW Chilled salt water 冷冻盐水(指0℃以下)CTM Cooling transfer material 冷载体CW Cooling water 冷却水CWR Cooling water return 冷却水回水CWS Cooling water supply 冷却水供水DAW Dealkalized water 脱碱水(用于除盐水系统)DEW Demineralized water 除盐水(脱盐水)DF Dry Flare 干火炬排放气DR Drain 排水、排液DW Domestic water 生活用水、饮用水EA Exhaust air 排出空气ER Ethane(or ethylene)refrigerant 乙烷(或乙烯)冷冻剂ES Exhaust steam 排出蒸汽F Flare exhaust 火炬排放气FA Filling Air 填充空气FG Fuel gas 燃料气FLG Flue gas 烟道气FLW Filtrated water 过滤水FO Fuel oil 燃料油FOS Foaming solution 泡沫液FR Freon refrigerant 氟里昂冷冻剂FT Fused salt 熔盐FW Fire water 消防水GO Gland oil 填料油GW Gased water 加气水、溶气水H Hydrogen 氢气HA Hydrochloric acid 盐酸HC High pressure condensate 高压蒸汽凝液HF Hot Flare 热火炬排放气HO Heating oil 热油、加热油、热载油HS High pressure steam 高压蒸汽HSS High pressure saturated steam 高压饱和蒸汽HSU High pressure super steam 高压过热蒸汽HTM Heat transfer material 热载体HW Hot water 热水HWR Hot water return 热水回水(用于采暖、加热、空调等) HWS Hot water supply 热水给水(用于采暖、加热、空调等) HYL Hydraulic liquid 液压液体HYO Hydraulic oil 液压油HYW Hydraulic water 液压水IA Instrument air 仪表空气ICW Intermadiate cooling water 冷却水二次用水IDW Industrial snd domestic water 生产和生活用水IG Inert gas 惰性气体IS Industrial sewage 生产污水(泛指工艺过程产生的污水)IW Industrial water 生产用水LC Low pressure condensate 低压蒸汽凝液LD Liquid drain 排液(泛指工艺排液)LO Lubricating oil 润滑油LS Low pressure steam 低压蒸汽LSS Low pressure saturated steam 低压饱和蒸汽LSU Low pressure super steam 低压过热蒸汽MC Medium pressure condensate 中压蒸汽凝液MR Methane refrigerant 甲烷冷冻剂MS Medium pressure steam 中压蒸汽MSS Medium pressure saturated steam 中压饱和蒸汽MSU Medium pressure super steam 中压过热蒸汽N Nitrogen 氮气NG Natural gas 天然气OL Oil 油(泛指除原料外的油)OS Oily sewage 含油污水OX Oxygen 氧气PA Plant air 工厂空气PC Process Condensate 工艺冷凝液PR Propane(or propylene)refrigerant 丙烷(或丙烯)冷冻剂PW Polished water 精制水QO Quench Oil 急冷油QW Quench water 急冷水R Refrigerant 冷冻剂、冷媒、制冷剂RAW Raw water 原水RCS Rain water and clean sewage 雨水及清净下水(指清净的雨水、冲洗水、放净水、排水)RW Raw water 雨水S Steam 蒸汽SA Sulphuric acid 硫酸SEW Sea water 海水SFW Soft water 软水(软化水)SG Stack Gas 烟道气SL Sealing liquid 密封液SO Sealing oil 密封油SS Sanitary sewage 生活污水STA Starting Air 开车空气SU Sludge,slurry 污泥、泥浆SW Sealing water 密封水TC Turbine Condensate 透平凝液TW Treated waste water 处理后的废(污)水TWF Filtration Treated Water 过滤水TWP Purified Treated Water 澄清水VE Vacuun exhaust 真空排放气VG Vent gas 放(排)空气体W Water 水WAC Waste acid 废酸WCA Waste caustic 废碱WF Wet Flare 湿火炬排放气WG Waste gas 废气WL Waste liquid 废液WO Waste oil 废油WS Waste solid 废渣WW Waste water 废水(各种污水统称) WWC Chemical Waste Water 化学污水WWP Production Waste Water 生产污水WWS Sanitary Waste Water 生活污水3 管道仪表流程图上的缩写词3.1按英文字母顺序排列的缩写词缩写词用于图纸上的说明和标注。

