在allegro中设置PADS常用的快捷键方法
把ENV文件复制到目录C:\\Cadence\\SPB_16.3\\share\\pcb\\text 替换就OK
ENV文件内容：
#
# ALLEGRO GLOBAL Environment file
#
# The following variables are set by the software if not preset by user:
# CDS_SITE, ALLEGRO_SITE, TELENV, ALLEGRO_INSTALL_DIR,
# ALLEGRO_INSTALL_TOOLS, ALLEGRO_INSTALL_ROOT, ALLEGRO_TYPE,
# __UNIX (if UNIX), _PROGRAM, HOME
#
# You may set the Operating System variable:
# ALLEGRO_PCBENV
# to overwrite the default of the user's pcbenv directory. This variable
# must be set at the OS level and has no effect if set in an Allegro env file. # The directory given must exist. If no directory is found the system will
# fallback to its default location.
#
# The following variables are preset at startup, direct settings in env
# files will be overridden
# LOCALENV: seeded based upon /pcbenv (or if set ALLEGRO_PCBENV)
# LOCALPATH: seeded based upon . LOCALENV, ALLEGRO_SITE, GLOBALPATH
# Variable names are case insensitive
#--------------------------------------------------------------------
# System Variables
set GLOBAL = $ALLEGRO_INSTALL_DIR/text
# change from LIBPATH because it conflicts with IBM's shared library
# environment variable
set ALIBPATH = $ALLEGRO_INSTALL_DIR/pcb_lib
set COMPLIBPATH = $ALLEGRO_INSTALL_DIR/allegrolib
set GLOBALPATH = . $GLOBAL
# Allegro Data Services Variable
set ADSPATH = $GLOBALPATH
# Present for compatiblity with older versions of Allegro.
ifnvar ALLEGRO_SITE "set ALLEGRO_SITE ."
ifnvar CDSPLAT "set CDSPLAT "
ifnvar ALLEGRO_INSTALL_DLL "set ALLEGRO_INSTALL_DLL "
#--------------------------------------------------------------------
# Configuration variables (Don't change)
set BMPPATH = . $ALLEGRO_SITE/icons $GLOBAL/icons
set FORMPATH = . $ALLEGRO_SITE/forms $GLOBAL/forms
set MENUPATH = . $ALLEGRO_SITE/menus $GLOBAL/cuimenus
set MATERIALPATH = . $LOCALENV $ALLEGRO_SITE $GLOBAL
#Configuration paths
set PRFEDITPATH = . $LOCALENV/configure/prfedit $ALLEGRO_SITE/configure/prfedit $ALLEGRO_INSTALL_DIR/configure/prfedit
set BATCHHELPPATH = . $ALLEGRO_INSTALL_DIR/batchhelp
set SPROUTEPATH = $ALLEGRO_INSTALL_DIR/configure/sproute
set HELPPATH = . $ALLEGRO_INSTALL_DIR/help $GLOBAL/help
set PDFPATH = . $ALLEGRO_INSTALL_DIR/help/pdf
# Graphics demo env
set IMAGEPATH = . $ALLEGRO_INSTALL_DIR/examples/image
# Allegro Plugin search path
set AXLPLUGINPATH = . $LOCALENV/$CDSPLAT $ALLEGRO_SITE/$CDSPLAT $ALLEGRO_INSTALL_DLL
#--------------------------------------------------------------------
# Drawing font
set VECTORFONTPATH = . $GLOBAL
set ANSIFONT = ansifont
set KANJIFONTPATH = . $GLOBAL/fonts/kanji
set KANJIFONT1 = kanjifont1
set KANJIFONT2 = kanjifont2
#--------------------------------------------------------------------
# Display Variables
set display_backingstore on
# disable repair under ratsnests
set display_shapefill_analysis 1
