UBOOT从NAND FLASH启动分析UBOOT从NAND FLASH启动分析在分析启动代码之前先看一下S3C2440的NAND启动:在配置NAND启动模式之后,S3C2440上电会先将NAND中的0x0 - 0x1000共4096字节的数据拷贝到位于Bank0中的Boot Internal SRAM上Bank0如下图:可以看出Boot Internal SRAM为4KB大小,也正是因为Boot Internal SRAM只有4KB 大小,所以只能从NAND中拷贝4K的内容= 3= 这个Boot Internal SRAM是配置为NAND FLASH启动模式才有的这4K内容是什么呢?~ 这就要看Uboot的镜像文件中是如何进行连接的了~连接脚本在board/smdk2440/u-boot.lds中,如下SECTIONS{. = 0x00000000;. = ALIGN(4);.text :{cpu/arm920t/start.o (.text)cpu/arm920t/s3c24x0/nand_read.o (.text)*(.text)}. = ALIGN(4);.rodata : { *(.rodata) }. = ALIGN(4);.data : { *(.data) }. = ALIGN(4);.got : { *(.got) }. = .;__u_boot_cmd_start = .;.u_boot_cmd : { *(.u_boot_cmd) }__u_boot_cmd_end = .;. = ALIGN(4);__bss_start = .;.bss : { *(.bss) }_end = .;}.text为代码段,可以看出cpu/arm920t/start.o在代码段的最前面,所以会先执行start.o 中的代码连接完成后的镜像文件的前4K如下cpu/arm920t/start.o(.text).text 0x33f80000 0x4e0 cpu/arm920t/start.o0x33f80050 IRQ_STACK_START0x33f80048 _bss_start0x33f8004c _bss_end0x33f80044 _armboot_start0x33f80000 _start0x33f80054 FIQ_STACK_STARTcpu/arm920t/s3c24x0/nand_read.o(.text).text 0x33f804e0 0x1b8 cpu/arm920t/s3c24x0/nand_read.o0x33f804e0 nand_read_ll*(.text).text 0x33f80698 0x64 board/smdk2440/libsmdk2440.a(lowlevel_init.o)0x33f8069c lowlevel_init.text 0x33f806fc 0x280 cpu/arm920t/libarm920t.a(interrupts.o)0x33f80934 do_fiq0x33f80880 do_undefined_instruction0x33f80744 show_regs0x33f80958 do_irq0x33f80728 bad_mode0x33f808c8 do_prefetch_abort0x33f8070c disable_interrupts0x33f80910 do_not_used0x33f808ec do_data_abort0x33f808a4 do_software_interrupt0x33f806fc enable_interrupts.text 0x33f8097c 0x250 cpu/arm920t/s3c24x0/libs3c24x0.a(interrupts.o)0x33f80aa4 set_timer0x33f80a20 reset_timer0x33f8097c interrupt_init0x33f80ba0 get_tbclk0x33f80a90 get_timer0x33f809f0 reset_timer_masked0x33f80a24 get_timer_masked0x33f80ab4 udelay0x33f80b10 udelay_masked0x33f80bac reset_cpu0x33f80b8c get_ticks.text 0x33f80bcc 0x150 cpu/arm920t/s3c24x0/libs3c24x0.a(speed.o)0x33f80c4c get_HCLK0x33f80cec get_PCLK0x33f80c44 get_FCLK0x33f80d14 get_UCLK.text 0x33f80d1c 0x1e8 cpu/arm920t/s3c24x0/libs3c24x0.a(cmd_s3c24xx.o) 0x33f80d8c do_s3c24xx.text 0x33f80f04 0xdc cpu/arm920t/s3c24x0/libs3c24x0.a(serial.o)0x33f80f04 serial_setbrg0x33f80fa8 serial_tstc0x33f80f80 serial_putc0x33f80f58 serial_init0x33f80fb8 serial_puts0x33f80f68 serial_getc.text 0x33f80fe0 0x140 lib_arm/libarm.a(_divsi3.o)0x33f80fe0 __divsi3如何设置从0x33f80000开始呢?