管道综合材料中英文对照表PIPE.SMLS 无缝钢管
PIPE.EFW 焊接钢管
90.ELBOW.LR 90度长半径弯头(R=1.5D)
90.ELBOW.SR 90度短半径弯头(R=1.0D)
45.ELBOW.LR 45度长半径弯头(R=1.5D)
TEE 三通(包括等径三通和异径三通)
CAP 管帽
REDUCER.CON 同心异径管
REDUCER.ECC 偏心异径管
HALF.COUPLING 半拷贝伦
OLET.WELDOLET 对焊鞍座
FLANGE.WN 带颈对焊法兰
BLIND.FLANGE 盲板法兰(法兰盖)
VALVE.GATE 闸阀
VALVE.GLOBE 截止阀
VALVE.BALL 球阀
VALVE.BUTTERFLY 蝶阀
VALVE.CHECK 止回阀
VALVE.PISTON.CHECK 升降式止回阀
VALVE.SWING.CHECK 旋启式止回阀
VALVE.NEEDLE 针形阀
GASKET 垫片
OCTAGONAL.RING.GASKET 八角型环垫片
STUD.BOLTS/HEAVY.HEX.NUTS 螺柱/螺母
RF 凸台面密封面
RJ 环槽面密封面
SW 承插焊
BW 对焊
WAFER 对夹
CL 、LB表示磅级例如:CL600表示压力等级为600LB(磅)FLEX.HOST 金属软管
GASKET.SPIRAL-WOUND 金属缠绕垫。
工程管道英文缩写对照AA Anchor 固定ABS Absolute 绝对的AISI American Iron and Steel Institute 美国钢铁学会ANSI American National Standards Institute 美国国家标准学会API American Petroleum Institute 美国石油学会APPROX Approximate 大约,近似的ASB Asbestos 石棉ASME *American Society Of Testing Material 美国机械工程师协会ASSY *Assembly 装配,组装ASTM *American Society OfTesting Material 美国材料实验协会ATM *Atmosphere 大气压AWG *American Wire Gage 美国线规AWS *American Wel**** Society 美国焊接协会AWWA *American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover(cap) 螺栓连接的阀兰盖(帽)BE Beveled End (for wel****) 坡口(焊接用)B.E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 法兰盖BLD Blind 盲板BLDG *Buil**** 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B-P Beveled End —Plain End 坡口端.平端BV Butterfly valve 蝶阀BWG * Birmingham Wire Gage 伯明翰线规BW Butt Weld 对焊CC Cap 管帽C-C Center to Center 中至中C-E Center to End 中至端面C-F Center to Face 中至面CH-OP Chain Operated 链条操纵的CH.PL Checkered Plate 花纹钢管C.I *Cast Iron 铸铁CL *Class 英制压力等级,等级,种类CLEAR Clearance 间隙COD Continued on Drawing 接续图COL *Column 柱,塔CONC Concentric 同心的CONN Connection 连接,接口CONT *Continue 连续CONT.V. Control Valve 控制阀CPLG Coupling 管接头,连轴节C.R. Concentric Reducer 同心异径管C.S. *Carbon Steel 碳钢C.S. Cold Spring 冷紧C.S.C. Car Seal Close 在关闭状态下封住C.S.O. Car Seal Open 在开启状态下封住CUST Customer 客C.V Check Valve 止回阀DDEG *Degree 度DF Drain funnel 排液漏斗DIA *Diameter 直径DIM *Dimension 尺寸DISCH *Discharge 出口,排出Diaphragm VELVE 隔膜阀DMF Double Male And Female 双重凹凸DN *Double Male And Female 公称直径DN Down 下DR Drain 排液DS Directional Stop 定向限为架DWG *Drawing 图EE *East 东EC External Coating 外面涂防腐层ECC Eccentric 偏心EFW Electric Fusion Welded 电容焊的EL(ELEV) *Elevation 标高;立面ELL Elbow 弯头EQIOP Equipment 设备,装置EQUIV Equivalent 相当的E.R. Eccentric Reducer 偏心异经管ERW Electric Resistance Welded 电阻焊的EW Eye Washer & Shower 洗眼器及淋浴器EXP.JT Expansion Joint 膨胀节FFDN Foundation 基础FF Flat Faced Or Full Faced 全平面;满平面F-F Face To Face 面至面FGW Fusion Gas Wel**** 气熔焊FIG *Figure 图FL Floor 楼面FLEX TUBE Flexible Tube 挠性管FLG Flange 法兰FLGD Flanged 法兰式的FLGF Flanged Face 法兰面FOB Flat On Bottom 底面平FOT Flat On Top 顶面平FP Fix Point 固定点FS Forged Steel 锻钢FTF Fitting To Fitting 管件直连FTG Fitting 管件FURND Furnished 提供的,装设的FW Field Weld 现伤焊GG Guide 导向GA *Gage 表,表压,规(线规)GALV *Galvanize 镀锌GL Ground Level 地面GLV Globe Valve 截止阀GEAR OP Gear Operated 齿轮传动的GMAW Gas Metal Arc Wel**** 金属极惰气体保护焊GSKT Gasket 垫片GTAW (Inert)Gas Tungsten Arc Wel**** 惰性气体保护钨极电弧焊GV Gate Valve 闸阀HH Hanger 吊架HC Hose Connection 软管接头H.CPLG Half Coupling 半节管接头HDR Header 总管HEX *Hexagon 六角形HF Hard Alloy Face on阀内件(阀心)为Valve Trim 硬质合金密封面HH Hand Pole 手孔HOR Horizontal 水平的H.P *High Pressure 高压HS Hose Station 软管IID *Inside Diameter 内径IN *Inch 英寸INS Insulation 隔热INST Instrument 仪表INV Invert (inside bottom of pipe) 管子内底IPS Iron Pipe size 铁管尺寸ISO Isometric Drawing 周测图(空视图)I.S.B.L Inside Battery Limit 装置边界内恻ISNS Inside screw & Non-rising Stem 内螺纹非升杆ISRS Inside screw & Rising stem 内螺纹升杆JJT Joint 接头JS Jack Screw 顶开(起)螺栓LLC Locked Closed 在关闭状态下锁定LEP Large end plain 大端为平的LET Large end Threaded 大端带螺纹LG Long 长LGF Lens Gasket Face 透镜垫连接面L.H.THD Left Hand Thread 左螺纹LIFT Lift Type 升降式LJ Lap Joint 搭接LJF Lap Joint Flange 松套法兰LO Locked Open 在开启状态下锁定L.P. Low Pressure 低压LR Long Radius 长半径LRE Long Radius Elbow 长半径弯头LTG Large Tongue & Groove 大椎槽MMATL Material 材料MAX Maximum 最大MB Machine Bolt 机器螺栓(单头)MF Male and Female 凸和凹MFG Manufacture 制造MF *Manufacture 制造厂MH Manhole 人孔MI Malleable Iron 可锻铸铁MIN *Minimum 最小MJ Mechanical Joint 机械接头M.L Match Line 连续线MSS * Manufacturers Standardization Society of the Valve and Fittings Industry, Inc. 美国阀门和管件制造商标准化协会MTO Material take-off 材料统计MW Minimum Wall 最小壁厚M.W. Mineral Wool 矿(物)棉NN *North 北NB Nominal Bore 公称孔径N.B. Non-Bonnet 无阀盖NC Normally Closed 常闭NIP Nipple 短管NO Normally Open; 常开*Number号;数量NO INS No Insulation 不隔热NOM Nominal 公称的;额定的NOZ Nozzle 管口NPS Nominal Pipe Size 公称管径NPSH Net Positive Suction Head 净正吸入压头NPT *American National Taper 美国锥管螺纹Pipe ThreadNS Nominal Size 公称直径NV Needle Valve 针形阀OOD *Outside Diameter 外径OET One end Threaded 一端带螺纹OR Outside Radius 外半径ORF Orifice 孔板ORIENT Orientation 方位OS & Y Outside Screw and Yoke 外螺纹阀杆和阀轭OSNB Outside Screw Non-Bonnet 外螺纹无阀盖PP Plug 堵头PAP Piping Arrangement Plan 管道布置平面图PB Pressure Seal Bonnet 压力密封的阀盖P-B Plain End –Bevel End 平端—坡口端PC Pressure Seal Cap 压力密封的阀帽P.C.D. Pitch Circle Diameter 节圆直径PE Plain End (not beveled) 平端(无坡口)PF Platform 平台PID Piping & Instrument Diagram管道及仪表流程图PN *Nominal Pressure 公称压力PN Plant North 工厂北向POS point of Support 支承点P-P Plain End—Plain End 两端为平端PREP Preparation 加工准备PSIA *Pounds Per Square InchAbsolute 磅/PSIG Pounds Per Square Inch Gage 磅/PT Point 点PTFE *Polytetrafluoroethylene聚四氟乙烯PT.NO Part No. 件号PV Plug Valve 旋塞阀PVC *Poly Vinyl Chloride 聚氯乙烯QQTY *Quantity 数量RR *Radius 半径RED Reducer 异径管REF Reference 参考REINF Reinforce 加强REQD Required 需要;申请REV *Revision 修改RF Raised Face 凸面RG Ring Gasket 环形垫片R.H.THD Right Hand Thread 右螺旋RJ Ring Joint 环垫接头RO Restriction Orifice 限流孔板RPM *Revolutions Per Minute 转/分RPS *Revolutions Per Second 转/秒RS Resting Support 支承架,滑动架RTJ Ring Type Joint(见RJ)RV Relief Valve 安全泄液阀SS *South 南S Spring 弹簧(管架用)SAW (Automatic)Submerged Arc Wel**** 自动埋弧焊SB Stud Bolt 双头螺栓SB Screwed Bonnet 螺纹阀盖SC Sample Cooler 取样冷却器SCH *Schedule 管壁厚系列号SCRD Screwed 螺纹SEP Small end Plain 小端为平的SET Small end Threaded 小端带螺纹SF Semi-Finished 半光SG Sight Glass 视镜SH Surface Hard Facing 硬质密封面SK Sketch 草图SMAW Shielded Metal Arc Wel**** 有保护的金属电弧焊SMLS Seamless 无缝SN Swaged Nipple 异径短管SO Slip – On 滑套SOF Slip – On Flange 滑套法兰SPEC *Specification 规定,说明SPL Sound Pressure Lever 升压水准SQ *Square 方的,平方SR Shout Radius 短半径SRE Short Radius Elbow 短半径弯头SS *Stainless Steel 不锈钢ST Steam Trap 蒸汽疏水阀STD *Standard 标准STG Small Tongue & Groove 小椎槽面STL *Steel 钢STM Steam 蒸汽STM.TR Steam Tracing 蒸汽拌热SUCT Suction 吸入口SV Safety Valve 安全泄气阀SW Socket Weld 承插焊SWG Swage 锻造,模锻SWMG Swing Type 旋启式SYM Symmetrical 对称的TT Tee 三通TE Threaded End 螺纹端TEMP *Temperature 温度TG Tongue & Groove 椎槽THD *Threaded 螺纹的THK *Thickness 厚度TL Tangent Line 切线TN True North 真实北向TOC Top of Concrete 混凝土北向TOP Top of pipe 管顶TOS Top of Support 支架顶面Top of Steel 钢结构顶面TYP Typical 典型的UUB Union Bonnet 带活接头的阀盖UC Union Cap 带活接头的阀帽UN Union 活接头VV Valve 阀VAC Vacuum 真空VAR Variable 可变的VERT Vertical 垂直的VOL *Volume 卷,册,容量,体积WW *West 西WB Weld Branch 焊接支管WC Weld Cap 焊接管帽WD Width 宽度WE Weld End 焊接端WL Wel**** Line 焊接线WN Wel**** Neck 对焊法兰(颈部)WNF Weld Neck Flange 对焊法兰WP Working Pressure 工作压力W.P. Working Point 工作点WT Wall Thickness 壁厚Weight 重量XXH Extra Heavy 加强的,加厚的XXH Double Extra Heavy 双倍加强(厚)的XS Extra Strong 加强的XXS Double Extra Strong 双倍加强的YYP Yield Point 屈服点。
工艺管道中英文对照管材规格:1.管材数量:2个8英寸的管道。
2.管道中英文对照:PIPES-STDBEA106-B(EJ=1.00)SMLSASME-B36.1M。
3.管壁厚端部材质:无缝标准号。
4.假管备注:与主管相同。
5.90度长半径弯头数量:4个。
6.90度长半径弯头材质:STDBWA234-WPB-SSMLSASME-B16.9.7.90度长半径弯头壁厚端部材质:无缝标准号。
8.材质有A106B、P11、P22、A691、TP304H、A.管配规格:1.材质有A234-WPB-S=A106、A691;A234-WP11=P11;A234-WP22=P22.2.STR TEE数量:1个。
3.STR TEE规格:CL3000SWA105FORGEASME-B16.11,等径三通壁厚承插焊材质铸造标准号。