石油预处理工艺流程框图The process flow diagram of oil pretreatment is an essential tool in the oil refining industry. It outlines the various steps involved in preparing crude oil for further processing. This diagram provides a clear visual representation of the equipment, piping, and control systems required for the efficient operation of the pretreatment process.石油预处理工艺流程图是石油精炼行业的重要工具。

它概述了为进一步加工石油原油而涉及的各个步骤。

该图提供了用于有效运行预处理过程所需的设备、管道和控制系统的清晰视觉表示。

The first step in the oil pretreatment process is desalting, which involves removing salt and other impurities from the crude oil. This is typically done using electrostatic precipitators or chemical additives to facilitate the separation of the salt from the oil. Desalting is crucial to prevent corrosion in downstream equipment and to improve the quality of the refined products.石油预处理过程的第一步是脱盐，其中涉及从原油中去除盐和其他杂质。

产品工艺流程图Flowchart(标准版)*** 专案量产 FLOWCHART专案号：厂内代码：编客户名称图片工程1234567891011121314151617181920212223242526号料号工艺流程原资料下料冲刷1退火1浸浓油1成一冲刷2退火2浸浓油2成二冲刷3退火3浸浓油3成三冲刷4退火4浸浓油4成四冲刷5浸淡油1成五冲刷5浸淡油2成六冲刷6浸淡油3设备/60T冲冲刷线退火炉浓油线300T油压冲刷线退火炉浓油线300T油压冲刷线退火炉浓油线300T油压冲刷线退火炉浓油线300T油压冲刷线淡油线300T油压冲刷线淡油线300T油压冲刷线淡油线床机机机机机机辅助//冲刷吊夹钳浸油吊篮成一模具冲刷吊篮夹钳浸油吊篮成二模具冲刷吊篮夹钳浸油吊篮成二模具冲刷吊篮夹钳浸油吊篮成二模具冲刷吊篮浸油吊篮成二模具冲刷吊篮浸油吊篮成三模具冲刷吊篮浸油吊篮成三模具设备篮SUS 304///////////////////原资料0H/1Cycle0.80*401s/pcs1s/pcs1s/pcs1s/pcs1s/pcs Time/s pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs pcs(1 出8〕(1 出8〕(1 出8〕(1 出8〕(1 出8〕(1 出8〕(S)/PC(1 出8〕标准产/24000128000560001000000240012800056000100000036001280005600010000003600128000560001000000360012800010000003600128000100000036001280001000000能pcs/hr人力/1121112111211121111111111良率100.0%99.9%100.0%100.0%100.0%99.5%100.0%100.0%100.0%99.5%100.0%100.0%100.0%99.0%100.0%100.0%100.0%99.0%100.0%100.0%99.0%100.0%100.0%98.0%100.0%100.0%场所采买厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内厂内版次日期校正纪录A02021/2/28初版刊行A12021/5/17增加 CNC制程A22021/5/24调整 CNC等制程 C/TA32021/5/31调整下料，冲刷，浸油，退火等制程 C/T。