~这是链接的时候指定的在根目录下面的config.mk中有下面一句LDFLAGS += -Bstatic -T $(LDSCRIPT) -Ttext $(TEXT_BASE) $(PLATFORM_LDFLAGS)关键就是其中的-Ttext $(TEXT_BASE),这句指明了代码段的起始地址而TEXT_BASE在board/smdk2440/config.mk中定义TEXT_BASE = 0x33F8 0000 为什么是0x33F8 0000呢?~这是将NAND中Uboot拷贝到RAM中的起始地址,所以在代码拷贝到RAM之前不能使用绝对地址来寻址数据,只能用相对地址在以下将用虚拟地址来指Uboot在RAM中的地址,也就是0x33F8 0000现在来看代码cpu/arm920t/start.S_start: ;异常处理向量表b start_codeldr pc, _undefined_instruction ;未定义指令异常：0x00000004ldr pc, _software_interrupt ;软中断异常:0x00000008ldr pc, _prefetch_abort ;预取异常：0x0000000Cldr pc, _data_abort ;数据异常:0x00000010ldr pc, _not_used ;未使用：0x00000014ldr pc, _irq ;外部中断请求IRQ:0x00000018ldr pc, _fiq ;快束中断请求FIQ:0x0000001Cb start_code在虚拟地址0x33F8 0000处, 拷贝到Boot Internal SRAM后则位于0x0处,所以b start_code是第一条执行的指令,start_code在cpu/arm920t/start.S中代码如下://读取CPSR寄存器的内容到R0mrs r0,cpsr//清除R0中的0 - 4 这5个位后保存到R0中//也就是清除用户模式位bic r0,r0,#0x1f//置R0的0 1 4 6 7 位为真//也就是选择SVC模式,同时IRQ和FIQ被禁止，处理器处于ARM状态//关闭中断和快速中断orr r0,r0,#0xd3//将R0中的值保存到CPSR上msr cpsr,r0# define pWTCON 0x53000000 ;看门狗控制寄存器WTCON# define INTMSK 0x4A000008 ;中断屏蔽寄存器INTMSK# define INTSUBMSK 0x4A00001C ;辅助中断屏蔽寄存器，由于外设中断源太多，要用此寄存器屏蔽剩余的中断源# define LOCKTIME 0x4c000000 ;PLL锁定时间计数寄存器# define MPLLCON 0x4c000004 ;主时钟锁相环控制寄存器# define UPLLCON 0x4c000008# define CLKDIVN 0x4C000014 ;时钟分频寄存器/* clock divisor register */# define INTSUBMSK_val 0xffff# define MPLLCON_val ((184 12) + (2 4) + 2) /*406M*/# define UPLLCON_val ((60 12) + (4 4) + 2) /* 47M */# define CLKDIVN_val 7 /* FCLK:HCLK:PCLK = 1:3:6 */# define CAMDIVN 0x4C000018//取得看门狗寄存器的地址ldr r0, =pWTCON//将R1寄存器清0mov r1, #0x0//将看门狗寄存器清0，即将看门狗禁止，包括定时器定时，溢出中断及溢出复位等str r1, [r0]/** mask all IRQs by setting all bits in the INTMR - default*///设R1寄存器为0xFFFF FFFFmov r1, #0xffffffff//读取中断屏蔽寄存器的地址ldr r0, =INTMSK//将中断屏蔽寄存器中的位全设1,屏蔽所有中断str r1, [r0]//# define INTSUBMSK_val 0xffff//设R1寄存器为0xFFFFldr r1, =INTSUBMSK_val//读取辅助中断屏蔽寄存器的地址ldr r0, =INTSUBMSK//将辅助中断屏蔽寄中的11个中断信号屏蔽掉，本人觉得INTSUBMS_val应设成7ff str r1, [r0]//# define LOCKTIME 0x4c000000//读取PLL锁频计数器寄存器地址到R0中ldr r0,=LOCKTIME//将R1设为0x00FF FFFFldr r1,=0xffffff//M_LTIME为最大的0xFFF//U_LTIME为最大的0xFFFstr r1,[r0] ;0xfff=4096>1800，远远满足锁定要求/* FCLK:HCLK:PCLK = 1:2:4 *//* default FCLK is 120 MHz ! *///# define CLKDIVN 0x4C000014 /* clock divisor register *///读取时钟分频寄存器的地址ldr r0, =CLKDIVN//# define CLKDIVN_val 7 /* FCLK:HCLK:PCLK = 1:3:6 *///将R1设为0x7mov r1, #CLKDIVN_va//PDIVN - 1: PCLK has the clock same as the HCLK/2.