4.RED XXX数量:3个。
5.RED TEE规格:11.07×S-XXS BW A234-WP22 CL1-S SMLS ASME-B16.9,异径三通壁厚端部材质无缝标准号。
6.ECC SWAGES数量:6个。
7.ECC SWAGES规格:80×S-80 PE×PE A234-WPB—S SMLS MSS-SP-95,偏心大小头壁厚端部材质无缝标准号。
8.CON REDUCER数量:2个。
9.CON REDUCER规格:25.8×14.02mm BW A234-WP22 CL1-S SMLS ASME-B16.9,偏心大小头壁厚端部材质无缝标准号。
10.SOCKLET数量:1个。
11.SOCKLET规格:CL6000SWA182-F22CL3FORGEMSS-SP-97,承插支管台壁厚端部材质锻炼标准号。
12.SMLS(无缝)WELD(焊接)数量:4个。
13.45 DEG(45)数量:2个。
14.CON SWAGE数量:1个。
15.ECC REDUCER数量:1个。
工程管道英文缩写对照AA Anchor 固定ABS Absolute 绝对的AISI American Iron and Steel Institute 美国钢铁学会ANSI American National Standards Institute 美国国家标准学会API American Petroleum Institute 美国石油学会APPROX Approximate 大约,近似的ASB Asbestos 石棉ASME *American Society Of Testing Material 美国机械工程师协会ASSY *Assembly 装配,组装ASTM *American Society OfTesting Material 美国材料实验协会ATM *Atmosphere 大气压AWG *American Wire Gage 美国线规AWS *American Wel**** Society 美国焊接协会AWWA *American Water WorksAssociation 美国水工协会BBB Bolted Bonnet 栓柱连接的阀盖BB By Buyer 买方供货B-B Beveled End-Beveled End 两端为坡口端BC Bolt Circle 螺栓中心圆B.C Bolted Cover(cap) 螺栓连接的阀兰盖(帽)BE Beveled End (for wel****) 坡口(焊接用)B.E Bell End 承口BEP Both Ends Plain 两端平BET Both Ends Threaded 两端带螺纹BL Battery Limit 装置区边界BF Blind Flange 法兰盖BLD Blind 盲板BLDG *Buil**** 建筑物BM Bill Of Material 材料表BOP Bottom Of Pipe 管底B-P Beveled End —Plain End 坡口端 . 平端BV Butterfly valve 蝶阀BWG * Birmingham Wire Gage 伯明翰线规BW Butt Weld 对焊CC Cap 管帽C-C Center to Center 中至中C-E Center to End 中至端面C-F Center to Face 中至面CH-OP Chain Operated 链条操纵的CH.PL Checkered Plate 花纹钢管C.I *Cast Iron 铸铁CL *Class 英制压力等级,等级,种类CLEAR Clearance 间隙COD Continued on Drawing 接续图COL *Column 柱,塔CONC Concentric 同心的CONN Connection 连接,接口CONT *Continue 连续CONT.V. Control Valve 控制阀CPLG Coupling 管接头,连轴节C.R. Concentric Reducer 同心异径管C.S. *Carbon Steel 碳钢C.S. Cold Spring 冷紧C.S.C. Car Seal Close 在关闭状态下封住C.S.O. Car Seal Open 在开启状态下封住 CUST Customer 客C.V Check Valve 止回阀DDEG *Degree 度DF Drain funnel 排液漏斗DIA *Diameter 直径DIM *Dimension 尺寸DISCH *Discharge 出口,排出Diaphragm VELVE 隔膜阀DMF Double Male And Female 双重凹凸DN *Double Male And Female 公称直径DN Down 下DR Drain 排液DS Directional Stop 定向限为架DWG *Drawing 图EE *East 东EC External Coating 外面涂防腐层ECC Eccentric 偏心EFW Electric Fusion Welded 电容焊的EL(ELEV) *Elevation 标高;立面ELL Elbow 弯头EQIOP Equipment 设备,装置EQUIV Equivalent 相当的E.R. Eccentric Reducer 偏心异经管ERW Electric Resistance Welded 电阻焊的EW Eye Washer &Shower 洗眼器及淋浴器 EXP.JT Expansion Joint 膨胀节FFDN Foundation 基础FF Flat Faced Or Full Faced 全平面;满平面F-F Face To Face 面至面FGW Fusion Gas Wel**** 气熔焊FIG *Figure 图FL Floor 楼面FLEX TUBE Flexible Tube 挠性管FLG Flange 法兰FLGD Flanged 法兰式的 FLGF Flanged Face 法兰面FOB Flat On Bottom 底面平FOT Flat On Top 顶面平FP Fix Point 固定点FS Forged Steel 锻钢FTF Fitting To Fitting 管件直连FTG Fitting 管件FURND Furnished 提供的,装设的FW Field Weld 现伤焊GG Guide 导向GA *Gage 表,表压,规(线规)GALV *Galvanize 镀锌GL Ground Level 地面GLV Globe Valve 截止阀GEAR OP Gear Operated 齿轮传动的GMAW Gas Metal Arc Wel**** 金属极惰气体保护焊GSKT Gasket 垫片GTAW (Inert)Gas Tungsten Arc Wel**** 惰性气体保护钨极电弧焊GV Gate Valve 闸阀HH Hanger 吊架HC Hose Connection 软管接头H.CPLG Half Coupling 半节管接头HDR Header 总管HEX *Hexagon 六角形HF Hard Alloy Face on 阀内件(阀心)为Valve Trim 硬质合金密封面HH Hand Pole 手孔HOR Horizontal 水平的H.P *High Pressure 高压 HS Hose Station 软管 IID *Inside Diameter 内径IN *Inch 英寸INS Insulation 隔热INST Instrument 仪表INV Invert (inside bottom of pipe)管子内底IPS Iron Pipe size 铁管尺寸ISO Isometric Drawing 周测图(空视图)I.S.B.L Inside Battery Limit 装置边界内恻ISNS Inside screw &Non-rising Stem 内螺纹非升杆ISRS Inside screw &Rising stem 内螺纹升杆JJT Joint 接头JS Jack Screw 顶开(起)螺栓LLC Locked Closed 在关闭状态下锁定LEP Large end plain 大端为平的LET Large end Threaded 大端带螺纹LG Long 长LGF Lens Gasket Face 透镜垫连接面L. H.THD Left Hand Thread 左螺纹LIFT Lift Type 升降式LJ Lap Joint 搭接LJF Lap Joint Flange 松套法兰LO Locked Open 在开启状态下锁定L.P. Low Pressure 低压LR Long Radius 长半径LRE Long Radius Elbow 长半径弯头LTG Large Tongue &Groove 大椎槽MMATL Material 材料MAX Maxim um 最大MB Machine Bolt 机器螺栓(单头)MF Male and Female 凸和凹MFG Manufacture 制造MF *Manufacture 制造厂MH Manhole 人孔MI Malleable Iron 可锻铸铁MIN *Minimum 最小MJ Mechanical Joint 机械接头M.L Match Line 连续线MSS * Manufacturers Standardization Society of the Valve and Fittings Industry, Inc.美国阀门和管件制造商标准化协会MTO Material take-off 材料统计MW Minimum Wall 最小壁厚M.W. Mineral Wool 矿(物)棉NN *North 北NB Nominal Bore 公称孔径N.B. Non-Bonnet 无阀盖NC Normally Closed 常闭NIP Nipple 短管NO Normally Open; 常开 *Number 号;数量NO INS No Insulation 不隔热NOM Nominal 公称的;额定的NOZ Nozzle 管口NPS Nominal Pipe Size 公称管径NPSH Net Positive Suction Head 净正吸入压头NPT *American National Taper 美国锥管螺纹Pipe ThreadNS Nominal Size 公称直径NV Needle Valve 针形阀OOD *Outside Diameter 外径 OET One end Threaded 一端带螺纹OR Outside Radius 外半径ORF Orifice 孔板ORIENT Orientation 方位OS &Y Outside Screw and Yoke 外螺纹阀杆和阀轭OSNB Outside Screw Non-Bonnet 外螺纹无阀盖 PP Plug 堵头PAP Piping Arrangement Plan 管道布置平面图 PB Pressure Seal Bonnet 压力密封的阀盖P-B Plain End -Bevel End 平端一坡口端PC Pressure Seal Cap 压力密封的阀帽 P.C.D. Pitch Circle Diameter 节圆直径PE Plain End (not beveled)平端(无坡口)PF Platform 平台PID Piping &Instrument Diagram 管道及仪表流程图 PN *Nominal Pressure公称压力PN Plant North 工厂北向POS point of Support 支承点P-P Plain End —Plain End 两端为平端PREP Preparation 加工准备PSIA *Pounds Per Square Inch Absolute 磅 /PSIG Pounds Per Square Inch Gage 磅 /PT Point 点PTFE *Polytetrafluoroethylene 聚四氟乙烯 PT.NO Part No. 件号PV Plug Valve 旋塞阀PVC *Poly Vinyl Chloride 聚氯乙烯QQTY *Quantity 数量RR *Radius 半径 RED Reducer 异径管 REF Reference 参考 REINF Reinforce 加强 REQD Required 需要;申请 REV *Revision 修改 RF Raised Face 凸面 RG Ring Gasket 环形垫片 R.H.THD Right Hand Thread 右螺旋 RJ Ring Joint 环垫接头 RO Restriction Orifice 限流孔板 RPM *Revolutions Per Minute 转 / 分 RPS*Revolutions Per Second 转 / 秒 RS Resting Support 支承架,滑动架 RTJ Ring Type Joint (见 RJ) RV Relief Valve 安全泄液阀SS *South 南S Spring 弹簧(管架用)SAW (Automatic)Submerged Arc Wel**** 自动埋弧焊 SB Stud Bolt 双头螺栓SB Screwed Bonnet 螺纹阀盖 SC Sample Cooler 取样冷却器 SCH *Schedule 管壁厚系列号 SCRD Screwed 螺纹SEP Small end Plain 小端为平的 SET Small end Threaded 小端带螺纹 SF Semi-Finished 半光 SG Sight Glass 视镜SH Surface Hard Facing 硬质密封面SK Sketch 草图SMAW Shielded Metal Arc Wel**** 有保护的金属电弧焊 SMLS Seamless 无缝SN Swaged Nipple 异径短管SO Slip -On 滑套SOF Slip -On Fla nge 滑套法兰SPEC *Specification 规定,说明SPL Sound Pressure Lever 升压水准SQ *Square 方的,平方 SR Shout Radius 短半径SRE Short Radius Elbow 短半径弯头 SS *Stainless Steel 不锈钢 ST Steam Trap 蒸汽疏水阀STD *Standard 标准STG Small Tongue &Groove 小椎槽面 STL *Steel 钢STM Steam 蒸汽STM.TR Steam Tracing 蒸汽拌热 SUCT Suction 吸入口SV Safety Valve 安全泄气阀 SW Socket Weld 承插焊SWG Swage锻造,模锻SWMG Swing Type 旋启式 SYM Symmetrical 对称的 TT Tee 三通TE Threaded End 螺纹端 TEMP *Temperature 温度 TG Tongue &Groove 椎槽 THD *Threaded 螺纹的 THK *Thickness 厚度 TL Tangent Line 切线 TN True North 真实北向TOC Top of Concrete 混凝土北向TOP Top of pipe 管顶TOS Top of Support 支架顶面 Top of Steel 钢结构顶面 TYP Typical 典型的 UUB Union Bonnet 带活接头的阀盖 UC Union Cap 带活接头的阀帽 UN Union 活接头VV Valve 阀VAC Vacuum 真空VAR Variable 可变的VERT Vertical 垂直的VOL *Volume 卷,册,容量,体积WW *West 西WB Weld Branch 焊接支管WC Weld Cap 焊接管帽WD Width 宽度WE Weld End 焊接端WL Wel**** Line 焊接线WN Wel**** Neck 对焊法兰(颈部)WNF Weld Neck Flange 对焊法兰WP Working Pressure 工作压力W.P. Working Point 工作点 WT Wall Thickness 壁厚 Weight 重量XXH Extra Heavy 加强的,加厚的XXH Double Extra Heavy 双倍加强(厚)的XS Extra Strong 加强的XXS Double Extra Strong 双倍加强的 YYP Yield Point 屈服点编丐缩场啰文名称龙艾名称b管子及管件1.1P 管子Pipe1.2EL 弯头ElbowL2t 1 LLL 长半控缚头Long radius plb™1.2.2LLS 虬半轮弯头Short radius elbc*1.2.3亚―斜接骂犬[卜来艘弯头)Milrc oJbow1.2.4 REL 异径弯头Reducing elbow1.3T 三通TeeL 3+1 LT 斜二通LalerM t^eL3.2 RT 异径三通Reducing leeL4 K畀径管接头(大小头)Reducer1.4.1CR同心异径營接头(同心人小头丨Concentric reducer* \.A.2 ER偏心异径管接头「偏心大小头)Eccentric reducer 1.5 CPL 管箍CouplingL5. 