化工生产流程图解第四版英文回答：Chemical production processes involve a series of steps to transform raw materials into valuable products. The process flow diagram is a visual representation of these steps, providing a clear overview of the entire production process.The first step in chemical production is the selection and preparation of raw materials. This may involve sourcing and testing raw materials to ensure they meet the required specifications for the final product. Once the raw materials are approved, they are stored in designated areas until needed for production.The next step is the mixing and reaction process, where the raw materials are combined and undergo chemical reactions to produce the desired compounds. This step is crucial in determining the quality and properties of thefinal product. The process flow diagram illustrates the equipment and machinery used in this step, as well as the flow of materials through the production line.Following the mixing and reaction process, the product undergoes purification and separation to remove impurities and isolate the desired compound. This step often involves the use of distillation, filtration, and other separation techniques to achieve the required level of purity.Once the product is purified, it may undergo further processing, such as drying, crystallization, or chemical treatment to enhance its properties. The process flow diagram highlights these additional steps and the equipment involved in each process.Finally, the finished product is packaged and labeled for distribution. The process flow diagram shows the packaging and labeling steps, as well as any qualitycontrol checks that may occur before the product is released for distribution.Overall, the process flow diagram provides a comprehensive overview of the chemical production process, from raw material selection to final product distribution.中文回答：化工生产流程涉及一系列步骤，将原材料转化为有价值的产品。

炼油厂成品油出厂流程英语Finished Product Ex-Refinery Process.The finished product ex-refinery process is the sequence of steps involved in preparing and releasing refined petroleum products from a refinery for distribution to customers. It encompasses a range of activities, including product blending, storage, testing, and loading.Product Blending.The first step in the ex-refinery process is product blending. Here, various refined products are combined to create specific grades and specifications required by customers. For example, different octane-rated gasoline blends are created by mixing components such as straight-run gasoline, reformate, and alkylate. Blending is acritical process that ensures the finished product meets industry standards and end-user requirements.Storage.After blending, the finished products are stored in large tanks to await distribution. These tanks provide temporary storage for various products, including gasoline, diesel, jet fuel, and heating oil. The storage facilities are designed to maintain product quality and prevent contamination.Testing.Before release from the refinery, the finished products undergo rigorous testing to ensure they meet specifications and regulatory standards. This testing includes:Physical property analysis: Measuring parameters such as density, viscosity, and flash point to ensure the product meets industry standards.Chemical analysis: Determining the composition of the product, including the presence of impurities or additives.Performance evaluation: Assessing the product's performance in specific applications, such as enginetesting for gasoline.Loading.Once testing is complete, the finished products are loaded onto various transportation modes for distribution to customers. These include:Trucks: Used for short-haul transportation of products to local distribution terminals or end-users.Railcars: Suitable for larger volumes and longer-distance transportation.Ships: Used for export and import of products to and from international markets.Documentation.Throughout the ex-refinery process, detaileddocumentation is maintained to track the movement and quality of the products. This documentation includes:Product certificates: Official documents that certify the specifications and quality of the finished products.Shipment records: Detailed logs of product loading, transportation, and delivery.Quality control reports: Records of testing results and any deviations from specifications.Quality Control and Assurance.Maintaining the quality of finished products is paramount throughout the ex-refinery process. Refineries implement strict quality control measures, including:Process monitoring: Continuously monitoring process parameters to ensure optimal blending and storage conditions.Regular testing: Performing scheduled testing toverify product quality and compliance with specifications.Equipment maintenance: Ensuring proper maintenance and calibration of storage tanks and loading equipment to prevent contamination.Safety and Environmental Considerations.Safety and environmental protection are integral to the finished product ex-refinery process. Refineries adhere to rigorous safety protocols and environmental regulations to minimize risks and protect human health and the environment. These measures include:Proper handling and storage: Implementing safehandling practices and maintaining appropriate storage facilities to prevent spills and leaks.Waste management: Establishing systems for proper disposal of waste generated during the process.Emergency response plans: Developing and implementing plans to respond effectively to potential emergencies, minimizing impact on the environment and ensuring the safety of personnel.Conclusion.The finished product ex-refinery process is a complex and multi-faceted operation that ensures the safe and efficient release of refined petroleum products from refineries to customers. It involves a series of steps, from product blending and storage to rigorous testing, loading, and documentation. By adhering to industry standards and implementing strict quality control measures, refineries deliver products that meet customer specifications and regulatory requirements. Safety and environmental considerations remain paramount throughout the process, protecting human health, the environment, and the integrity of the products.。