//HDIVN - 11 : HCLK = FCLK/3 when CAMDIVN[8] = 0.// HCLK = FCLK/6 when CAMDIVN[8] = 1.str r1, [r0]/* Make sure we get FCLK:HCLK:PCLK = 1:3:6 *///# define CAMDIVN 0x4C000018//读取摄像头时钟分频寄存器的地址ldr r0, =CAMDIVN//将R1设为0mov r1, #0//将摄像头时钟分频寄存器清0str r1, [r0]/* Clock asynchronous mode *///MRC p15, 0, Rd, c1, c0, 0 ; read control register//读取控制寄存器中的值到R1中mrc p15, 0, r1, c1, c0, 0 ;将协处理器p15的寄存器c1和c0的值传到arm处理器的R1寄存器中//31 iA bit Asynchronous clock select//30 nF bit notFastBus selectorr r1, r1, #0xc0000000 ;将最高两位置1//MCR p15, 0, Rd, c1, c0, 0 ; write control register//将R1中的值写到控制寄存器中mcr p15, 0, r1, c1, c0, 0 将arm的寄存器R1的32位数据传到协处理器p15的两个16位寄存器c1和c0//# define UPLLCON 0x4c000008//读取UPLL设置寄存器的地址到R0中ldr r0,=UPLLCON//# define UPLLCON_val ((60ldr r1,=UPLLCON_val//将R1中的值写入UPLL设置寄存器中str r1,[r0]//ARM920T为5级流水线,需要至少5个周期来让指令生效nopnopnopnopnopnopnopnop//读取MPLL设置寄存器的地址到R0中ldr r0,=MPLLCON//# define MPLLCON_val ((184ldr r1,=MPLLCON_val//将R1中的值写入MPLL设置寄存器中str r1,[r0]#define GPJCON 0x560000D0#define GPJDAT 0x560000D4#define GPJUP 0x560000D8//跳转到cpu_init_crit处执行//并将下一条指令的地址写入LR寄存器中bl cpu_init_critcpu_init_crit在cpu/arm920t/start.S中代码如下:cpu_init_crit:/** flush v4 I/D caches*///将R0寄存器置0mov r0, #0//Invalidate ICache and DCache SBZ MCR p15,0,Rd,c7,c7,0 //禁止指令和数据cachemcr p15, 0, r0, c7, c7, 0 /* flush v3/v4 cache *///Invalidate TLB(s) SBZ MCR p15,0,Rd,c8,c7,0mcr p15, 0, r0, c8, c7, 0 /* flush v4 TLB *//** disable MMU stuff and caches*///MRC p15, 0, Rd, c1, c0, 0 ; read control registermrc p15, 0, r0, c1, c0, 0//清除[8] [9] [13] 这3个位//8 - System protection//9 - ROM protection//13 - Base location of exception registers - 0 = Low addresses = 0x00000000. bic r0, r0, #0x00002300 // clear bits 13, 9:8 (--V- --RS)//清除[0] [1] [2] [7] 这4个位// 0 - MMU enable - 0 = MMU disabled.// 1 - Alignment fault enable - 0 = Fault checking disabled.// 2 - DCache enable - 0 = DCache disabled.