1 FCPL 双头管箍Full couplingL5.2 HCPL 单头背箍Half couplingL 5. 3 BCPL 异径骨JS Reducing couplingL6 BU内外螺St接头Bushing1.7LN 活接头Union1.8HC 软管接头Hose coupler1.9SE圄边短节Stub end1* 10 NIP 炬节 Pipe nipple or straight nipple1.10.1SNIP 异径短节Swaged nippleLU CP 1 封头)Cap1.1? PL 堵i 箧墳〉Plug1.13BLK 肓板BlankL 13. 1 SB 8 'y-HSpectacle blind (blank)1.14RP 补强板Reinforcing pad2.法兰2.1PLG 法兰Flange2.L 1 WNF 对埠法兰Wold ing no^k [ 1 nngo2.1.2冏F 平焊法兰Slip-on flanEe2.1.3SWF 承插焊法兰Sockel weldin; flange2・ IL 4 T 螺纹法兰Threaded llangp2*1- S LJ 松套法兰Lapped joint fhinge2* L 6 IOF 显径法竺Reduc i ng Clangs2.L7 BF 法兰葢(口法二丿Blind rinngc2*2 FSF 注一磴対面Flange scaling face2.2.1FF 金平而Flat face2, 2.2RF 凸合面Raised face2T2. 3 MEF 凹凸面Male and female lace2.2.4 LF rinn徒瞪1曽畑氓2.比斤仙凸面Male face2.2. 6 RJ 环连接面Ring joint face2.N7 Tt-櫛槽iE Tnnguf* nnd gr^cive (ice2.2, H TF 挥面Tongue face2*2.9 GF 摘面Groove fnce3 •垫片3.1G 热片G般keL3.1. 1 NMG 非佥属垫片Non me la 11 ic gasket3,L L 1 AG 石棉隸:片Asbest os gasket3.LL2 RG 椽胶垫片Rubber gasket3.L 1. 3 TEG聚四龜乙烯包复塑片PUT envelop gasket3,L 2 SMG 半金属犁:片Semiiaetallic gasket3.1.2. 1 MJG 金屈ti 地片Me tn jacket gasket3.L 2. S SiG 鍵境式垫片Spiral wound gasket3. L 3 MG 金属敝片Metal Lie gasket3, L/l 1 FMS 金屈平热片Flat metallic gasket3. L, 3, 2 SMS(i 崗冊金属给片Mil id metal serraled gasket 3丄3* 3 LER透愎式金属环垫Lens ring gasket3.1.3.t OCli 八角形金属环垫Octagonal ring gasket3.1.3, 5 OVR IB圆形益属环墊Oval ring gaske t3.1. 3, fi IR/OR 内外定位环inner ring and outer ring3”L.£7 IK 内定fit环Inner ring3.1.3,8 OR 外定位环OutEr ring4 ,坚固件4.1 B 蝶栓Holt4.1.1SB 螺栓Stud bolt4.2籾*ffi母Nut4.3JB 花蓝螺母Tumbuckie4.4WSK 地阉Washer4^ 4^ 1 SWSR 弹黃呈圈Spring washer「阀门fk 1 CW |剤阀Gale va I\r p 5.2GL¥ 截止阀Globe valve。
UNDERGROUND PIPING INSTALLATION 地下管道的安装1.0 SCOPE 范围This Specification, accompanied by other applicable specifications, drawings and details, covers the requirements for field handling, storage, fabrication and installation of ferrous metallic and non-metallic underground piping systems.Wherever a difference exists between this specification and the drawings, the drawing shall govern. No deviation shall be made from this specification without written approval from ***l. In principle handling, storing and installations shall be in accordance with manufacturers instructions. This specification shall be used in conjunction with the "Combined Underground and Paving Plan", herein after called CUPP, and a package, containing standardized details, General Notes and References. 本规范,及其他适用的规范、图纸和详细资料,涵盖了铁质金属和非金属地下管道的现场搬移、储存、预制和安装的要求。
化工管道设计中英文对照1 管道组成件 Piping component1.1 管子 Pipe管子(按照配管标准规格制造的) pipe管子(不按配管标准规格制造的其他用管) tube钢管 steel pipe铸铁管 cast iron pipe衬里管 lined pipe复合管 clad pipe碳钢管 carbon steel pipe合金钢管 alloy steel pipe不锈钢 stainless steel pipe奥氏体不锈钢管 austenitic stainless steel pipe铁合金钢管 ferritic alloy steel pipe轧制钢管 wrought-steel pipe锻铁管 wrought-iron pipe无缝钢管 seamless (SMLS) steel pipe焊接钢管 welded steel pipe电阻焊钢管 electric-resistance welded steel pipe电熔(弧)焊钢板卷管 electric-fusion (arc)-welded steel-plate pipe螺旋焊接钢管 spiral welded steel pipe镀锌钢管 galvanized steel pipe热轧无缝钢管 hot-rolling seamless pipe冷拔无缝钢管 cold-drawing seamless pipe水煤气钢管 water-gas steel pipe塑料管 plastic pipe玻璃管 glass tube橡胶管 rubber tube直管 run pipe; straight pipe1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头(右向或左向) side outlet elbow (right hand or left hand) 双支管弯头(形) double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通(右向或左向) side outlet tee (right hand or 1eft hand) 异径三通(分支口为异径)reducing tee (reducing on outlet)异径三通(一个直通口为异径)reducing tee (reducing on one run)带支座三通 base tee异径三通(一个直通口及分支口为异径)reducing tee (reducing on one run and outlet)异径三通(两个直通口为异径,双头式)reducing tee (reducing on both runs, bull head)45°斜三通45° lateral45°斜三通(支管为异径)45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run) 45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通(俗称裤衩)true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通(一个分支口为异径)reducing cross (reducing on one outlet) 异径四通(一个直通口及分支口为异径) reducing cross (reducing on one run and outlet)异径四通(两个分支口为异径)reducing cross (reducing on both outlet) 异径四通(一个直通口及两个分支口为异径) reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台,插入式支管台 boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union外螺纹缩接(俗称补芯) bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple1.3 弯管 Bend预制弯管 fabricated pipe bend跨越弯管(^ 形) cross-over bend偏置弯管(~ 形) offset bend90°弯管 quarter bend环形弯管 cirele bend单侧偏置90°弯管(? 形) single offset quarter bendS形弯管“S” bend单侧偏置U形膨胀弯管(| ?形)single offset “U” bendU形弯管“U” b end双偏置U膨胀弯管double offset expansion “U” bend斜接弯管 mitre bend三节斜接弯管 3-piece mitre bend折皱弯管 corrugated bend圆度 roundness1.4 法兰 Flange (FLG)整体管法兰 integral pipe flange钢管法兰 steel pipe flange螺纹法兰 threaded flange滑套法兰(包括平焊法兰)slip-on flange (SO); slip-on welding flange 承插焊法兰 socket welding flange松套法兰 lap joint flange (LJF)对焊法兰 welding neckflange (WNF)法兰盖 blind flange, blind孔板法兰 orifice flange异径法兰 reducing flange盘座式法兰 pad type flange松套带颈法兰 loose hubbed flange焊接板式法兰 welding plate flange对焊环 welding neck collar (与stub end相似)平焊环 welding-on collar突缘短节 stub end, lap翻边端 lapped pipe end松套板式法兰 loose plate flange压力级 pressure rating, pressure rating class压力—温度等级 pressure-temperature rating法兰密封面,法兰面 flange facing突面 raised face (RF)凸面 male face (MF)凹面 female face (FMF)榫面 tongue face槽面 groove face环连接面 ring joint face全平面;满平面 flat face; full face (FF)光滑突面 smooth raised face (SRF)法兰面加工 facing finish粗糙度 roughness光滑的 smooth齿形 serrated均方根 root mean square (RMS)算术平均粗糙高度arithmetical average roughness height (AARH)配对法兰 companion-flange螺栓圆 bolt circle (B.C.)1.5 垫片 Gasket (GSKT)垫片的型式 type of gasket平垫片 flat gasket环形平垫片 flat ring gasket平金属垫片 flat metal gasket夹棉织物的橡胶 elastomer with cotton fabric insertion夹石棉织物的橡胶 elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶 elastomer with asbestos fabric insertion and with wire reinforcement无石墨压缩白石棉垫片non graphited compressed white asbestos gasket 天然白橡胶垫片 natural white rubber gasket 压缩石棉垫片 compressed asbestos class gasket浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket 夹石棉的缠绕金属垫片spiral-wound metal gasket with asbestos filler 环 inner ring外环,外定位环 outer ring波纹金属垫片 corrugated metal gasket波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted 双夹套波纹金属包石棉垫片corrugated metal double jacketed asbestos filled gasket双夹套垫片 double jacketed gasket金属包石棉平垫片 flat metal jacketed asbestos filled gasket整体金属齿形垫片 solid metal serrated gasket槽形金属垫片 grooved metal gasket环形连接金属垫片 ring joint metal gasket八角环形垫片 octagonal ring gasket椭圆环形垫片 oval ring gasket透镜式垫片 lens gasket非金属垫片 non-metallic gasket1.6 阀门 Valve1.6.1 阀门结构、零件阀轭 yoke外螺纹阀杆及阀轭 outside screw and yoke (OS & Y) 阀杆 stem 螺纹 inside screw (IS)阀轭套 yoke sleeve阀杆环 stem ring阀座 valve seat (body seat)阀座环、密封圈 seat ring整体(阀)座 integral seat堆焊(阀)座 deposited seat阀芯(包括密封圈、杆等件) trim阀盘 disc阀盘密封圈 disc seat阀体 body阀盖 bonnet阀盖衬套 bonnet bush螺纹阀帽 screw cap螺纹阀盖 screw bonnet螺栓连接的阀盖 bolted bonnet (BB) 活接阀盖(帽) union bonnet (cap) 螺栓连接的阀帽 bolted cap (BC)焊接阀盖 welded bonnet (WB)本体阀杆密封 body stem seal石棉安全密封 asbestos emenen seal 倒密封 back seal压力密封的阀盖 pressure-tight bonnet 动力操纵器 powered operator电动操纵器 electric motor operator 气动操纵器 pneumatic operator液压操纵器 hydraulic operator快速操纵器 quick-acting operator滑动阀杆 sliding stem正齿轮传动 spur gear operated伞齿轮传动 bevel gear operated扳手操作 wrench operated链轮 chain wheel手轮 hand wheel手柄 hand lever (handle)气缸(或液压缸)操纵的 cylinder operated链条操纵的 chain operated等径孔道 full bore; full port异径孔道 reducing bore, reduced port,venturi port 短型 short pattern紧凑型(小型) compact type笼式环 lantern ring压盖 gland阀杆填料 stem packing阀盖垫片 bonnet gasket升杆式(明杆) rising stem (RS)非升杆式(暗杆) non-rising stem (NRS)指示器/限位器 indicator/stopper注油器 grease injector可更换的阀座环 renewable seat ring1.6.2 常用阀(1)闸阀 gate valve平行双闸板 double disc parallel seat开口楔形闸板 split wedge挠性整体楔形闸扳 flexible solid wedge整体楔形闸板 solid wedge塞型闸阀 plug gate valve直通型闸阀 through conduit gate valve(2) 截止阀 globe valve球心型阀盘 globe type disc塞型阀盘 plug type disc可转动的阀盘 swivel disc(3) 节流闪阀 throttle valve针阀 needle valve(4) 角阀 angle valve(5) Y型阀(Y 型阀体截止阀) Y-valve (Y-body globe valve)(6) 球阀 ball valve三通球阀 3-way ball valve装有底轴的 trunnion mounted耐火型 fire safe type浮动球型 floating ball type防脱出阀杆 blowout proof stem(7) 蝶阀 butterfly valve对夹式(薄片型) wafer type凸耳式 lug type偏心阀板蝶阀offset disc burerfly valve; eccentric butterfly valve 斜阀盘蝶阀 canted disc butterfly valve连杆式蝶阀 link butterfly valve8) 柱塞阀 piston type valve(9) 旋塞阀 plug valve三通旋塞阀 three-way plug valve。