49张化工装置流程图催化分流部分工艺流程图导读：石油化工厂里的装置多种多样，而很多装置作为化工人必须要熟悉，那么今天小编为大家介绍各种化工装置的流程图，不仅能帮助大家熟悉各种装置的生产流程还能了解部分生产工艺。

常减压电脱盐装置原则流程从油田送往炼油厂的原油往往含盐(主要是氧化物)带水（溶于油或呈乳化状态），可导致设备的腐蚀，在设备内壁结垢和影响成品油的组成，需在加工前脱除。

电脱盐基本原理：为了脱掉原油中的盐份，要注入一定数量的新鲜水，使原油中的盐充分溶解于水中，形成石油与水的乳化液。

在强弱电场与破乳剂的作用下，破坏了乳化液的保护膜，使水滴由小变大，不断聚合形成较大的水滴，借助于重力与电场的作用沉降下来与油分离，因为盐溶于水，所以脱水的过程也就是脱盐的过程。

CDU装置原则流程CDU装置即常压蒸馏部分常压蒸馏原理：精馏又称分馏，它是在精馏塔内同时进行的液体多次部分汽化和汽体多次部分冷凝的过程。

原油之所以能够利用分馏的方法进行分离，其根本原因在于原油内部的各组分的沸点不同。

在原油加工过程中，把原油加热到360～370℃左右进入常压分馏塔，在汽化段进行部分汽化，其中汽油、煤油、轻柴油、重柴油这些较低沸点的馏分优先汽化成为气体，而蜡油、渣油仍为液体。

+◆◆◆VDU装置原则流程VDU装置即减压蒸馏部分减压蒸馏原理：液体沸腾必要条件是蒸汽压必须等于外界压力。

降低外界压力就等效于降低液体的沸点。

压力愈小，沸点降的愈低。

如果蒸馏过程的压力低于大气压以下进行，这种过程称为减压蒸馏。

+◆◆◆轻烃回收装置原则流程轻烃回收装置是轻烃的回收设备，采用成熟、可靠的工艺技术，将天然气中比甲烷或乙烷更重的组分以液态形式回收。

+◆◆◆RDS装置流程图RDS即渣油加氢装置，渣油加氢技术包含固定床渣油加氢处理、切换床渣油加氢处理、移动床渣油加氢处理、沸腾床渣油加氢处理、沸腾床渣油加氢裂化、悬浮床渣油加氢裂化、渣油加氢一体化技术及相应的组合工艺技术。

Download tips: This document is carefully compiled by the editor. I hope that after you download them, they can help you solve practical problems. The document can be customized and modified after downloading, please adjust and use it according to actual needs, thank you!In addition, our shop provides you with various types of practical materials, such as educational essays, diary appreciation, sentence excerpts, ancient poems, classic articles, topic composition, work summary, word parsing, copy excerpts, other materials and so on, want to know different data formats and writing methods, please pay attention!石油化工工艺流程图是石油化工生产中必不可少的工具，它能清晰地展现出整个工艺流程，为工程师和操作人员提供了重要的参考依据。