// 7 - Endianness - 0 = Little-endian operation.bic r0, r0, #0x00000087 // clear bits 7, 2:0 (B--- -CAM)//设置位[1]为真// 1 - Alignment fault enable - 1 = Fault checking enabled.orr r0, r0, #0x00000002 // set bit 2 (A) Align//设置位[12]为真//12 - ICache enable - 1 = ICache enabled.orr r0, r0, #0x00001000 // set bit 12 (I) I-Cache//MCR p15, 0, Rd, c1, c0, 0 ; write control registermcr p15, 0, r0, c1, c0, 0//将返回地址保存到IP中mov ip, lr//跳转到lowlevel_init中执行bl lowlevel_initcpu_init_crit在cpu/arm920t/start.S中代码如下:.globl lowlevel_init//读取下面标号为SMRDATA处的地址到R0中ldr r0, =SMRDATA//读取上面标号为_TEXT_BASE处的地址内容到R1中//也就是取得TEXT_BASE的值到R1中ldr r1, _TEXT_BASE//计算SMRDATA的相对地址保存到R0中//SMRDATA为虚拟地址,而TEXT_BASE为虚拟地址的起始地址//而现在Uboot的起始地址并不为虚拟地址//TEXT_BASE为0x33F8 0000,SMRDATA为0x33F8 06C8//而现在程序运行在起始地址为0x0000 0000的地方//所以需要计算以0x0000 0000为标准的相对地址sub r0, r0, r1//取得带宽与等待状态控制寄存器地址到R1中ldr r1, =BWSCON /* Bus Width Status Controller *///一共需要设置13个寄存器,每个寄存器4字节add r2, r0, #13*40://读取R0所指的项的值到R3中后R0自加4字节ldr r3, [r0], #4//将R3中的值保存到R1所指的地址中后R1自加4字节str r3, [r1], #4//比较R0和R2是否相等,相等则说明13个寄存器全部设置完毕cmp r2, r0//不等则跳转到上面标号为0处的地址继续执行bne 0b//跳回到返回地址中继续执行mov pc, lr.ltorg/* the literal pools origin */SMRDATA:.word(0+(B1_BWSCON4)+(B2_BWSCON8)+(B3_BWSCON12)+(B4_BWSCON16)+( B5_BWSCON20)+(B6_BWSCON24)+(B7_BWSCON28)).word((B0_Tacs13)+(B0_Tcos11)+(B0_T acc8)+(B0_Tcoh6)+(B0_T ah4)+(B0_T acp2) +(B0_PMC)).word((B1_Tacs13)+(B1_Tcos11)+(B1_T acc8)+(B1_Tcoh6)+(B1_T ah4)+(B1_T acp2) +(B1_PMC)).word((B2_Tacs13)+(B2_Tcos11)+(B2_T acc8)+(B2_Tcoh6)+(B2_T ah4)+(B2_T acp2) +(B2_PMC)).word((B3_Tacs13)+(B3_Tcos11)+(B3_T acc8)+(B3_Tcoh6)+(B3_T ah4)+(B3_T acp2) +(B3_PMC)).word((B4_Tacs13)+(B4_Tcos11)+(B4_T acc8)+(B4_Tcoh6)+(B4_T ah4)+(B4_T acp2) +(B4_PMC)).word((B5_Tacs13)+(B5_Tcos11)+(B5_T acc8)+(B5_Tcoh6)+(B5_T ah4)+(B5_T acp2) +(B5_PMC)).word ((B6_MT15)+(B6_Trcd2)+(B6_SCAN)).word ((B7_MT15)+(B7_Trcd2)+(B7_SCAN)).word ((REFEN23)+(TREFMD22)+(Trp20)+(Trc18)+(Tchr16)+REFCNT).word 0x32.word 0x30.word 0x30执行mov pc, lr后将返回到cpu_init_crit中剩下来还有2条指令//恢复返回地址到LRmov lr, ip//跳转到返回地址mov pc, lr执行完毕之后将返回到start_code中执行接下来的代码代码如下://#define GPJCON 0x560000D0//取得J端口控制寄存器的地址到R0中LDR R0, = GPJCON//将R1设置为0x1 5555LDR R1, = 0x15555//将R1中的值保存到J端口控制寄存器//GPJ0 - 01 - Output//GPJ1 - 01 - Output//GPJ2 - 01 - Output//GPJ3 - 01 - Output//GPJ4 - 01 - OutputSTR R1, [R0]//#define GPJUP 0x560000D8//取得J端口上拉功能寄存器的地址到R0中LDR R0, = GPJUP//将R1设置为0x1FLDR R1, = 