管道及配件中英文对照化工管道词汇翻译1 管道组成件Piping component1.1 管子Pipe管子(按照配管标准规格制造的) pipe管子(不按配管标准规格制造的其他用管) tube钢管steel pipe铸铁管cast iron pipe衬里管lined pipe复合管clad pipe碳钢管carbon steel pipe合金钢管alloy steel pipe不锈钢stainless steel pipe奥氏体不锈钢管austenitic stainless steel pipe铁合金钢管ferritic alloy steel pipe轧制钢管wrought-steel pipe锻铁管wrought-iron pipe无缝钢管seamless (SMLS) steel pipe焊接钢管welded steel pipe电阻焊钢管electric-resistance welded steel pipe电熔(弧)焊钢板卷管electric-fusion (arc)-welded steel-plate pipe螺旋焊接钢管spiral welded steel pipe镀锌钢管galvanized steel pipe热轧无缝钢管hot-rolling seamless pipe冷拔无缝钢管cold-drawing seamless pipe水煤气钢管water-gas steel pipe塑料管plastic pipe玻璃管glass tube橡胶管rubber tube直管run pipe; straight pipe1.2 管件Fitting弯头elbow异径弯头reducing elbow带支座弯头base elbow长半径弯头long radius elbow短半径弯头short radius elbow长半径180°弯头long radius return短半径180°弯头short radius return带侧向口的弯头(右向或左向)side outlet elbow (right hand or left hand) 双支管弯头(形)double branch elbow三通tee异径三通reducing tee等径三通straight tee带侧向口的三通(右向或左向)side outlet tee (right hand or 1eft hand)异径三通(分支口为异径)reducing tee (reducing on outlet)异径三通(一个直通口为异径)reducing tee (reducing on one run)带支座三通base tee异径三通(一个直通口及分支口为异径)reducing tee (reducing on one run and outlet)异径三通(两个直通口为异径,双头式)reducing tee (reducing on both runs, bull head) 45°斜三通45° lateral管道及配件中英文对照245°斜三通(支管为异径)45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通(俗称裤衩)true “Y”四通cross等径四通straight cross异径四通reducing cross异径四通(一个分支口为异径)reducing cross (reducing on one outlet)异径四通(一个直通口及分支口为异径)reducing cross (reducing on one run and outlet)异径四通(两个分支口为异径)reducing cross (reducing on both outlet)异径四通(一个直通口及两个分支口为异径)reducing cross (reducing on one run and both outlet)异径管reducer同心异径管concentric reducer偏心异径管eccentric reducer锻制异径管reducing swage螺纹支管台threadolet焊接支管台weldolet承插支管台sockolet弯头支管台elbolet斜接支管台latrolet镶入式支管嘴sweepolet短管支管台nipolet支管台,插入式支管台boss(以上带红线的单词已经查过,应该是行业很组合的名词,可以查得到)。
.1 管道施工方案Piping Construction Plan.1.1 工程特点Project Feature1)本装置工艺流程复杂,操作介质易燃、易爆、高温、高压,对焊接和密封件装配质量提出了严格的要求。
The process flow of the fitting is complicated,and operation medium is combustible, explosive, high temperature and high pressure. Thus, some strict requests have been put forward for the quality of welding and sealed fitting assembly.2)工艺配管中大量采用不锈钢、低温钢、合金钢材料,对焊工的技能和多面适应性及焊接过程中的质量控制要求很高。
A lot of stainless steel, low temperature steel and alloy steel material have been used during the process tubing, so welders should be skillful and have all round adaptability. and the quality control in welding process is much high.3)管道的材质、种类多,管件、阀门数量大,需采用微机进行材料管理和工程施工进度统计以保证材料供应及时、到货信息准确以及材料使用准确无误。
There are a lot of kinds of piping materials, and the number of tubes of valves is high, thus, computers should be used to control materials management and project construction schedule so as to delivery of material on time, exactness of arrival information and usage of material..1.2 总体施工方案General Construction Plan工艺管道施工采用设在现场的管道预制场进行管道预制,使用微机进行管线材料、计划和完成情况及施工过程控制管理,加强管道安装专业与其他专业的协调,按照系统优先顺序安排整个管道的施工。
1 管道组成件 Piping component1.1 管子 Pipe管子(按照配管标准规格制造的) pipe管子(不按配管标准规格制造的其他用管) tube钢管 steel pipe铸铁管 cast iron pipe衬里管 lined pipe复合管 clad pipe碳钢管 carbon steel pipe合金钢管 alloy steel pipe不锈钢 stainless steel pipe奥氏体不锈钢管 austenitic stainless steel pipe铁合金钢管 ferritic alloy steel pipe轧制钢管 wrought-steel pipe锻铁管 wrought-iron pipe无缝钢管 seamless (SMLS) steel pipe焊接钢管 welded steel pipe电阻焊钢管 electric-resistance welded steel pipe电熔(弧)焊钢板卷管 electric-fusion (arc)-welded steel-plate pipe螺旋焊接钢管 spiral welded steel pipe镀锌钢管 galvanized steel pipe热轧无缝钢管 hot-rolling seamless pipe冷拔无缝钢管 cold-drawing seamless pipe水煤气钢管 water-gas steel pipe塑料管 plastic pipe玻璃管 glass tube橡胶管 rubber tube直管 run pipe; straight pipe1.2 管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头(右向或左向) side outlet elbow (right hand or left hand) 双支管弯头(形) double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通(右向或左向) side outlet tee (right hand or 1eft hand) 异径三通(分支口为异径) reducing tee (reducing on outlet)异径三通(一个直通口为异径)reducing tee (reducing on one run)带支座三通 base tee异径三通(一个直通口及分支口为异径) reducing tee (reducing on one run and outlet)异径三通(两个直通口为异径,双头式) reducing tee (reducing on both runs, bull head)45°斜三通45° lateral45°斜三通(支管为异径)45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通(俗称裤衩)true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通(一个分支口为异径)reducing cross (reducing on one outlet) 异径四通(一个直通口及分支口为异径) reducing cross (reducing on one run and outlet)异径四通(两个分支口为异径) reducing cross (reducing on both outlet) 异径四通(一个直通口及两个分支口为异径) reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台,插入式支管台 boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union外螺纹缩接(俗称补芯) bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple1.3 弯管 Bend预制弯管 fabricated pipe bend跨越弯管(^ 形) cross-over bend偏置弯管(~ 形) offset bend90°弯管 quarter bend环形弯管 cirele bend单侧偏置90°弯管(? 形) single offset quarter bendS形弯管“S” bend单侧偏置U形膨胀弯管(| ?形)single offset “U” bendU形弯管“U” bend双偏置U膨胀弯管double offset expansion “U” bend斜接弯管 mitre bend三节斜接弯管 3-piece mitre bend折皱弯管 corrugated bend圆度 roundness1.4 法兰 Flange (FLG)整体管法兰 integral pipe flange钢管法兰 steel pipe flange螺纹法兰 threaded flange滑套法兰(包括平焊法兰) slip-on flange (SO); slip-on welding flange 承插焊法兰 socket welding flange松套法兰 lap joint flange (LJF)对焊法兰 welding neckflange (WNF)法兰盖 blind flange, blind孔板法兰 orifice flange异径法兰 reducing flange盘座式法兰 pad type flange松套带颈法兰 loose hubbed flange焊接板式法兰 welding plate flange对焊环 welding neck collar (与stub end相似)平焊环 welding-on collar突缘短节 stub end, lap翻边端 lapped pipe end松套板式法兰 loose plate flange压力级 pressure rating, pressure rating class压力—温度等级 pressure-temperature rating法兰密封面,法兰面 flange facing突面 raised face (RF)凸面 male face (MF)凹面 female face (FMF)榫面 tongue face槽面 groove face环连接面 ring joint face全平面;满平面 flat face; full face (FF)光滑突面 smooth raised face (SRF)法兰面加工 facing finish粗糙度 roughness光滑的 smooth齿形 serrated均方根 root mean square (RMS)算术平均粗糙高度 arithmetical average roughness height (AARH)配对法兰 companion-flange螺栓圆 bolt circle (B.C.)1.5 垫片 Gasket (GSKT)垫片的型式 type of gasket平垫片 flat gasket环形平垫片 flat ring gasket平金属垫片 flat metal gasket夹棉织物的橡胶 elastomer with cotton fabric insertion夹石棉织物的橡胶 elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶 elastomer with asbestos fabric insertion and with wire reinforcement无石墨压缩白石棉垫片 non graphited compressed white asbestos gasket 天然白橡胶垫片 natural white rubber gasket压缩石棉垫片 compressed asbestos class gasket浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket夹石棉的缠绕金属垫片 spiral-wound metal gasket with asbestos filler 环 inner ring外环,外定位环 outer ring波纹金属垫片 corrugated metal gasket波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted 双夹套波纹金属包石棉垫片 