而为了使石油化工工艺流程图更加易于理解和准确无误地传达信息，制定了相应的图例标准。

下面将详细介绍石油化工工艺流程图图例标准的相关内容。

一、图例标准的重要性1. 规范化：图例标准能够统一图中元素的表达方式，避免因表达不清晰而引起的误解。

2. 便于理解：符合图例标准的工艺流程图能够使人一目了然地了解整个流程。

常减压电脱盐装置原则流程CDU装置原则流程VDU装置原则流程轻烃回收装置原则流程补充新氢热低分反应进料泵原料升压泵R-101R-102热高分加氢裂化反应部分流程图加氢裂化分馏部分流程图（一）加氢裂化分馏部分流程图（二）粗汽油凝缩油泵吸收塔底泵补充吸收泵间凝液泵催化吸收稳定部分流程图干气脱硫贫液泵液化气脱硫贫液泵常减压液化气进料泵加氢裂化液化气进料泵过剩空气至焚烧炉液化气脱硫醇碱液再生部分流程图汽油进料泵活化剂泵精汽油泵防胶剂注入泵防胶剂配制泵汽油脱硫脱硫醇装置流程图碳二、碳三馏分脱乙烷塔回流泵丙烷馏分泵丙烯塔回流泵丙烯产品泵脱戊烷塔回流及产品泵戊烷馏分泵气体分馏装置流程图缓冲罐加氢精加氢反应油连续重整预加氢反应部分流程图预加氢反应液相连续重整预加氢分馏部分流程图重整反应器三连续重整反应部分流程图汽油至脱戊烷塔分馏生构化加氢至管网装置来连续重整再接触部分流程图连续重整后分馏部分流程图统连续重整再生部分流程图1.0MPa连续重整热工部分流程图塔来缓冲罐异构化装置流程图苯抽提装置流程图原料油缓冲罐原料油泵新氢酸性水柴油泵分馏塔底重沸炉泵石脑油塔顶气柴油加氢分馏部分流程图低分油航煤加氢反应部分流程图航煤加氢分馏部分流程图酸性气分液制硫燃烧制硫余热锅冷凝冷却转化成型硫封液硫尾气分液硫磺回收制硫部分流程图尾气焚烧炉硫磺回收尾气部分流脱硫富液闪蒸脱硫溶剂储脱硫溶剂再生再生塔顶回流溶剂再生装置流程图汽提塔顶分液罐酸性水汽提装置流程丙烯洗涤塔PP装置闪蒸、汽蒸部分流程图PPPP装置造粒部分流程图储运系统装置、罐区油品系统管线冲洗原则流程图。

适用于炼油装置和石油化工装置的‘工艺流程图’（PFD）和‘管道及仪表流程图’（PID）设计。

对于有特殊要求的项目，须结合具体情况，灵活运用。

工艺流程图的标准，应使用下列标准最新版本。

SH/T 3101《炼油厂流程图图例》EMGS 0807 《设计文件复用规定》SEPM 0101.1 《管道材料等级规定（炼油）》PFD图的画法标准：工艺流程图（PFD）的图例应按SH/T 3101的有关规定绘制。

图纸规格：应采用1号、2号或3号图，如果采用2号或3号图，需要延长时，其长度尽量不要超过1号图的长度。

PFD图的构成：a) 设备；b) 工艺管道及介质流向；c) 参数控制方；d) 工艺操作条件； e) 物料的流率及主要物料的组成和主要物性数据；f) 加热及冷却设备的热负荷。

设备画法流程中只画与生产流程有关的主要设备，不画辅助设备及备用设备。

对作用相同的并联或串联的同类设备，一般只表示其中的一台（或一组），而不必将全部设备同时画出。

所有的设备均用细实线表示并注明编号，并同时注明其名称（汉字）。

设备按同类性质设备的流程顺序统一编号，编号之间可以有空号。

用代号表示设备的属性。

例如C表示塔，E表示换热器等。

但也可以根据用户要求，在设计的技术统一规定中明确采用其他相应设备代号。

装置设备的编号格式规定如下：× ×－× × ×× ×例如某常压催化联合装置（单元号为1）中常压部分（部分号为1）的塔-1，可写成C-1101；催化部分（部分号为2）的塔-1可写成C-1201。

又如某重整装置（不列单元号）重整部分（部分号为2）的换-4可写成E-204。

又如某焦化装置的D-1（不列单元及部分号）可写成D-1。

设备大小可以不按比例画，但其规格应尽量有相对的概念。

有位差要求的设备，应示意出其相对高度位置。

对工艺有特殊要求的设备内部构件应予表示。

例如板式塔应画出有物料进出的塔板位置及自下往上数的塔板总数；容器应画出内部挡板及破沫网的位置；反应器应画出器内床层数；填料塔应表示填料层、气液分布器、集油箱等的数量及位置。