0x1f//将R1中的值保存到J端口上拉功能寄存器//禁止GPJ0 - GPJ4的上拉功能STR R1, [R0]//#define GPJDAT 0x560000D4//取得J端口数据寄存器的地址到R0中LDR R0, = GPJDAT//将R1设为0x0LDR R1, = 0x00//将R1中的值保存到J端口数据寄存器//将J端口数据寄存器清0STR R1, [R0]//下面是NAND数据拷贝过程//relocate:copy_myself://#define S3C2440_NAND_BASE 0x4E000000//取得Nand Flash设置寄存器的地址mov r1, #S3C2440_NAND_BASE//将R2设为0xFFF0ldr r2, =0xfff0 // initial value tacls=3,rph0=7,rph1=7 //#define oNFCONF 0x00//读取Nand Flash设置寄存器中的值到R3中ldr r3, [r1, #oNFCONF]//将R3或上R2后保存到R3中orr r3, r3, r2//将R3中的值保存到Nand Flash设置寄存器中//TWRPH0 - 111 - Duration = HCLK * (TWRPH0 + 1) //TACLS - 11 - Duration = HCLK * TACLSstr r3, [r1, #oNFCONF]//#define oNFCONT 0x04//读取Nand Flash控制寄存器中的值到R3中ldr r3, [r1, #oNFCONT]//将R3的[0]位置1orr r3, r3, #1 // enable nand controller//将R3中的值保存到Nand Flash控制寄存器中//Mode - 1:Nand Flash Controller Enablestr r3, [r1, #oNFCONT]//读取虚拟起始地址到R0中ldr r0, _TEXT_BASE /* upper 128 KiB: relocated uboot *///预留malloc所需要的空间sub r0, r0, #CFG_MALLOC_LEN /* malloc area *///预留bdinfo所需要的空间sub r0, r0, #CFG_GBL_DATA_SIZE /* bdinfo *///预留中断和快速中断向量表空间sub r0, r0, #(CONFIG_STACKSIZE_IRQ+CONFIG_STACKSIZE_FIQ)//预留12字节给中断栈sub sp, r0, #12 /* leave 3 words for abort-stack */// copy u-boot to RAM//读取虚拟起始地址到R0中,作为目标地址ldr r0, _TEXT_BASE//将R1设为0,作为源地址mov r1, #0x0//将UBOOT大小的值保存在R2中,作为数据大小mov r2, #CFG_UBOOT_SIZE//跳转到nand_read_ll处执行//并将下一条指令的地址保存在LR中bl nand_read_llnand_read_ll的原型为int nand_read_ll(unsigned char *buf, unsigned long start_addr, int size) 之前设置的R0 R1 R2为它的3个参数R0 - bufR1 - start_addrR2 - sizenand_read_ll的代码在cpu/arm920t/s3c24x0/nand_read.c中int nand_read_ll(unsigned char *buf, unsigned long start_addr, int size) {int i, j;//检测源地址和大小是否在NandFlash的边界上if ((start_addr & NAND_BLOCK_MASK) || (size & NAND_BLOCK_MASK)) //不在边界上则返回-1表示出错return -1; /* invalid alignment *//* chip Enable */// #define nand_select() (NFCONT &= ~(1//置NAND Flash控制寄存器中除Reg_nCE外所有的位为1//Reg_nCE - NAND FLASH Memory nFCE signal control//0 - Force nFCE to low (Enable chip select)nand_select();// #define nand_clear_RnB() (NFSTAT |= (1//置NAND Flash操作状态寄存器中的RnB_TransDetect位为1//When RnB low to high transition is occurred, this value set and issue interrupt if enabled.