corrugated metal double jacketed asbestos filled gasket双夹套垫片 double jacketed gasket金属包石棉平垫片 flat metal jacketed asbestos filled gasket整体金属齿形垫片 solid metal serrated gasket槽形金属垫片 grooved metal gasket环形连接金属垫片 ring joint metal gasket八角环形垫片 octagonal ring gasket椭圆环形垫片 oval ring gasket透镜式垫片 lens gasket非金属垫片 non-metallic gasket1.6 阀门 Valve1.6.1 阀门结构、零件阀轭 yoke外螺纹阀杆及阀轭 outside screw and yoke (OS & Y) 阀杆 stem螺纹 inside screw (IS)阀轭套 yoke sleeve阀杆环 stem ring阀座 valve seat (body seat)阀座环、密封圈 seat ring整体(阀)座 integral seat堆焊(阀)座 deposited seat阀芯(包括密封圈、杆等件) trim阀盘 disc阀盘密封圈 disc seat阀体 body阀盖 bonnet阀盖衬套 bonnet bush螺纹阀帽 screw cap螺纹阀盖 screw bonnet螺栓连接的阀盖 bolted bonnet (BB)活接阀盖(帽) union bonnet (cap)螺栓连接的阀帽 bolted cap (BC)焊接阀盖 welded bonnet (WB)本体阀杆密封 body stem seal石棉安全密封 asbestos emenen seal倒密封 back seal压力密封的阀盖 pressure-tight bonnet动力操纵器 powered operator电动操纵器 electric motor operator气动操纵器 pneumatic operator液压操纵器 hydraulic operator快速操纵器 quick-acting operator滑动阀杆 sliding stem正齿轮传动 spur gear operated伞齿轮传动 bevel gear operated扳手操作 wrench operated链轮 chain wheel手轮 hand wheel手柄 hand lever (handle)气缸(或液压缸)操纵的 cylinder operated链条操纵的 chain operated等径孔道 full bore; full port异径孔道 reducing bore, reduced port,venturi port短型 short pattern紧凑型(小型) compact type笼式环 lantern ring压盖 gland阀杆填料 stem packing阀盖垫片 bonnet gasket升杆式(明杆) rising stem (RS)非升杆式(暗杆) non-rising stem (NRS)指示器/限位器 indicator/stopper注油器 grease injector可更换的阀座环 renewable seat ring1.6.2 常用阀(1)闸阀 gate valve平行双闸板 double disc parallel seat开口楔形闸板 split wedge挠性整体楔形闸扳 flexible solid wedge整体楔形闸板 solid wedge塞型闸阀 plug gate valve直通型闸阀 through conduit gate valve(2) 截止阀 globe valve球心型阀盘 globe type disc塞型阀盘 plug type disc可转动的阀盘 swivel disc(3) 节流闪阀 throttle valve针阀 needle valve(4) 角阀 angle valve(5) Y型阀(Y 型阀体截止阀) Y-valve (Y-body globe valve)(6) 球阀 ball valve三通球阀 3-way ball valve装有底轴的 trunnion mounted耐火型 fire safe type浮动球型 floating ball type防脱出阀杆 blowout proof stem(7) 蝶阀 butterfly valve对夹式(薄片型) wafer type凸耳式 lug type偏心阀板蝶阀 offset disc burerfly valve; eccentric butterfly valve 斜阀盘蝶阀 canted disc butterfly valve连杆式蝶阀 link butterfly valve8) 柱塞阀 piston type valve(9) 旋塞阀 plug valve三通旋塞阀 three-way plug valve四通旋塞阀 four-way plug valve旋塞 cock衬套旋塞 sleeve cock(10) 隔膜阀 diaphragm valve橡胶衬里隔膜阀 rubber lined diaphragm valve直通式隔膜阀 straight way diaphragm valve堰式隔膜阀 weir diaphragm valve(11) 夹紧式胶管阀 pinch valve(用于泥浆、粉尘等)(12) 止回阀 check valve升降式止回阀 lift check valve旋启式止回阀 swing check valve, flap check valve落球式止回阀 ball check valve弹簧球式止回阀 spring ball check valve双板对夹式止回阀 dual plate wafer type check valve无撞击声止回阀 non-slam cheek valve底阀 foot valve切断式止回阀 stop check valve; non-return valve活塞式止回阀 piston check valve斜翻盘止回阀 tilting disc check valve蝶式止回阀 butterfly check valve1.6.3 其它用途的阀安全泄气阀 safety valve (SV)安全泄液阀 relief valve (RV)安全泄压阀 safety relief valve杠杆重锤式 lever and weight type引导阀操纵的安全泄气阀 pilot operated safety valve复式安全泄气阀 twin type safety valve罐底排污阀 flush-bottom tank valve电磁阀 solenoid valve, solenoid operated valve电动阀 electrically operated valve, electric-motor operated valve 气动阀 pneumatic operated valve低温用阀 cryogenic service valve蒸汽疏水阀 steam trap机械式疏水阎 mechanical trap浮桶式疏水阀 open bucket trap, open top bucket trap浮球式疏水阀 float trap倒吊桶式疏水阀 inverted bucket trap自由浮球式疏水阀 loose float trap恒温式疏水阀 thermostatic trap金属膨胀式蒸汽疏水阀 metal expansion steam trap液体膨胀式蒸汽疏水阀 liquid expansion steam trap双金属膨胀式蒸汽疏水阀 bimetallic expansion steam trap压力平衡式恒温疏水阀 balanced pressure thermostatic trap热动力式疏水阀 thermodynamic trap脉冲式蒸汽疏水阀 impulse steam trap放气阀(自动放气阀) air vent valve (automatic air vent valve) (疏水阀用)平板式滑动闸阀 slab type sliding gate valve盖阀 flat valve换向阀 diverting valve, reversing valve热膨胀阀 thermo expansion valve自动关闭阀 self-closing gate valve自动排液阀 self-draining valve管道盲板阀 line-blind valve挤压阀 squeeze valve(用于泥浆及粉尘等)呼吸阀 breather valve风门、挡板 damper减压阀 pressure reducing valve, reducing valve控制阀 control valve膜式控制阀 diaphragm operated control valve执行机构 actuator背压调节阀 back pressure regulating valve差压调节阀 differential pressure regulating valve压力比例调节阀 pressure ratio regulating valve1.6.4 未指明结构(或阀型)的阀切断阀 block valve; shut-off valve; stop valve调节阀 regulating valve快开阀 quick opening valve快闭阀 quick closing valve隔断阀 isolating valve三通阀 three way valve夹套阔 jacketed valve非旋转式阀 non-rotary valve排污阀 blowdown valve集液排放阀 drip valve排液阀 drain valve放空阀 vent valve卸载阀 unloading valve排出阀 discharge valve吸入阀 suction valve多通路阀 multiport valve取样阀 sampling valve手动阀 hand-operated valve; manually operated valve锻造阀 forged valve铸造阀 cast valve(水)龙头 bibb; bib; faucet抽出液阀(小阀) bleed valve旁路阀 by-pass valve软管阀 hose valve混合阀 mixing valve破真空阀 vacuum breaker冲洗阀 flush valve第一道阀;根部阀 primary valve根部阀 root valve总管阀 header valve事故切断阀 emergency valve1.7 管道特殊件 Piping Specialty1.7.1 管道特殊件(组件)粗滤器 strainer过滤器 filter临时粗滤器(锥型) temporary strainer (cone type)y 型粗滤器 y-type strainerT型粗滤器 T-type strainer永久过滤器 permanent filter丝网粗滤器 gauze strainer洗眼器及淋浴器 eye washer and shower视镜 sight glass阻火器 flame arrester喷嘴;喷头 spray nozzle取样冷却器 sample cooler消声器 silencer膨胀节 expansion joint波纹膨胀节 bellow expansion joint单波 single bellow双波 double bellow多波 multiple bellow压力平衡式膨胀节 pressure balanced expansion带铰链膨胀节 hinged expansion joint轴向位移型膨胀节 axial movement type expansion joint自均衡膨胀节(外加强环)self-equalizing expansion joint 带接杆膨胀节 tied expansion joint万向型膨胀节 universal type expansion joint球形补偿器 ball type expansion joint填函式补偿器 slip type (packed type) expansion joint单向滑动填料函补偿器 single actionpacked slip joint1.7.2 管道特殊元件Piping Special Element软管接头 hose connection (HC)快速接头 quick coupling金属软管 metal hose橡胶管 rubber hose挠性管 flexible tube鞍形补强板 reinforcing saddles补强板 reinforcement pad特殊法兰 special flange漏斗 funnel排液环 drip ring排液漏斗 drain funnel插板 blank垫环 spacer8字盲板 spectacle blind; figure 8 blind限流孔板 restriction orifice爆破片 rupture disk法兰盖贴面 protective disc费托立克接头 victaulic coupling1.8 端部连接 End Connection法兰端 flanged end坡口端 beveled end (BE)对焊端 butt welded end平端 plain end (PE)承插焊端 socket welding end螺纹端 threaded end (TE)承口 bell end焊接端 welding end法兰连接(接头) flanged joint对焊连接(接头) butt welded joint螺纹连接,管螺纹连接 threaded joint, pipe threaded joint 锥管螺纹密封焊连接 seal-welded taper pipe threaded joint 承插焊连接(接头) socket welded joint承插连接(接头) bell and spigot joint环垫接头 ring joint (RJ)万向接头 universal joint软钎焊连接(接头) soldered joint搭接接头,松套连接 lapped joint外侧厚度切斜角 bevel for outside thickncss侧厚度切斜角 bevel for inside thickness外侧厚度切斜角 bevel for combined thickness法兰式的 flanged (FLGD).. ..对焊的 butt welded (BW)螺纹的 threaded (THD)承插焊的 socket welded (SW)小端为平的 small end plain (SEP)大端为平的 large end plain (LEP)两端平 both ends plain (BEP)小端带螺纹 small end thread (SET)大端带螺纹 large end thread (LET)两端带螺纹 both end thread (BET)一端带螺纹 one end thread (OET)支管连接 branch connection焊接支管 branch pipe welded directly to the run pipe .. .. ..。
【关键字】整体管道及配件中英文对照化工管道词汇翻译1 管道组成件Piping component1.1 管子Pipe管子(按照配管标准规格制造的) pipe管子(不按配管标准规格制造的其他用管) tube钢管steel pipe铸铁管cast iron pipe衬里管lined pipe复合管clad pipe碳钢管carbon steel pipe合金钢管alloy steel pipe不锈钢stainless steel pipe奥氏体不锈钢管austenitic stainless steel pipe铁合金钢管ferritic alloy steel pipe轧制钢管wrought-steel pipe锻铁管wrought-iron pipe无缝钢管seamless (SMLS) steel pipe焊接钢管welded steel pipe电阻焊钢管electric-resistance welded steel pipe电熔(弧)焊钢板卷管electric-fusion (arc)-welded steel-plate pipe螺旋焊接钢管spiral welded steel pipe镀锌钢管galvanized steel pipe热轧无缝钢管hot-rolling seamless pipe冷拔无缝钢管cold-drawing seamless pipe水煤气钢管water-gas steel pipe塑料管plastic pipe玻璃管glass tube橡胶管rubber tube直管run pipe; straight pipe1.2 管件Fitting弯头elbow异径弯头reducing elbow带支座弯头base elbow长半径弯头long radius elbow短半径弯头short radius elbow长半径180°弯头long radius return短半径180°弯头short radius return带侧向口的弯头(右向或左向)side outlet elbow (right hand or left hand) 双支管弯头(形)double branch elbow三通tee异径三通reducing tee等径三通straight tee带侧向口的三通(右向或左向)side outlet tee (right hand or 1eft hand)异径三通(分支口为异径)reducing tee (reducing on outlet)异径三通(一个直通口为异径)reducing tee (reducing on one run)带支座三通base tee异径三通(一个直通口及分支口为异径)reducing tee (reducing on one run and outlet)异径三通(两个直通口为异径,双头式)reducing tee (reducing on both runs, bull head) 45°斜三通45° lateral管道及配件中英文对照245°斜三通(支管为异径)45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通(俗称裤衩)true “Y”四通cross等径四通straight cross异径四通reducing cross异径四通(一个分支口为异径)reducing cross (reducing on one outlet)异径四通(一个直通口及分支口为异径)reducing cross (reducing on one run and outlet)异径四通(两个分支口为异径)reducing cross (reducing on both outlet)异径四通(一个直通口及两个分支口为异径)reducing cross (reducing on one run and both outlet)异径管reducer同心异径管concentric reducer偏心异径管eccentric reducer锻制异径管reducing swage螺纹支管台threadolet焊接支管台weldolet承插支管台sockolet弯头支管台elbolet斜接支管台latrolet镶入式支管嘴sweepolet短管支管台nipolet支管台,插入式支管台boss(以上带红线的单词已经查过,应该是行业很组合的名词,可以查得到)。
管道安装-中英对照6 管道施工方案Construction Schemes for Piping Works6.1概述General Statement乙烯装置一标段的管道施工,主要是裂解区、急冷区、压缩二区、裂解汽油加氢区和废碱处理区管道安装。
管道安装工程量91034米,管道材质有碳钢、低温钢、不锈钢及铬钼合金钢,管道安装的主要工程量见表1。
The construction of the piping works for the tendered Works I in the ethylene complex covers mainly the piping installation for the cracking heater area, quench area, compression area 2#, pyrolysis gasoline hydrogenation area and the spent alkali treatment area. The quantity for the piping installation works amounts are about 91,034 meters and the involved construction materials of the piping include carbon steel, low temperature steel, stainless steel as well as chrome-molybdenum alloy steel. For the major quantity of piping installation works, refer to Table 1.一标段管道工程量表1Table 1 Quantity of Piping Installation for Tendered Works I方案编制依据:Basis of the Schemes Preparation——SECCO提供招标文件中的技术资料和标准规范;Technical Information and standards and codes provided in SECCO’s bid inviting documents;——国内的有关标准和相应的施工及验收规范;Applicable national standards and the relevant construction and acceptance specification;——我公司在其他乙烯工程施工的经验。
1 管道组成件 Piping component管子 Pipe管子(按照配管标准规格制造的) pipe管子(不按配管标准规格制造的其他用管) tube钢管 steel pipe铸铁管 cast iron pipe衬里管 lined pipe复合管 clad pipe碳钢管 carbon steel pipe合金钢管 alloy steel pipe不锈钢 stainless steel pipe奥氏体不锈钢管 austenitic stainless steel pipe铁合金钢管 ferritic alloy steel pipe轧制钢管 wrought-steel pipe锻铁管 wrought-iron pipe无缝钢管 seamless (SMLS) steel pipe焊接钢管 welded steel pipe电阻焊钢管 electric-resistance welded steel pipe电熔(弧)焊钢板卷管 electric-fusion (arc)-welded steel-plate pipe螺旋焊接钢管 spiral welded steel pipe镀锌钢管 galvanized steel pipe热轧无缝钢管 hot-rolling seamless pipe冷拔无缝钢管 cold-drawing seamless pipe水煤气钢管 water-gas steel pipe塑料管 plastic pipe玻璃管 glass tube橡胶管 rubber tube直管 run pipe; straight pipe管件 Fitting弯头 elbow异径弯头 reducing elbow带支座弯头 base elbowk半径弯头 long radius elbow短半径弯头 short radius elbow长半径180°弯头 long radius return短半径180°弯头 short radius return带侧向口的弯头(右向或左向) side outlet elbow (right hand or left hand) 双支管弯头(形) double branch elbow三通 tee异径三通 reducing tee等径三通 straight tee带侧向口的三通(右向或左向) side outlet tee (right hand or 1eft hand) 异径三通(分支口为异径) reducing tee (reducing on outlet)异径三通(一个直通口为异径)reducing tee (reducing on one run)带支座三通 base tee异径三通(一个直通口及分支口为异径) reducing tee (reducing on one run and outlet)异径三通(两个直通口为异径,双头式) reducing tee (reducing on both runs, bull head)45°斜三通45° lateral45°斜三通(支管为异径)45° lateral (reducing on branch)45°斜三通(一个直通口为异径) 45° lateral (reducing on one run)45°斜三通(一个直通口及支管为异径) 45° lateral (reducing on one run and branch)Y型三通(俗称裤衩)true “Y”四通 cross等径四通 straight cross异径四通 reducing cross异径四通(一个分支口为异径)reducing cross (reducing on one outlet) 异径四通(一个直通口及分支口为异径) reducing cross (reducing on one run and outlet)异径四通(两个分支口为异径) reducing cross (reducing on both outlet) 异径四通(一个直通口及两个分支口为异径) reducing cross (reducing on one run and both outlet)异径管 reducer同心异径管 concentric reducer偏心异径管 eccentric reducer锻制异径管 reducing swage螺纹支管台 threadolet焊接支管台 weldolet承插支管台 sockolet弯头支管台 elbolet斜接支管台 latrolet镶入式支管嘴 sweepolet短管支管台 nipolet支管台,插入式支管台 boss管接头 coupling, full coupling半管接头 half coupling异径管接头 reducing coupling活接头 union内外螺纹缩接(俗称补芯) bushing管帽 cap (C)堵头 plug短节 nipple异径短节 reducing nipple; swage nipple弯管 Bend预制弯管 fabricated pipe bend跨越弯管(^ 形) cross-over bend偏置弯管(~ 形) offset bend90°弯管 quarter bend环形弯管 cirele bend单侧偏置90°弯管(形) single offset quarter bendS形弯管“S” bend单侧偏置U形膨胀弯管(| 形)single offset “U” bendU形弯管“U” bend双偏置U膨胀弯管double offset expansion “U” bend斜接弯管 mitre bend三节斜接弯管 3-piece mitre bend折皱弯管 corrugated bend圆度 roundness法兰 Flange (FLG)整体管法兰 integral pipe flange钢管法兰 steel pipe flange螺纹法兰 threaded flange滑套法兰(包括平焊法兰) slip-on flange (SO); slip-on welding flange 承插焊法兰 socket welding flange松套法兰 lap joint flange (LJF)对焊法兰 welding neckflange (WNF)法兰盖 blind flange, blind孔板法兰 orifice flange异径法兰 reducing flange盘座式法兰?? pad type flange松套带颈法兰 loose hubbed flange焊接板式法兰?? welding plate flange对焊环 welding neck collar (与stub end相似)平焊环 welding-on collar突缘短节 stub end, lap翻边端 lapped pipe end松套板式法兰 loose plate flange压力级 pressure rating, pressure rating class压力—温度等级 pressure-temperature rating法兰密封面,法兰面 flange facing突面 raised face (RF)凸面 male face (MF)凹面 female face (FMF)榫面 tongue face槽面 groove face环连接面 ring joint face全平面;满平面 flat face; full face (FF)光滑突面 smooth raised face (SRF)法兰面加工 facing finish粗糙度 roughness光滑的 smooth齿形 serrated均方根 root mean square (RMS)算术平均粗糙高度 arithmetical average roughness height (AARH)配对法兰 companion-flange螺栓圆 bolt circle .)垫片 Gasket (GSKT)垫片的型式 type of gasket平垫片 flat gasket环形平垫片 flat ring gasket平金属垫片 flat metal gasket夹棉织物的橡胶 elastomer with cotton fabric insertion夹石棉织物的橡胶 elastomer with asbestos fabric insertion夹石棉织物及金属丝加强的橡胶 elastomer with asbestos fabric insertion and with wire reinforcement无石墨压缩白石棉垫片 non graphited compressed white asbestos gasket 天然白橡胶垫片 natural white rubber gasket压缩石棉垫片 compressed asbestos class gasket浸聚四氟乙烯的石棉垫片 PTFE impregnated asbestos gasket夹石棉的缠绕金属垫片 spiral-wound metal gasket with asbestos filler 内环 inner ring外环,外定位环 outer ring波纹金属垫片 corrugated metal gasket波纹金属包嵌石棉垫片 corrugated metal gasket with asbestos inserted 双夹套波纹金属包石棉垫片 corrugated metal double jacketed asbestos filled gasket双夹套垫片 double jacketed gasket金属包石棉平垫片 flat metal jacketed asbestos filled gasket整体金属齿形垫片 solid metal serrated gasket槽形金属垫片 grooved metal gasket环形连接金属垫片 ring joint metal gasket八角环形垫片 octagonal ring gasket椭圆环形垫片 oval ring gasket透镜式垫片 lens gasket非金属垫片 non-metallic gasket阀门 Valve阀门结构、零件阀轭 yoke外螺纹阀杆及阀轭 outside screw and yoke (OS & Y) 阀杆 stem内螺纹 inside screw (IS)阀轭套 yoke sleeve阀杆环 stem ring阀座 valve seat (body seat)阀座环、密封圈 seat ring整体(阀)座 integral seat堆焊(阀)座 deposited seat阀芯(包括密封圈、杆等内件) trim阀盘 disc阀盘密封圈 disc seat阀体 body阀盖 bonnet阀盖衬套 bonnet bush螺纹阀帽 screw cap螺纹阀盖 screw bonnet螺栓连接的阀盖 bolted bonnet (BB)活接阀盖(帽) union bonnet (cap)螺栓连接的阀帽 bolted cap (BC)焊接阀盖 welded bonnet (WB)本体阀杆密封 body stem seal石棉安全密封 asbestos emenen seal倒密封 back seal压力密封的阀盖 pressure-tight bonnet动力操纵器 powered operator电动操纵器 electric motor operator气动操纵器 pneumatic operator液压操纵器 hydraulic operator快速操纵器 quick-acting operator滑动阀杆 sliding stem正齿轮传动 spur gear operated伞齿轮传动 bevel gear operated扳手操作 wrench operated链轮 chain wheel手轮 hand wheel手柄 hand lever (handle)气缸(或液压缸)操纵的 cylinder operated链条操纵的 chain operated等径孔道 full bore; full port异径孔道 reducing bore, reduced port,venturi port短型 short pattern紧凑型(小型) compact type笼式环 lantern ring压盖 gland阀杆填料 