//To clear this value write '1'//1: RnB transition is detectednand_clear_RnB();for (i=0; i10; i++);//从源地址的首地址开始历便所要拷贝的数据大小for (i=start_addr; i (start_addr + size);){//检测地址是否在NAND Flash的边界上if (start_addr % NAND_BLOCK_SIZE == 0){//检测是否为坏块if (is_bad_block(i)){/* Bad block *///向后延伸一个存储块i += NAND_BLOCK_SIZE;size += NAND_BLOCK_SIZE;//跳到下一块continue;}}j = nand_read_page_ll(buf, i);//指向下一块i += j;buf += j;// LED_FLASH();}/* chip Disable */// #define nand_deselect() (NFCONT |= (1//置Reg_nCE位为1//NAND Flash Memory nFCE signal control//1: Force nFCE to High(Disable chip select)nand_deselect();return 0;}nand_read_ll将Uboot从NAND中拷贝到RAM中拷贝完成后将返回到start_code接下来的代码如下://检测R0是否为0,R0为nand_read_ll的返回值tst r0, #0x0//为0则说明无错,跳转到ok_nand_read处执行beq ok_nand_readok_nand_read://将R0设为0mov r0, #0//ldr r1, =0x33f00000//将R1设为虚拟地址起始处ldr r1, _TEXT_BASE//检测0x400个字节mov r2, #0x400 // 4 bytes * 1024 = 4K-bytesgo_next://读取R0处地址的数据到R3中//然后R0自加4字节ldr r3, [r0], #4//读取R1处地址的数据到R4中//然后R1自加4字节ldr r4, [r1], #4//比较R3和R4的数据是否相等//也就是检测Boot Internal SRAM和RAM中的数据是否相等//以保证数据无错teq r3, r4//不等则跳转到notmatchbne notmatch//相等则R2自减4subs r2, r2, #4//当R2为0则跳转到done_nand_readbeq done_nand_read//R2不为0则跳转回go_next继续检测bne go_nextdone_nand_read:LDR R0, = GPJDATLDR R1, = 0x2STR R1, [R0]stack_setup://读取虚拟起始地址到R0中ldr r0, _TEXT_BASE /* upper 128 KiB: relocated uboot */ //预留malloc所需要的空间sub r0, r0, #CFG_MALLOC_LEN /* malloc area *///预留bdinfo所需要的空间sub r0, r0, #CFG_GBL_DATA_SIZE /* bdinfo *///预留中断和快速中断向量表空间sub r0, r0, #(CONFIG_STACKSIZE_IRQ+CONFIG_STACKSIZE_FIQ)//预留12字节给中断栈sub sp, r0, #12 /* leave 3 words for abort-stack */clear_bss://读取BSS段的起始地址ldr r0, _bss_start /* find start of bss segment *///读取BSS段的结束地址ldr r1, _bss_end /* stop here *///将R2设为0x0mov r2, #0x00000000 /* clear */clbss_l://将R2中的值保存在R0所指的地址str r2, [r0] /* clear loop... *///R0自加4字节add r0, r0, #4//比较R0和R1是否相等cmp r0, r1//不等则说明清0还没结束ble clbss_lLDR R0, = GPJDATLDR R1, = 0x1STR R1, [R0]//跳转到start_armboot处执行ldr pc, _start_armboot_start_armboot: .word start_armboot这里start_armboot是一个绝对地址,在朗成所修改的这个Uboot中为0x33F8 13F4 执行ldr pc, _start_armboot之后将会跳到RAM中的绝对地址继续执行整理了一个流程图,分为3个存储器:1 Boot Internal SRAM , 接在BANK0,起始地址为0x02 RAM , 接在BANK6,起始地址为0x3000 00003 NAND FLASH,为单独寻址流程如下图:红字为流程序号:1. 首先将NAND FLASH中的前0x1000字节内容拷贝到Boot Internal SRAM中2. 从Boot Internal SRAM的0x0地址处开始执行指令3. 将Uboot从Flash拷贝到RAM中4. 执行ldr pc, _start_armboot从Boot Internal SRAM中跳转到RAM中的绝对地址0x33F8 13F4处继续执行。