stem packing阀盖垫片 bonnet gasket升杆式(明杆) rising stem (RS)非升杆式(暗杆) non-rising stem (NRS)指示器/限位器 indicator/stopper注油器 grease injector可更换的阀座环 renewable seat ring常用阀(1)闸阀 gate valve平行双闸板 double disc parallel seat开口楔形闸板 split wedge挠性整体楔形闸扳 flexible solid wedge整体楔形闸板 solid wedge塞型闸阀 plug gate valve直通型闸阀 through conduit gate valve(2) 截止阀 globe valve球心型阀盘 globe type disc塞型阀盘 plug type disc可转动的阀盘 swivel disc(3) 节流闪阀 throttle valve针阀 needle valve(4) 角阀 angle valve(5) Y型阀(Y 型阀体截止阀) Y-valve (Y-body globe valve)(6) 球阀 ball valve三通球阀 3-way ball valve装有底轴的 trunnion mounted耐火型 fire safe type浮动球型 floating ball type防脱出阀杆 blowout proof stem(7) 蝶阀 butterfly valve对夹式(薄片型) wafer type凸耳式 lug type偏心阀板蝶阀 offset disc burerfly valve; eccentric butterfly valve 斜阀盘蝶阀 canted disc butterfly valve连杆式蝶阀 link butterfly valve8) 柱塞阀 piston type valve(9) 旋塞阀 plug valve三通旋塞阀 three-way plug valve四通旋塞阀 four-way plug valve旋塞 cock衬套旋塞 sleeve cock(10) 隔膜阀 diaphragm valve橡胶衬里隔膜阀 rubber lined diaphragm valve直通式隔膜阀 straight way diaphragm valve堰式隔膜阀 weir diaphragm valve(11) 夹紧式胶管阀 pinch valve(用于泥浆、粉尘等)(12) 止回阀 check valve升降式止回阀 lift check valve旋启式止回阀 swing check valve, flap check valve落球式止回阀 ball check valve弹簧球式止回阀 spring ball check valve双板对夹式止回阀 dual plate wafer type check valve无撞击声止回阀 non-slam cheek valve底阀 foot valve切断式止回阀 stop check valve; non-return valve活塞式止回阀 piston check valve斜翻盘止回阀 tilting disc check valve蝶式止回阀 butterfly check valve其它用途的阀安全泄气阀 safety valve (SV)安全泄液阀 relief valve (RV)安全泄压阀 safety relief valve杠杆重锤式 lever and weight type引导阀操纵的安全泄气阀 pilot operated safety valve复式安全泄气阀 twin type safety valve罐底排污阀 flush-bottom tank valve电磁阀 solenoid valve, solenoid operated valve电动阀 electrically operated valve, electric-motor operated valve 气动阀 pneumatic operated valve低温用阀 cryogenic service valve蒸汽疏水阀 steam trap机械式疏水阎 mechanical trap浮桶式疏水阀 open bucket trap, open top bucket trap浮球式疏水阀 float trap倒吊桶式疏水阀 inverted bucket trap自由浮球式疏水阀 loose float trap恒温式疏水阀 thermostatic trap金属膨胀式蒸汽疏水阀 metal expansion steam trap液体膨胀式蒸汽疏水阀 liquid expansion steam trap双金属膨胀式蒸汽疏水阀 bimetallic expansion steam trap压力平衡式恒温疏水阀 balanced pressure thermostatic trap热动力式疏水阀 thermodynamic trap脉冲式蒸汽疏水阀 impulse steam trap放气阀(自动放气阀) air vent valve (automatic air vent valve) (疏水阀用)平板式滑动闸阀 slab type sliding gate valve盖阀 flat valve换向阀 diverting valve, reversing valve热膨胀阀 thermo expansion valve自动关闭阀 self-closing gate valve自动排液阀 self-draining valve管道盲板阀 line-blind valve挤压阀 squeeze valve(用于泥浆及粉尘等)呼吸阀 breather valve风门、挡板 damper减压阀 pressure reducing valve, reducing valve控制阀 control valve膜式控制阀 diaphragm operated control valve执行机构 actuator背压调节阀 back pressure regulating valve差压调节阀 differential pressure regulating valve压力比例调节阀 pressure ratio regulating valve未指明结构(或阀型)的阀切断阀 block valve; shut-off valve; stop valve调节阀 regulating valve快开阀 quick opening valve快闭阀 quick closing valve隔断阀 isolating valve三通阀 three way valve夹套阔 jacketed valve非旋转式阀 non-rotary valve排污阀 blowdown valve集液排放阀 drip valve排液阀 drain valve放空阀 vent valve卸载阀 unloading valve排出阀 discharge valve吸入阀 suction valve多通路阀 multiport valve取样阀 sampling valve手动阀 hand-operated valve; manually operated valve锻造阀 forged valve铸造阀 cast valve(水)龙头 bibb; bib; faucet抽出液阀(小阀) bleed valve旁路阀 by-pass valve软管阀 hose valve混合阀 mixing valve破真空阀 vacuum breaker冲洗阀 flush valve第一道阀;根部阀 primary valve根部阀 root valve总管阀 header valve事故切断阀 emergency valve管道特殊件 Piping Specialty管道特殊件(组件)粗滤器 strainer过滤器 filter临时粗滤器(锥型) temporary strainer (cone type)y 型粗滤器 y-type strainerT型粗滤器 T-type strainer永久过滤器 permanent filter丝网粗滤器 gauze strainer洗眼器及淋浴器 eye washer and shower视镜 sight glass阻火器 flame arrester喷嘴;喷头 spray nozzle取样冷却器 sample cooler消声器 silencer膨胀节 expansion joint波纹膨胀节 bellow expansion joint单波 single bellow双波 double bellow多波 multiple bellow压力平衡式膨胀节 pressure balanced expansion带铰链膨胀节 hinged expansion joint轴向位移型膨胀节 axial movement type expansion joint自均衡膨胀节(外加强环)self-equalizing expansion joint 带接杆膨胀节 tied expansion joint万向型膨胀节 universal type expansion joint球形补偿器 ball type expansion joint填函式补偿器 slip type (packed type) expansion joint单向滑动填料函补偿器 single actionpacked slip joint管道特殊元件Piping Special Element软管接头 hose connection (HC)快速接头 quick coupling金属软管 metal hose橡胶管 rubber hose挠性管 flexible tube鞍形补强板 reinforcing saddles补强板 reinforcement pad特殊法兰 special flange漏斗 funnel排液环 drip ring排液漏斗 drain funnel插板 blank垫环 spacer8字盲板 spectacle blind; figure 8 blind限流孔板 restriction orifice爆破片 rupture disk法兰盖贴面 protective disc费托立克接头 victaulic coupling端部连接 End Connection法兰端 flanged end坡口端 beveled end (BE)对焊端 butt welded end平端 plain end (PE)承插焊端 socket welding end螺纹端 threaded end (TE)承口 bell end焊接端 welding end法兰连接(接头) flanged joint对焊连接(接头) butt welded joint螺纹连接,管螺纹连接 threaded joint, pipe threaded joint 锥管螺纹密封焊连接 seal-welded taper pipe threaded joint 承插焊连接(接头) socket welded joint承插连接(接头) bell and spigot joint环垫接头 ring joint (RJ)万向接头 universal joint软钎焊连接(接头) soldered joint搭接接头,松套连接 lapped joint外侧厚度切斜角 bevel for outside thickncss内侧厚度切斜角 bevel for inside thickness内外侧厚度切斜角 bevel for combined thickness法兰式的 flanged (FLGD)对焊的 butt welded (BW)螺纹的 threaded (THD)承插焊的 socket welded (SW)小端为平的 small end plain (SEP)大端为平的 large end plain (LEP)两端平 both ends plain (BEP)小端带螺纹 small end thread (SET)大端带螺纹 large end thread (LET)两端带螺纹 both end thread (BET)一端带螺纹 one end thread (OET)支管连接 branch connection焊接支管 branch pipe welded directly to the run pipe。
管道方案(中英文对照版)一、项目背景随着我国经济的快速发展,基础设施建设的步伐不断加快,管道系统的需求也日益增长。
本项目旨在为某大型工业园区提供一套完整、高效的管道系统方案,以满足园区内各企业的生产需求。
1.ProjectBackgroundWiththerapiddevelopmentofChina'seconomyandtheacceleratio nofinfrastructureconstruction,thedemandforpipelinesystemsco ntinuestogrow.Thisprojectmstoprovideapleteandefficientpipel inesystemsolutionforalargeindustrialparktomeettheproduction needsofvariousenterpriseswithinthepark.二、项目目标1.提高管道系统的运行效率,降低能耗;2.确保管道系统的安全稳定,降低故障率;3.提升管道系统的智能化水平,便于维护和管理;4.节约成本,提高投资回报率。
2.ProjectObjectives1.Improvetheoperatingefficiencyofthepipelinesystem,reduc eenergyconsumption;2.Ensurethesafetyandstabilityofthepipelinesystem,reducet heflurerate;3.Enhancetheintelligencelevelofthepipelinesystem,facilitatemntenanceandmanagement;4.Savecosts,improvereturnoninvestment.三、方案设计1.管道材料选择(2)不锈钢管:具有优异的耐腐蚀性能,适用于腐蚀性介质;(3)塑料管:重量轻、安装方便,适用于低压、低温等工况。
管道工程施工质量管理工作细则PIPING CONSTRUCTION QUALITY MANAGEMENT DETAIL RULES目录Content1.0 编制目的及适用范围Purpose for Preparation and Scope of Application2.0 编制原则Principles for Preparation3.0执行标准及有关规定Applicable Standards and Relevant Regulations3.1 中国政府的相关法规和政策Relevant laws, regulations and policies issued by Chinese government: 3.2 SECCO项目IPMT质量体系有关文件Documentation related to IPMT quality system of SECCO project: 3.3 SECCO项目IPMT规定和要求IPMT regulations and requirements of SECCO project:3.4 施工验收标准及规范Standards and codes for construction acceptance:4.0 冲突和协调Conflict and Coordination5.0 专业技术经理与专业工程师Specialist Technical Manager and Specialist Engineer5.1专业技术经理Specialist technical manager5.2 专业工程师Specialist engineer6.0 HSE7.0 施工过程中工程施工质量的控制Quality Control in the Process of Construction7.1 主要依据Main basis7.2 熟悉现场管理体系、建立工作接口Acquaintance with site management system and establishment ofworking interface7.3 技术准备Technical Preparations7.4 组织设计交底Organization Design Briefing7.5 图纸与设计文件会审Joint Check-up of Drawings and Design Documents7.6 审查施工组织设计和施工方案Check-up of Construction Organization Design and Construction Plan 7.7 施工过程的质量控制点的制定和检查程序Procedures for the Establishment and Inspection of Quality ControlPoints in the Construction Process7.8 施工过程中的质量控制Quality Control During the Construction Process7.8.1 原材料的检查与验收原则Principles for the Inspection and Verification of Raw Materials7.8.2 管子抽检的内容和比例Contents and Percentage of Pipe Spot-check7.8.3 其他管道组成件抽检的内容和比例Spot-check Contents and Percentage of Other Pipe Components7.8.4 阀门的检验与试验(包括管道视镜、过滤器及阻火器检验)Valve Inspection and Experiment (Including the inspection of pipe signtglass, strainer and flame arrestor)7.8.5 采用的主要管道器材标准(规范)Major Piping Specifications Standards (or codes)7.8.5.1 材料标准Material Standards7.8.5.1.1 无缝钢管Seamless Steel Pipe7.8.5.1.2 焊接钢管Welded Steel Pipe7.8.5.1.3 管件Pipe fittings7.8.5.1.4 联接件Pipe joints7.8.5.1.5 阀门Valves7.8.5.2 应用规范Application specification7.8.5.2.1 管子Pipe7.8.5.2.2 管件Pipe fittings7.8.5.2.3 联接件Pipe joints7.8.5.2.4 阀门Valves7.8.6 管道防腐Pipingcorrosion prevention7.8.7 管道的预制加工工艺Pre-fabrication process for pipe7.8.8 碳素钢管道焊接、热处理及质量检查Welding, heat treatment and quality inspection for carbon steel pipe 7.8.9 阀门安装Valve installation7.8.10 低温材料检验及安装Cryogenic material inspection and installation7.8.11 静电接地安装Static grounding erection7.8.12 管道系统试验、吹除与清洗Test, purging and cleaning for piping system7.8.13 工程中间交接Engineering intermediate takeover7.8.14 竣工验收Completion acceptance7.9 专业工程师应保存的资料Documents to be retained by specialist engineer附录1: 管道安装工程质量控制点Appendix 1 Quality Control Points for Piping Installation Project附录2:工业管道施工管理台帐Appendix 2 I ndustrial Piping Construction Management Record Book1.0编制目的及适用范围:Purpose for Preparation and Scope of Application1.1 本规定适用于上海SECCO 90x104t/a乙烯项目(以下简称SECCO项目)的现场施工质量管理工作。
These stipulations are applicable to the site construction quality management of Shanghai SECCO 90x104t/a Ethene Project (hereinafter referred to as SECCOproject).1.2 本规定是为了明确SECCO项目的现场施工质量管理工作的职责、工作内容、工作流程、方法以及设计、采购、施工的协调,推行现代化、科学化、规范化的项目管理模式而编制的。
These stipulations are prepared for the purpose of defining the responsibilities, working contents, operating process and procedures for the site constructionquality management of the SECCO project and for coordination among thedesign, procurement and construction, so as to pursue the modernized, scientific and standardized mode for project management.2.0 编制原则Principles for Preparation2.1 本细则在项目质量管理目标合理分解、项目质量管理组织已经确立的前提下,以项目的规律效应性和操作实用性为原则编制的。
These rules are prepared on the principle of the law effectiveness and operating practicability of the project, under the precondition that the objectives of theproject quality management have been reasonably decomposed and theorganization of project quality management has been established.2.2 本细则注意到质量检验评定中工程划分与WBS分解结构在施工管理中的内在联系,我们强调将两者的划分尽量统一。
These rules have given full attention to the inherent links between the projectcomponent division in the quality inspection and evaluation and WBSdecomposed structure in the construction management. We emphasize that the two divisions should be unified as far as possible.2.3为加强主动控制的力度,本细则建议建立专业施工管理台帐,将施工质量控制纳入现场施工管理体系,专业工程师应参加重要的材料和设备的招标订货会议,了解产品质量、合同技术要求、厂家售后服务及到货情况。
以便在施工管理台帐中列出每月到货清单,使材料报检及工程报检工作系统化。
In order to strengthen the power of active control, it is recommended by theserules that a specialized construction management record book is established tointegrate the construction quality control into site construction managementsystem. It is also suggested that specialist engineers should participate in thebidding and ordering meetings for important materials and equipment to getacquainted with the product quality, the technical requirements of the contract, after-sale service provided by manufacturer and the deliverystatus. And then it is possible to put the monthly goods-arrival list in theconstruction management record book and to realize the systematization ofmaterial acceptance and engineering inspection procedures.3.0执行标准及有关规定Applicable Standards and Relevant Regulations3.1 中国政府的相关法规和政策:Relevant laws, regulations and policies issued by Chinese government:压力管道安全管理和监察规程Regulations for Pressure Piping Safety Management and Supervision压力管道安装安全质量监督检验规则Rules for Pressure Piping Installation Safety and Quality Supervision andInspection3.2 SECCO项目IPMT质量体系有关文件:Documentation related to IPMT quality system of SECCO project:规划管理计划(PMP) PL-00-IIJ-PM-0001Program Management Plan (PMP)质量管理策略ST-00-IIJ-QU-0001Quality Management Strategy质量管理组织体系PL-00-IIJ-QU-0002Quality Management Organization System工程质量管理规定PR-00-CIJ-QU-0001Regulations for Project Quality Management质量审核程序PR-00-IIJ-QU-0001Quality Check Procedures承包商质量(QA/QC)标准SD-00-IIJ-QU-0001Quality Assurance/Quality Control (QA/QC) Standard for Contractors施工管理细则Construction Management Detail Rules3.3 SECCO项目IPMT规定和要求:IPMT regulations and requirements of SECCO project:装置布置原则PH-00-TSC-PP-0001Plant Layout Philosophy管道材料规定SD-00-TSC-PP-0001Specifications for Piping Materials工艺及公用工程管道设计要求SD-00-TSC-PP-0002Process and Utility Piping Design Requirements地下钢管涂层及包覆标准SD-00-TSC-PP-0003Standard for Coating and Wrapping of Underground Steel Pipe管道制作SD-00-TSC-PP-0004Fabrication of Piping蒸汽伴热管要求SD-00-TSC-PP-0005Steam Tracing Piping Requirements管道支撑标准SD-00-TSC-PP-0007Standard for Piping Support管道柔性--设计标准SD-00-TSC-PP-0008Piping Flexibility—Design Criteria管道的现场试压SD-00-TSC-PP-0009Field Pressure Testing of Piping隔离材料及应用—热保温SD-00-TSC-PP-0010Insulation Materials & Application ------Hot Service隔离材料及应用—冷保温SD-00-TSC-PP-0011Insulation Materials& Application------Cold Service管道及设备的隔音保护SD-00-TSC-PP-0012Sound ControlInsulation of Piping and Equipment标准详图SD-00-TSC-PP-0013Standard Detail Drawing管道焊接标准SD-00-TSC-MS-0025Standard for Piping Welding3.4 施工验收标准及规范:Standards and codes for construction acceptance:石油化工剧毒、可燃介质管道工程施工及验收规范SH3501-2001 Specification for Construction and Acceptance of Hypertoxic and Combustible Medium Piping Engineering in Petrochemical Industry工业金属管道工程施工及验收规范GB50235-97 Code for Construction and Acceptance of Industrial Metallic Piping现场设备、工业管道焊接工程施工及验收规范GB50236-98 Code for Construction and Acceptance of Field Equipment and Industrial PipingWecontractorng工业安装工程质量检验评定统一标准GB50252-94Unified Standard for Checking and Evaluating the Quality of Industrial Installation Engineering工业金属管道工程质量检验评定标准GB50184-93 Standard for Checking and Evaluating the Quality of Industrial Metallic Piping Engineering工业管道、设备绝热工程施工及验收规范GBJ126-89C ode for Construction and Acceptance of Industrial Piping andEquipmentThermalInsulationEngineering石油化工工程焊接工艺评定SHJ509-88 Welding ProcedureQualification for Petrochemical Engineering石油化工钢制管道工程施工工艺标准SH3517-2001Construction Process Standard for Petrochemical Steel Piping Engineering阀门检验与管理规程SH3518-2000 Code forValve Inspection and Management石油化工钢制通用阀门选用、检验及验收SH3064-94 Selection, Inspection and Acceptance of Petrochemical General Steel Valves石油化工设备和管道涂料防腐蚀技术规范SH3022-1999 Technical Specification forthe Coating anticorrosion of Equipment and Piping in Petrochemical Industry石油化工企业设备管道表面色和标志SH3043-91 Equipment and Piping Surface Color and Marking for Petrochemical Industry 埋地钢质管道石油沥青防腐层施工及验收规范SYJ4020-88 Code for Construction and Acceptance of Petroleum Asphalt CorrosionProtection Layer for Undergrand Steel Piping工艺管道ASME B31.3-2002 Process Piping无损检测ASME Section V Nondestructive Examination焊接和钎焊评定ASME Section IXWelding and Brazing Qualification阀门检验及试验API Std 598Valve Inspection and Testing4.0冲突与协调Conflict and Coordination中国政府法规、SECCO项目规定、标准和规范(包括国内的和国外的): Laws and regulations issued by Chinese government and the stipulations, standards and codes of SECCO project (including home and foreign ones): 当在项目执行过程中,中国政府法规、SECCO项目规定及标准、规范间有矛盾时,执行的顺序应当是:中国政府法规、SECCO项目规定、标准和规范要求。
